- Page 1 ALFATRON ALF-WL-HDMI Wireless HDMI Extender ALFATRON ELECTRONICS GmbH GERMANY User Manual...
- Page 2 ALFATRON ALF-WL-HDMI Preface Read this user manual carefully before using the product. Pictures shown in this manual are for reference only. Different models and specifications are subject to real product. This manual is only for operation instruction, please contact the local distributor for maintenance assistance.
- Page 3 ALFATRON ALF-WL-HDMI SAFETY PRECAUTIONS To ensure the best performance from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for ...
-
Page 4: Table Of Contents
ALFATRON ALF-WL-HDMI Table of Contents 1. Product Introduction ....................1 1.1 Features ......................1 1.2 Package List ...................... 1 2. Specification ....................... 2 3. Panel Description ......................4 3.1 Transmitter (Tx) ....................4 3.2 Receiver (Rx) ..................... 4 4. System Connection ..................... 5 5. -
Page 5: Product Introduction
ALFATRON ALF-WL-HDMI 1. Product Introduction The ALF-WL-HDMI is a wireless HDMI extension solution kit, it transmits full HD video up to 130m with low latency of 60~100ms as well as low power consumption. It can be used in home theater, conference centers, auditoriums etc. -
Page 6: Specification
ALFATRON ALF-WL-HDMI 2. Specification Transmitter (Tx) Video Input (1) HDMI Video Input Connector (1) Type-A female HDMI (1) DCJACK, (1) DC5V Power Input Power Input Connector (1) DC Jack, (1) Micro-USB Receiver (Rx) Video Output (1) HDMI Video Output Connector... - Page 7 ALFATRON ALF-WL-HDMI Speed of Change Resolution Transmission Distance up to 426ft/130m at 1080P External Power Supply 100V~240V AC, 50/60Hz or 5VDC 1A Tx: 5V 580mA=2.9W Power Consumption Rx: 5V 540mA=2.7W Product Temperature Rx: 37℃, Tx:49℃ Operation Temperature -10℃ ~ +55℃...
-
Page 8: Panel Description
ALFATRON ALF-WL-HDMI 3. Panel Description 3.1 Transmitter (Tx) ① IN: Type-A HDMI port to connect HDMI source ② DCJACK: DC jack for external AC power supply device. ③ DC5V: Micro-USB port for external 5V DC power 110V ~ 220V, 50/60HZ ④... -
Page 9: System Connection
ALFATRON ALF-WL-HDMI 4. System Connection Usage Precautions Make sure all components and accessories included before installation. System should be installed in a clean environment with proper temperature and humidity. All of the power switches, plugs, sockets, and power cords should be insulated and ... -
Page 10: Default System Configuration
ALFATRON ALF-WL-HDMI <Table 1 Hardware Ports> Hardware Ports Transmitter (Tx) Receiver (Rx) HDMI connector Input Output Video / Audio Data WIFI (Antenna) 2T2R 2T2R IEEE 802.11 abgn Only for power Micro-B type USB Power Charge Power Charge charge, not for... -
Page 11: System Configuration
ALFATRON ALF-WL-HDMI 6. System Configuration 6.1 Preparation to connect to Web Server Step 1. In order to configure the Tx and Rx, use a PC with wireless LAN function. Please use PC static IP to connect the web server. Go to “Control Panel -> All Control Panel Items ->... - Page 12 ALFATRON ALF-WL-HDMI And then, click the properties of the Wireless Network in the “Network Connection‟ page. Open “Internet Protocol Version 4 (TCP/IPv4)” on the tap of the Networking, and then click the “Properties‟.
- Page 13 ALFATRON ALF-WL-HDMI Set the IP address and Subnet mask as the following figure. Please check if the wireless network is connected to Tx SSID, “QDM-3000”.
- Page 14 ALFATRON ALF-WL-HDMI After the network setting of the PC, please power on the Tx and Rx. After pairing both devices, please type “20.20.20.1” in the web browser to configure the web servers to configure Tx.
- Page 15 ALFATRON ALF-WL-HDMI Please type “20.20.20.2” in the web browser to configure the web servers to configure Attention: The basic connection of the web server is through the RootAP. To ※ connect the client web server with a browser, the RootAP should be alive and paired with the client.
-
Page 16: Configuration Rx
ALFATRON ALF-WL-HDMI 6.2 Configuration Rx The Tx and Rx should be connected properly. On the “20.20.20.2” page, please select the “Device tap” on the left, and configure as below: A. QIM Mode: Rx B. Startup Mode: Client C. Local IP Addr: 20.20.20.2 (for example) D. - Page 17 ALFATRON ALF-WL-HDMI 2) Please select “Wireless” tab on the left to configure SSID name. Note that both Tx and Rx should connect to the same SSID.
- Page 18 ALFATRON ALF-WL-HDMI 3) Please click the “Save‟ button after configuration of the wireless settings. Subsequently, click the “Reboot‟ button to restart the Tx and Rx, and they will be automatically paired and connected automatically.
-
Page 19: Configuration Tx
ALFATRON ALF-WL-HDMI 6.3 Configuration Tx The Tx and Rx should be connected properly. On the “20.20.20.1” page, please select the “Device tap” on the left, and configure as below: A. QIM Mode: Tx B. Startup Mode: RootAP C. Local IP Addr: 20.20.20.1 (for example) D. -
Page 20: Troubleshooting & Maintenance
ALFATRON ALF-WL-HDMI 7. Troubleshooting & Maintenance Problems Potential Causes Solutions Color loss or no video signal output on the HDMI display. The cables may not be Check the cables are No HDMI signal output in connected correctly or may properly connected and the device while local be faulty. -
Page 21: Warranty
ALFATRON ALF-WL-HDMI 8. Warranty 1. Limited warranty in respect of Alfatron Products Only 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. - Page 22 ALFATRON ALF-WL-HDMI 1.9 A 7 (seven) year limited warranty is given on the aforesaid product where used correctly according to the Company’s instructions, and only with the use of the Company’s components. 1.10 The Company will, at its sole option, provide one of the following three remedies to...
- Page 23 ALFATRON ALF-WL-HDMI liability and the Customer shall pay the price as if the goods had been delivered in accordance with the Agreement. 1.17 THE MAXIMUM LIABILITY OF THE COMPANY UNDER THIS LIMITED WARRANTY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID FOR...
