FatTwin
®
F619P2-FT
F619P3-FT
USER'S MANUAL
Revision 1.0a

Advertisement

Table of Contents
loading

Related Manuals for Supermicro FatTwin F619P2-FT

Summary of Contents for Supermicro FatTwin F619P2-FT

  • Page 1 FatTwin ® F619P2-FT F619P3-FT USER’S MANUAL Revision 1.0a...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Secure Data Deletion A secure data deletion tool designed to fully erase all data from storage devices can be found on our website: https://www.supermicro.com/about/policies/disclaimer.cfm?url=/wdl/utility/...

  • Page 4: Table Of Contents

    Preface Contents Chapter 1 Introduction 1.1 Overview ..........................9 1.2 Unpacking the System ......................9 1.3 FatTwin: System Notes ......................10 Nodes ..........................10 System Power ........................10 1.4 System Features ........................11 1.5 Server Chassis Features ....................12 Node Controls ........................12 Front Features ........................13 Rear Features ........................14 1.6 Motherboard Layout ......................15 Quick Reference Table ......................16 Chapter 2 Server Installation...
  • Page 5 FatTwin F619P2/3-FT User's Manual Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................25 3.2 Chassis Components ......................26 Installing and Removing the Node Drawers ..............26 Removing Nodes from the Chassis ................27 Removing the Cover from the Node................27 Node Configurations......................28 Overview of the Node ....................28 F418IF3-R2K20BP Node Layout ...................28 Nodes and Associated Hard Drives ..................29 Installing and Removing 2.5"...
  • Page 6 Preface Memory Support and Installation ..................48 ESD Precautions .......................48 Precautions ........................48 Introduction to Intel® Optane DC Persistent Memory ............48 Memory Support ......................48 Memory Installation Sequence ..................49 General Memory Population Requirements ..............50 DIMM Installation ......................52 DIMM Module Removal .....................52 Motherboard Battery ......................53 Chapter 4 Motherboard Connections 4.1 Power Connections ......................54 4.2 Headers and Connectors ....................55...
  • Page 7 Appendix C System Specifications Appendix D UEFI BIOS Recovery Appendix E BSMI Safety Warnings...
  • Page 8 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 9: Chapter 1 Introduction

    Chapter 1: Introduction Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the F619P2/3-FT. The F619P2/3-FT is based on the X11DPFF-SN motherboard and the F418IF3-R2K20BP chassis. This FatTwin system includes eight motherboard tray nodes in the chassis. In addition to the motherboard and chassis, several important parts that are included with the system are listed below.

  • Page 10: Fattwin: System Notes

    FatTwin F619P2/3-FT User's Manual 1.3 FatTwin: System Notes As a FatTwin configuration, the FatTwin F619P2/3-FT is a unique server system. With eight system boards incorporated into a single chassis acting as eight separate nodes, there are several points you should keep in mind. Nodes Each of the eight serverboards act as a separate node in the system.

  • Page 11: System Features

    Chapter 1: Introduction 1.4 System Features The following table provides you with an overview of the main features of the F619P2/3-FT. Please refer to Appendix C for additional specifications. System Features Motherboard X11DPFF-SN Chassis F418IF3-R2K20BP Dual 81xx/61xx/51xx/41xx/31xx or 82xx/62xx/52xx/42xx/32xx processor which offer 2 UPI (UltraPath Interconnect) of up to 10.4GT/s Note: Both CPUs need to be installed for full access to the PCI-E slots, DIMM slots, and onboard controllers.

  • Page 12: Server Chassis Features

    FatTwin F619P2/3-FT User's Manual 1.5 Server Chassis Features Node Controls Each node has a power button and UID LED located with I/O ports on the front of the node. See Chapter 4 for details on the node controls. Figure 1-1. Node Controls Node Controls Item Feature...

  • Page 13: Front Features

    Chapter 1: Introduction Front Features The F418IF3-R2K20BP is a 4U chassis with eight hot-swap server nodes. See the illustration below for the features included on the front of the chassis. Figure 1-2. Chassis Front View Front Chassis Features Item Feature Description See the section for node controls above for details, and see chapter 4 Node Ports and Controls (8)

  • Page 14: Rear Features

    FatTwin F619P2/3-FT User's Manual Rear Features The illustration below shows the features included on the rear of the chassis. PWS Slot2 PWS Slot2 PWS Slot1 PWS Slot1 Figure 1-3. Chassis Rear View Rear Chassis Features Item Feature Description Power Supply Four (4) redundant 2000 or 2200 Watt power supplies The chassis has eight rear fans for cooling.

