- Page 1 Quick Start Guide Compact Excavators 8008 CTS, 8010 CTS...
- Page 2 This machine should not be operated by any person who isn’t appropriately qualified or had the appropriate training. > Operation of this machine without periodic maintenance could cause it to malfunction. For more information please contact your JCB Dealer. Please see operator manual for full details.
-
Page 3: Table Of Contents
Shut Down Sequence ........................13 Mechanical Hitch Unlock ........................14 Maintenance Position ........................15 Service & Maintenance ........................16 Service & Access Covers........................17 Service / Maintenance Points ......................18 Fluids & Lubricants ..........................19 Machine Attachments ........................20 Troubleshooting / FAQs ........................21 Your Notes ..........................22-23 8008 CTS, 8010 CTS... -
Page 4: Intended Use
Intended Use General > Machine Type – Compact Excavator > Self propelled machine with a tracked undercarriage > 360° revolving upper structure with boom, dipper, bucket and slew mechanism Intended Use > Machine intended to be used in normal conditions as detailed in the operators manual >... -
Page 5: Dimensions
1110* Transport weight 1028 1028* * Operating weight to ISO 6016 including cab, rubber tracks, standard dipper, standard dozer, (460 mm) bucket, full tanks and 75 kg operator. Please see data plate for specific machine weight 8008 CTS, 8010 CTS... -
Page 6: Tie Down Points
Tie Down Points Fig 2 Machines fitted with mechanical slew lock, engage slew lock. Ensure by operating the slew control that the slew lock is engaged. Close the bucket. Position the dipper vertically and lower the boom until the bucket rests on a wooden block on the trailer bed. -
Page 7: Lifting Points
1. On each end of the dozer blade at point A. 2. On each side of the boom at points B. The correct lifting positions are identified on the machine by their labels: Lifting point position label. REFER TO OPERATORS MANUAL TRANSPORTING MACHINE 8008 CTS, 8010 CTS... -
Page 8: Cab Layout & Controls
Cab & Switch Panel Operator Station Layout Fig 4 1 Track controls 2 Hand throttle lever 3 Console switches 4 Starter switch 5 Instrument panel 6 Excavator controls 7 Dozer control 8 Extending undercarriage control 9 Excavator lever lock Switch Panel Fig 5 A Graphic symbol B Light bar... - Page 9 Instrument Panel Instrument Panel Fig 7 A Hourmeter B Charge (fault) indicator C Glow plugs (on) indicator D Low fuel indicator E Engine oil pressure (low) indicator F Coolant temperature (high) indicator 8008 CTS, 8010 CTS...
- Page 10 Excavator Controls Excavator Levers Fig 8 A Slew cab left B Slew cab right C Raise boom D Lower boom E Dipper in F Dipper out G Close bucket (to gather a load) H Open bucket (to dump a load) Swing Pedal Fig 9 Fig 10...
- Page 11 Dozer Lever Fig 11 Fig 12 A Control lever B Lower the dozer C Raise the dozer Extending Undercarriage Fig 13 Fig 14 A Control lever B Extend undercarriage C Retract undercarriage 8008 CTS, 8010 CTS...
-
Page 12: Start Up Sequence
Start Up Sequence Engage Seat Belt Engine Pre Heat Start Machine Move the throttle lever to half From ignition position 2 turn Engage seat belt (A) into latch speed position. Turn the starter ignition to position 3 to start (B) before starting machine. key to position 2 for 6 seconds the machine. -
Page 13: Shut Down Sequence
D to the locked and remove key. attachment (A) just above position. Leave machine using the ground and dozer (B) the handrails and footholds. on the ground. Make sure the engine cover is locked. A Handle B LH armrest 8008 CTS, 8010 CTS... -
Page 14: Mechanical Hitch Unlock
Mechanical Hitch Unlock System Park Machine Up Disconnect Attachment Insert tommy bar Park the machine on firm level Stop the engine, remove any Insert the tommy bar into the ground. Position the attach- connected hydraulic hoses and hole of the latch hook. Attachments ment (A) just above the ground remove the locking pin. -
Page 15: Maintenance Position
A Attachment flat on the ground B Dozer blade lowered to ground Stop the engine Discharge the hydraulic pressure Isolate the controls and remove ignition key Isolate the battery to prevent accidental operation of the engine 8008 CTS, 8010 CTS... -
Page 16: Service & Maintenance
Service & Maintenance Daily Checks (10h) Action Check condition of attachments / optional equipment Visual check Grease attachments / optional equipment/ pivot pins as required Lubricate Clean bodywork and framework Clean Check condition of bodywork and framework and general machine Visual check Check engine for leaks and oil level Visual check... -
Page 17: Service & Access Covers
Always adjust and latch the seat fully to the rear before raising the engine cover. Make sure that you return the seat to your correct operating position before operating the machine. The engine cover allows access to all key components on the Micro machines. 8008 CTS, 8010 CTS... -
Page 18: Service / Maintenance Points
Service / Maintenance Points Engine Compartment Fig 17 A Hydraulic oil level indicator B Oil Dipstick C Hydraulic filler cap D Hydraulic filter Cooling System Fig 18 A Radiator cap Air Filter & Battery Fig 19 A Battery B Air filter Please see operator manual for full details. -
Page 19: Fluids & Lubricants
JCB Special Slew Pinion Grease 4003/1619 400g All Other Grease – JCB MPL-EP Grease 4003/1501 400g JCB part numbers are liable to change and may also vary by region. For the latest information, always check with your dealer/distributor. 8008 CTS, 8010 CTS... -
Page 20: Machine Attachments
Machine Attachments Description Weight (kg) Machines Hydraulic Requirements Mechanical Quickhitch 8010 None Bucket GP 150mm 12 – 30 8008 – 80310 None Bucket GP 230mm 17 – 29 8008 – 8010 None Bucket GP 300mm 19 – 25 8008 – 8010 None Bucket GP 400mm 23 –... -
Page 21: Troubleshooting/Faqs
Digging to dozer can not be done while machine dig end is central to Can you dig to dozer? the dozer. To dig to dozer slew machine over to the side then use the boom swing to offset the boom enabling digging up to the dozer. 8008 CTS, 8010 CTS... -
Page 22: Your Notes
Your Notes Please see operator manual for full details. - Page 23 Your Notes 8008 CTS, 8010 CTS...
- Page 24 They should not therefore be relied upon in relation to suitability for a particular application. Guidance and advice should always be sought from your JCB Dealer’. JCB reserves the right to change specifications without notice. Illustrations and specifications shown may include optional equipment and accessories.
