Eurotech Vector ICE Quick Start page 2

Hardware Features
Expansion Port
The 12-position terminal block located on the secondary side of
the enclosure provides an expansion port that can be easily
reconfigured for your application. In the standard configuration,
this port has the following pin assignment:
Pin Name Type Description
1 LINEOUT_L O Line out – Left channel
2 LO_SENSE I Line out sense (note 1)
3 LINEOUT_R O Line out – Right channel
4 GND_HDA P Analog ground
5 SPKR2+ O Speaker 2 – Positive signal
6 SPKR2- O Speaker 2 – Negative signal
7 SPKR1+ O Speaker 1 – Positive signal
8 SPKR1- O Speaker 1 – Negative signal
9 MIC_IN_L I Microphone– Left channel
10 MIC_SENSE I Microphone plug in sense
(note 2)
11 MIC_IN_R I Microphone– Right channel
12 GND_HDA P Analog ground
Notes:
1. The default audio is the stereo speaker output.
Tying LO_SENSE to ground activates the Line out pins.
2. By default, the microphone input is disabled.
To enable, short MIC_SENSE to ground.
USB Host Ports
Two ports are general-purpose USB host ports (500 mA max),
while two ports support high-current, plug-in modules (1 A max).
VGA Output
The VGA output supports a standard monitor. This output also
provides a Display Data Channel interface (DDC_SDA pin 12 and
DDC_SCL pin 15) for monitor "Plug and Play".
Ethernet
Network settings are configured to operate with a DHCP server.
Technical Support
The Eurotech support site includes errata reports, the latest
releases of documents, and developer's forums. These
resources are available to registered developers at
http://support.eurotech-inc.com/
Next Steps
For a complete description of the Vector SBC including electrical
specifications, see the Vector User Manual (#110124-7000).
110124-70071
Serial Ports
The Vector ICE provides two EIA-232/485 serial ports with the
following pin assignment on the serial port plugs:
Pin
2
3
Vector SBC
5
J5.1
7
J5.2
8
J5.3
Note: Other pins are not connected.
J5.4
CAN
J4.1
The current Linux release does not support CAN.
J4.2
Future releases will support two CAN 2.0B buses with the
J4.3
following pin assignment on the CAN plug:
J4.4
J6.1 Pin
J6.2
1
2
J6.3
7
J6.4
8
Note: Other pins are not connected.
Enclosure
The Vector ICE enclosure has the following dimensions:
Dimensions
Length
Width (lid)
Width (base with mounting tabs)
Height
Weight
The enclosure is not intended to be opened by the customer.
Contact Us
EUROTECH
Toll-free +1 888.941.2224
Tel.
Fax
E-mail:
E-mail:
Web:
EIA-232 Type EIA-485
(Default) (Option)
RXD I RX-
TXD O TX-
GND P GND
RTS O TX+
CTS I RX+
Name Type Description
CANLOW_2 IO CAN 2-
CANLOW_1 IO CAN 1-
CANHIGH_1 IO CAN 1+
CANHIGH_2 IO CAN 2+
+1 301.490.4007
+1 301.490.4582
sales.us@eurotech.com
support.us@eurotech.com
www.eurotech-inc.com
Type Vector SBC
(J27 or J34)
I 3
O 5
P 9
O 4
I 6
Vector SBC
J25.2
J24.2
J24.1
J25.1
141 mm (5.6 in.)
188 mm (7.4 in.)
239 mm (9.4 in.)
65 mm (2.6 in.)
1.1 kg (2.5 lbs.)
