R-410A, 13 SEER
LATITUDE™ SERIES
UQ024-060
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unit Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Site Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Clearances. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
(Manufactured Housing) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Supply and Return Ducts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
The Return - Air Grille Boxes. . . . . . . . . . . . . . . . . . . . . . . . . . 7
Wye Insulation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Discharge Duct Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Installing Of Duct To Unit (Residential) . . . . . . . . . . . . . . . . . . . . 10
Installing Drain Tube And Connection . . . . . . . . . . . . . . . . . . . . . 10
Service Access . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
1 Unit Limitations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
3 Unit Clearances . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
4 Demand Defrost Selection . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Electrical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
6 Physical Data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
1 Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
2 Air Discharge Clearance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
3 Unit 4 Point Load Weight . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
4 Unit Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
5 Return Air Box and Grille . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
6 Wye Installation (Outlet) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Wye Installation (Inlet and Outlet) . . . . . . . . . . . . . . . . . . . . . 9

General

®
YORK
Model UQ units are factory assembled heat pump
designed to be installed along side the home or building. Field-
installed electric heater accessories are available to provide
supplemental electric heat.
The units are completely assembled on rigid base rails. All
piping, refrigerant charge, and electrical wiring is factory
installed and tested. The units require only electric power and
duct connections at the point of installation.
The electric heaters have nickel-chrome resistance wire
elements and utilize single point power connection.
Safety Considerations
This is a safety alert symbol
labels or in manuals, be alert to the potential for personal injury.
Understand and pay particular attention the signal words
DANGER, WARNING or CAUTION.

TABLE OF CONTENTS

LIST OF TABLES
LIST OF FIGURES
. When you see this symbol on
Compressors . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power And Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Power Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Control Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Wall Thermostat Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Pre-start Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
System Startup, Check-out . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Other Features Incorporated In The Control . . . . . . . . . . . . . . . . 13
Anti-Short Cycle time Delay. . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Safety Lock-Out. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Normal Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Typical Wiring Diagrams . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
7 Airflow Performance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
8 Additional Static Resistance . . . . . . . . . . . . . . . . . . . . . . . . . 17
9 Electric Heat Minimum Supply Air . . . . . . . . . . . . . . . . . . . . . 19
10 Indoor Blower Specifications . . . . . . . . . . . . . . . . . . . . . . . . . 19
11 Electric Heat Multipliers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
8 Duct Connector (With Damper) . . . . . . . . . . . . . . . . . . . . . . . 9
9 Duct Connector (No Damper) . . . . . . . . . . . . . . . . . . . . . . . . 9
10 Unit Component Location . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
11 Thermostat Wiring . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
12 Switch Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
13 Defrost Operation Curves . . . . . . . . . . . . . . . . . . . . . . . . . . 14
DANGER indicates an imminently hazardous situation, which,
if not avoided, will result in death or serious injury.
WARNING indicates a potentially hazardous situation, which,
if not avoided, could result in death or serious injury.
CAUTION indicates a potentially hazardous situation, which, if
not avoided may result in minor or moderate injury. It is also
used to alert against unsafe practices and hazards involving
only property damage.
Improper installation may create a condition where the
operation of the product could cause personal injury or
property damage. Improper installation, adjustment,
alteration, service or maintenance can cause injury or
property damage. Refer to this manual for assistance or
for additional information, consult a qualified contractor,
installer or service agency.
SO 9001
Certified Quality
Management System
548267-YIM-C-0211

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Latitude UQ024-060 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for York Latitude UQ024-060

  • Page 1: Table Of Contents

    DANGER indicates an imminently hazardous situation, which, if not avoided, will result in death or serious injury. ® YORK Model UQ units are factory assembled heat pump WARNING indicates a potentially hazardous situation, which, designed to be installed along side the home or building. Field- if not avoided, could result in death or serious injury.
  • Page 2 This system uses R-410A Refrigerant which operates at Renewal Parts higher pressures than R-22. No other refrigerant may be ® Contact your local York parts distribution center for authorized used in this system. Gage sets, hoses, refrigerant replacement parts. containers and recovery systems must be designed to handle R-410A.
  • Page 3: Installation

