Summary of Contents for ALFAtron EXT-60IR-Tx
-
Page 2: Safety Precaution
ALFATRON ALF-EXT60IR Statement Thanks for purchasing this product, please read this user manual carefully before using this product. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation. -
Page 3: Package Contents
ALFATRON ALF-EXT60IR Introduction The EXT-60IR extends HDMI signal between Transmitter and Receiver over CATx cable. It supports 1080p@60Hz video signals up to 55m including embedded multi-channel audio and HDCP 1.4. Built-in EDID make this product compatible with most display and source device, to ensure HDMI transmission. -
Page 4: Panel Description
ALFATRON ALF-EXT60IR Panel Description Transmitter (TX) ① CAT OUT: RJ45 connector with Green & Yellow indicators. Connect to Receiver over CATx cable. The Green indicator lights up when powered on. The Yellow indicator lights up when linked successfully between Transmitter and Receiver. -
Page 5: Specifications
ALFATRON ALF-EXT60IR Specifications Transmitter Receiver Input (1) HDMI (1) CAT (1) 19-pin type-A female Input Connector (1) RJ45 HDMI Output (1) HDMI; (1) CAT (1) HDMI (1) 19-pin type-A female (1) 19-pin type-A Output Connector HDMI; (1) RJ45 female HDMI Control (1) IR IN;... -
Page 6: Connection Diagram
Projector Remote IR Receiver DVD Remote 1080P 55m Limited warranty in respect of Alfatron Products Only 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. - Page 7 ALFATRON ALF-EXT60IR This limited warranty does not cover the cost of normal maintenance. Failure of the product due to insufficient or improper maintenance is not covered. 1.4 The Company does not warrant that the product covered hereby, including, without limitation, the technology and/or integrated circuit(s)