  • Page 15: Motherboard Layout

    Chapter 1: Introduction 1.6 Motherboard Layout Below is a layout of the X11DPFF-SN with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. UID LED Failure LED USB0/1...

  • Page 16: Quick Reference Table

    FatTwin F619P2/3-FT User's Manual Quick Reference Table Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) JPME2 ME Manufacturing Mode Pins 1-2 (Normal) JWD1 Watch Dog Timer Enable Pins 1-2 (Reset) Connector Description Battery (BT1) Onboard CMOS battery CPU1 Slot1 PCI-E (JPCEI4) PCI-E 3.0 x16 slot supported by CPU1 CPU1 Slot2 PCI-E (Slot 2) PCI-E 3.0 x8 slot supported by CPU1...
  • Page 17 Chapter 1: Introduction #F-1 #M-1 #E-1 #L-1 #D-1 #K-1 VR13 VR13 #C-1 #J-1 PHASE PHASE #B-1 #H-1 #A-1 #G-1 Proccessor Proccessor PECI: 30 PECI: 30 SOCKET ID:0 SOCKET ID:1 DMI3 DMI3 PCI-E X4 X2 G3 PCI-E X8 G3 PCI-E X16 G3 PCI-E X16 G3 PCI-E X16 G3 DMI3...

  • Page 18: Chapter 2 Server Installation

    FatTwin F619P2/3-FT User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 19: Server Precautions

    Chapter 2: Server Installation • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 20: Circuit Overloading

    FatTwin F619P2/3-FT User's Manual Note: Insert the nodes into the chassis from the bottom left to bottom right and then up all the way to the top (left first, then right). Do not insert the nodes on one side fully (leaving one side empty) and then the other side or it will be very hard to insert the last node.

  • Page 21: Rack Mounting Instructions

    Chapter 2: Server Installation 2.3 Rack Mounting Instructions This section provides information on installing the chassis into a rack unit with the rails provided. There are a variety of rack units on the market, which may mean that the assembly procedure will differ slightly from the instructions provided.

  • Page 22: Identifying The Sections Of The Rack Rails

    FatTwin F619P2/3-FT User's Manual Identifying the Sections of the Rack Rails The chassis package includes two rail assemblies in the rack mounting kit. Each assembly consists of two sections: A front section which secures to the front post of the rack and a rear section which adjusts in length and secures to the rear post of the rack.

  • Page 23: Installing The Rails On A Rack

    Chapter 2: Server Installation Installing the Rails on a Rack Installing the Rails 1. Adjust the length of both rails as described on the previous page. 2. Align the front section of the outer rail with the slots on the front post of the rack. Secure the front of the outer rail to the rack with two screws.

  • Page 24: Chassis Installation

    FatTwin F619P2/3-FT User's Manual Chassis Installation Installing the Chassis into a Rack 1. Confirm that the rails are correctly installed on the rack. 2. Align the bottom of the chassis with the bottom of the rails. 3. Insert the chassis into the F619P2/3-FT rails, keeping the pressure even on both sides, pushing the chassis into the rack until it clicks into the locked position.

  • Page 25: Chapter 3 Maintenance And Component Installation

    FatTwin F619P2/3-FT User's Manual Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 26: Chassis Components

    Chapter 3: Maintenance and Component Installation 3.2 Chassis Components The chassis includes power supplies, fans and eight nodes. Each node is a separate system containing a drawer with a serverboard and other components. Each node may be removed from the chassis separately. Installing and Removing the Node Drawers The F418IF3 chassis contains eight individual motherboards in separate node drawers (Figure 3-1).

  • Page 27: Removing Nodes From The Chassis

    FatTwin F619P2/3-FT User's Manual Removing Nodes from the Chassis Each of the eight individual nodes may be removed from the chassis separately. Note that when a node is removed from the chassis, the hard drives located in the node will shut-down. Removing a Node 1.

  • Page 28: Node Configurations

    Chapter 3: Maintenance and Component Installation Node Configurations Overview of the Node Node configuration for a typical node is shown below in Figure 3-3. Front of Rear of the Node the Node Figure 3-3. Front and Rear of the F418IF3-R2K20BP Node F418IF3-R2K20BP Node Layout The specifications for the F418IF3-R2K20BP nodes are shown in the table below.

