- Page 1 ALF-EXT60IR-18G 18G HDMI 2.0 HDMI Extender Set over CAT5e/CAT6 Intermark Sistemi Via A. Litta Modignani, 37 - 00144 ROMA Tel +39 06 5205 835 info@intermark.it - www.intermark.it...
-
Page 2: Safety Precaution
Alfatron ALF-EXT60IR-18G Statement Thanks for purchasing this product, please read this user manual carefully before using this product. The functions described in this version are updated till December, 2019. In the constant effort to improve our product, we reserve the right to make functions or parameters changes without notice or obligation. -
Page 3: Product Introduction
Alfatron ALF-EXT60IR-18G Product Introduction The EXT60IR-18G is a cost-effective point-to-point extender set for HDMI 2.0 and IR signals; this kit supports 4K/UHD video @ 60 Hz with 4:4:4 Chroma sampling, as well as HDMI data rates up to 18 Gbps, HDCP 2.2 compliant;... - Page 4 Alfatron ALF-EXT60IR-18G Transmitter Panel Description CATx OUT IR IN IR OUT DISPLAY SOURCE DC 12V EDID BYPASS EDID COPY Tx/3s 1. CATx OUT: RJ45 port to connect the CATx IN port of receiver by CATx cable. It supports 12V PoC to power the receiver. The orange LED illuminates when there is a valid HDMI signal input.
-
Page 5: Connection Diagram
Alfatron ALF-EXT60IR-18G Receiver Panel Description 1. DISPLAY: Type-A female HDMI port to connect HDMI display device. 2. CATx IN: RJ45 port to connect the CATx OUT port of transmitter by CATx cable. It supports 12V PoC and the receiver can be powered from the transmitter. -
Page 6: Specifications
Alfatron ALF-EXT60IR-18G Specifications Transmitter Input (1) SOURCE Input Connector (1) 19-pin type-A female HDMI Output (1) DISPLAY, (1) CATx OUT Output Connector (1) 19-pin type-A female HDMI, (1) RJ45 Control (1) IR IN, (1) IR OUT Control Connector (2) 3.5mm mini jacks... - Page 7 Alfatron ALF-EXT60IR-18G 1. Limited warranty in respect of Alfatron Products Only 1.1 This limited warranty covers defects in materials and workmanship in this product. 1.2 Should warranty service be required, proof of purchase must be presented to the Company. The serial number on the product must be clearly visible and not have been tampered with in any way whatsoever.
- Page 8 Alfatron ALF-EXT60IR-18G This limited warranty does not cover the cost of normal maintenance. Failure of the product due to insufficient or improper maintenance is not covered. 1.4 The Company does not warrant that the product covered hereby, including, without limitation, the technology and/or integrated circuit(s)
- Page 9 Alfatron ALF-EXT60IR-18G 1.9 A 7 (seven) year limited warranty is given on the aforesaid product where used correctly according to the Company’s instructions, and only with the use of the Company’s components. 1.10 The Company will, at its sole option, provide one of the following...
- Page 10 Alfatron ALF-EXT60IR-18G assumes all risks of loss or damage during shipment. The Company will not be responsible for any costs related to the removal or re-installation of this product from or into any installation. The Company will not be responsible for any costs related to any setting up this product, any adjustment of user controls or any programming required for a specific installation of this product.
- Page 11 Alfatron ALF-EXT60IR-18G Company shall have no liability and the Customer shall pay the price as if the goods had been delivered in accordance with the Agreement. 1.17 THE MAXIMUM LIABILITY OF THE COMPANY UNDER THIS LIMITED WARRANTY SHALL NOT EXCEED THE ACTUAL PURCHASE PRICE PAID FOR THE PRODUCT.