    548267-YIM-C-0211 Installation Refer to Table 6 for unit physical data and to Table 5 for electrical data. Limitations If components are to be added to a unit to meet local codes, These units must be installed in accordance with the following they are to be installed at the dealer's and/or the customer's national and local safety codes.
  • Page 4: Unit Location

    548267-YIM-C-0211 Unit Location heat pump base pan onto the ground below. A slight grade away from the unit will improve drainage. Several important factors must be considered before selecting 10. Average Winter Snow Depth - The heat pump must be the site for this unit: installed above the average snow depth to allow the Site –...
  • Page 5: Clearances

    548267-YIM-C-0211 Clearances All units require certain clearances for proper operation and service. Refer to Table 3 for the clearances required for construction, servicing and proper unit operation. Rear Left Right Front Figure 3: Unit 4 Point Load Weight Size Weight (lbs.) Center of Gravity 4 Point Load Location (lbs.) (Tons)
  • Page 6: Unit Dimensions

    548267-YIM-C-0211 HIGH VOLTAGE CONN. Ø7/8" KNOCKOUT HIGH VOLTAGE CONN. Ø1 3/32" KNOCKOUT HIGH VOLTAGE CONN. Ø1 3/8" 15-13/16 KNOCKOUT 13-9/16 CONDENSATE DRAIN 3/4" NPT LOW VOLTAGE CONN. Ø7/8" BUSHING 7-7/16 4-13/16 4-3/8 DUCT FLANGE ØG 1-15/16 2-9/16 Unit Dimensions Figure 4: Table 2: Unit Dimensions Size Dimensions...
  • Page 7: Installing Of Duct To Unit (Manufactured Housing)

    548267-YIM-C-0211 Table 3: Unit Clearances Distance Distance Direction Direction (in.) (in.) Right Front Left Rear Bottom 1. Units must be installed outdoors. Over hanging structure or shrubs should not obscure condenser air discharge outlet. 2. Unit may be positioned to draw air from underneath structure. Installing Of Duct To Unit...
  • Page 8: Wye Insulation

    548267-YIM-C-0211 When attaching the flex duct to the return air box, secure Insert a stub collar in the raw end of the duct and tape the duct collar and return box collar together with at least securely in place. three (3) sheet metal screws and seal with duct tape. Make sure the duct is not stretched tight and does not have Set the return air box, with flex duct attached, back into the kinks from excessive length after installation.
  • Page 9: Discharge Duct Installation

    548267-YIM-C-0211 Grille Filter Return Box Damper* Flex Duct Grille 12” Duct Connectors Filter Return Box Damper* Flex Duct Flex Duct WYE Insulation Recommended 12 x12 x12 12 x12 x12 for Greater Efficiency and Performance of Unit. May use duct connector without damper if no interior furnace or air handler is connected to duct system.
  • Page 10: Installing Of Duct To Unit (Residential)

    548267-YIM-C-0211 If using the duct connector with damper, cut a 9-1/8”x 16-1/8” (located in the front corner of the unit), and the drain tube hole in the center of the duct bottom. If using the 12” diameter installed on the barbed end of the plastic fitting secured in duct connector without damper cut a 12-1/8”...
  • Page 11: Compressors

    548267-YIM-C-0211 Compressors Power And Control Wiring The compressor used in this product is specifically designed to Field wiring to the unit must conform to provisions of the current operate with R-410A Refrigerant and cannot be interchanged. N.E.C. ANSI/NFPA No. 70 or C.E.C. and/or local ordinances. The unit must be electrically grounded in accordance with local codes or, in their absence, with the N.E.C./C.E.C.
  • Page 12: Control Wiring

    548267-YIM-C-0211 Control Wiring Wall Thermostat Installation Run low voltage control circuit wires through the “fingered” snap bushing into the low voltage compartment. Run low voltage control circuit wires through the fingered snap bushing to the low voltage terminal wire. Refer to If installing this heat pump system in conjunction with a Figure 11 diagram to connect the low voltage control wiring gas furnace, a baffle must be installed in the furnace to...
  • Page 13: Pre-Start Procedure