  • Page 29: Nodes And Associated Hard Drives

    FatTwin F619P2/3-FT User's Manual Nodes and Associated Hard Drives The F418IF3 chassis contains up to eight individual motherboards in separate 1U nodes. Each node has either two 2.5" drives, with an additional optional two 2.5" drives for the P2 model, or two 3.5" drives for the P3 model. Zero nodes have eight drives. Note that if a node is pulled out of the chassis, the hard drives associated with that node will power down as well.
  • Page 30 Chapter 3: Maintenance and Component Installation 4. Remove the screws securing the hard drive to the tray and set them aside for later use. Figure 3-5. Installing a Hard Drive in the Drive Carrier 5. Lift the hard drive up and out of the tray. 6.

  • Page 31: Drive Carrier Indicators

    Blinking at 1 Hz Attention state—do not remove NVMe device (not supported in VMD mode) Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at https://www.

  • Page 32: Checking The Temperature Of An Nvme Drive

    Chapter 3: Maintenance and Component Installation Figure 3-7. IPMI Screenshot Replacing the Drive 1. Insert the replacement drive. 2. IPMI > Server Health > NVMe SSD 3. Select Device, Group and slot and click Insert. The drive Status LED indicator flashes red, then turns off.

  • Page 33: Installing And Replacing 3.5" Hard Drives

    FatTwin F619P2/3-FT User's Manual Installing and Replacing 3.5" Hard Drives Replacing a Fixed 3.5" Hard Drive 1. Remove the node from the chassis and remove the cover from the node as described previously in this section. 2. Push the release tab on the tool-less hard drive tray to remove the tray and drive together from the floor of the node chassis.

  • Page 34: Installing Expansion Cards

    Chapter 3: Maintenance and Component Installation Installing Expansion Cards Each of the eight nodes in the chassis has space for two low-profile expansion cards mounted in the front of the node. The following instructions are for chassis nodes in which the expansion cards are mounted in the front of the node.

  • Page 35: Assembling The Pci-E Slot Bracket Assembly

    FatTwin F619P2/3-FT User's Manual Assembling the PCI-E Slot Bracket Assembly Each node supports two expansion cards in front of the node. Each expansion card must be plugged into a riser card, which in turn plugs into the motherboard. Assembling the PCI-E Slot Bracket Assembly 1.
  • Page 36 Chapter 3: Maintenance and Component Installation 5. Insert the riser card into the appropriate slot on the motherboard. 6. Simultaneously insert the expansion card into the riser card, while sliding the expansion card bracket into the open PCI-E slot. Figure 3-11. Installing the Expansion Card and Bracket into the Node...

  • Page 37: Installing Air Shrouds

    FatTwin F619P2/3-FT User's Manual Installing Air Shrouds Air Shrouds Air shrouds concentrate airflow to maximize fan efficiency. The F418IF3 chassis require an air shroud in each node. Installing an Air Shroud 1. Remove the node from the chassis and remove the cover from the node as described previously in this section.

  • Page 38: Removing And Installing System Fans

    Chapter 3: Maintenance and Component Installation Removing and Installing System Fans Removing and Installing External System Fans The chassis has eight fans in the rear of the system. Fans that fail can be replaced by simply removing them from the rear without powering down the system. Removing a Rear Exhaust Fan 1.

  • Page 39: Replacing The Power Supplies

    The F418IF3 chassis utilizes redundant power supplies. In the unlikely event that the power supply unit needs to be replaced, a power supply can be removed, without powering down the system. Replacement units can be ordered directly from Supermicro (See the contact information in the Preface of this manual).

  • Page 40: Motherboard Components

    CPU socket cap is in place and none of the socket pins are bent; otherwise, contact your retailer immediately. • Refer to the Supermicro website for updates on CPU support. The Processor (The 81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx processor ) Note: All graphics, drawings and pictures shown in this manual are for illustration only.

  • Page 41: Overview Of The Processor Socket Assembly

    FatTwin F619P2/3-FT User's Manual Overview of the Processor Socket Assembly The processor socket assembly contains 1) the 81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx processor 2) CPU/heatsink carrier, 3) dust cover, and 4) CPU socket. The 81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx processor Processor 2. CPU/Heatsink Carrier 3.