    548267-YIM-C-0211 Raise the wall thermostat temperature selection lever to a Cooling Heating setting above the room temperature. The heat pump Thermostat Thermostat should now run in the heating mode. To check the emergency heat operation, set the wall thermostat system switch to EMERGENCY HEAT. Raise the wall thermostat temperature selection lever high enough to close the second stage of the thermostat, if it is not already closed.
  • Page 14: Demand Defrost Selection

    548267-YIM-C-0211 Defrost Operation inhibit feature prohibits defrost if the coil temperature is above 40°F. The demand defrost control implements a temperature differential (”delta-T”) demand defrost algorithm. The heat pump A forced-defrost feature puts the system into a defrost period is allowed to operate in the heating mode until the combination every 6 hours and 4 minutes to recirculate lubricants, unless the of outdoor ambient and outdoor coil temperatures indicate that coil temperature is above 40°F.
  • Page 15: Ton

    548267-YIM-C-0211 Table 5: Electrical Data OD Fan Supply Factory Compressors Motors Blower Electric Heat Option Size MOCP Fuse (each) Volt (each) Motor (Tons) (Amps) (Amps) Size (Amps) Model Stages Amps None 22.1 2PH08520506 3.6/4.8 17.2/19.9 43.6/46.9 50/50 50/50 208/230-1-60 13.4 58.3 21.0 2PH08520706...
  • Page 16: Physical Data

    548267-YIM-C-0211 Table 6: Physical Data Models Component UQ024 UQ030 UQ036 UQ042 UQ048 UQ060 Nominal Tonnage ARI COOLING PERFORMANCE Gross Capacity @ ARI A point (Btu) 23220 28750 37000 41404 48000 54384 ARI net capacity (Btu) 22600 28000 35200 40200 46500 53000 11.2 11.2...
  • Page 17: Airflow Performance

    548267-YIM-C-0211 Airflow Performance Table 7: Airflow Performance External Static Pressure (Inch Water Gauge) Size Unit Speed) (Tons) SCFM SCFM SCFM SCFM SCFM 1004 1115 Low/Medium 1005 1072 Medium 1037 1057 1121 (2.0) Medium/High 1185 1137 1071 1048 1010 1109 1170 High 1336 1031...
  • Page 18 548267-YIM-C-0211 Table 8: Additional Static Resistance (Continued) Electric Heat, kW Size Model Wet Indoor Coil (Tons) 0.09 0.09 0.09 0.10 0.12 0.10 0.10 0.11 0.13 0.12 0.12 0.12 0.13 0.15 0.13 0.13 0.13 0.14 0.17 0.15 0.15 0.15 0.16 0.19 1000 0.17 0.17...
  • Page 19: Maintenance

    548267-YIM-C-0211 Table 9: Electric Heat Minimum Supply Air Minimum Supply Air (CFM) Size Voltage Heater kW (Tons) 10.0 15.0 208/230-1-60 (2.0) 208/230-1-60 (2.5) 208/230-1-60 (3.0) 208/230-1-60 1300 1300 1270 1270 (3.5) 208/230-1-60 1300 1300 1270 1270 (4.0) 208/230-1-60 1300 1300 1270 1270 (5.0)
  • Page 20: Typical Wiring Diagrams

    548267-YIM-C-0211 Typical Wiring Diagrams UQ024-060 Typical Heat Pump 208/230-1-60 volt Wiring Diagram Unitary Products Group...
  • Page 21 548267-YIM-C-0211 UQ036, 048 and 060 Typical Heat Pump 208/230-3-60 volt Wiring Diagram Unitary Products Group...
  • Page 22 UQ060 Typical Heat Pump 460-3-60 volt Wiring Diagram Subject to change without notice. Printed in U.S.A. 548267-YIM-C-0211 Copyright © 2011 by Unitary Products Group. All rights reserved. Supersedes: 548267-YIM-B-0910 Johnson Controls Unitary Products 5005 York Drive Norman, OK 73069...