  • Page 42: Overview Of The Processor Heatsink Module

    Chapter 3: Maintenance and Component Installation Overview of the Processor Heatsink Module The processor heatsink module (PHM) contains 1) a passive heatsink, 2) a CPU/heatsink carrier, and 3) The 81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx processor. 1. Passive Heatsink 2. CPU/Heatsink Carrier 81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx processor Processor Heatsink Module (Bottom View)

  • Page 43: Preparing The Cpu Socket For Installation

    FatTwin F619P2/3-FT User's Manual Preparing the CPU Socket for Installation This motherboard comes with the CPU socket pre-assembled in the factory. The CPU socket contains 1) a dust cover, 2) a socket bracket, 3) the CPU (LGA3647) socket, and 4) a back plate.

  • Page 44: Attaching The Processor To The Cpu/Heatsink Carrier

    Chapter 3: Maintenance and Component Installation Attaching the Processor to the CPU/Heatsink Carrier To properly install the CPU onto the CPU/heatsink carrier, please follow the steps below. Installing the CPU onto the CPU/heatsink 1. Locate Pin 1 (Notch A), Notch B, and Notch C on the CPU and locate Pin 1 (Notch A), Notch B, and Notch C on the CPU/heatsink carrier.

  • Page 45: Attaching The Cpu/Carrier Assembly To The Passive Heatsink To Form The Processor Heatsink Module (Phm)

    FatTwin F619P2/3-FT User's Manual Attaching the CPU/Carrier Assembly to the Passive Heatsink to Form the Processor Heatsink Module (PHM) After you have made a CPU/carrier assembly, please follow the steps below to mount the assembly onto the heatsink to create the Processor Heatsink Module (PHM). 1.

  • Page 46: Installing The Processor Heatsink Module (Phm)

    Chapter 3: Maintenance and Component Installation Installing the Processor Heatsink Module (PHM) 1. Once you have assembled the processor heatsink module (PHM) by following the instructions listed on the previous page, align the processor heatsink module with the CPU socket on the motherboard. 2.

  • Page 47: Removing The Processor Heatsink Module (Phm)

    FatTwin F619P2/3-FT User's Manual Removing the Processor Heatsink Module (PHM) Before starting to remove the processor heatsink module (PHM), unplug power cord from the power outlet. 1. Using a T30-size star driver, turn the screws on the PHM counterclockwise to loosen it from the socket, starting with screw marked #4 (in the sequence of 4, 3, 2, 1).

  • Page 48: Memory Support And Installation

    Chapter 3: Maintenance and Component Installation Memory Support and Installation Note: Check the Supermicro website for recommended memory modules. Important: Exercise extreme care when installing or removing DIMM modules to prevent any damage. ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules.

  • Page 49: Memory Installation Sequence

    8Rx4 4H-128 GB 4H-256 GB Check the Supermicro website for possible updates to memory support. Memory Installation Sequence Memory modules for the X11 UP/DP/MP motherboards are populated using the "Fill First" method. The blue memory slot of each channel is considered the "first DIMM module" of the channel, and the black slot, the second module of the channel.

  • Page 50: General Memory Population Requirements

    3. Populating memory slots with a pair of DIMM modules of the same type and size will result in interleaved memory, which will improve memory performance. Note: Unbalanced memory configuration decreases memory performance and is not recommended for Supermicro motherboards. Memory Population Table for X11DP Motherboards (w/12 Slots) based on the 81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx Platforms...
  • Page 51 FatTwin F619P2/3-FT User's Manual DCPMM Table for the X11DP Motherboards (w/12 Slots) based on the 82xx/62xx/52xx/42xx Platform Symmetric Population within 1 CPU Socket Modes P1-DIMMF1 P1-DIMME1 P1-DIMMD1 P1-DIMMA1 P1-DIMMB1 P1-DIMMC1 Channel Config. DCPMM DRAM1 DRAM1 DRAM1 DRAM1 DCPMM 1-1-1 DCPMM DRAM1 DRAM1 DRAM1...

  • Page 52: Dimm Installation

    Chapter 3: Maintenance and Component Installation DIMM Installation 1. Follow the instructions given in the memory population guidelines listed in the previous sections to install memory modules on your motherboard. For the X11DPFF-SN Rev. 1.00 system to work properly, please use memory modules of the same type and speed on the motherboard.

  • Page 53: Motherboard Battery

    FatTwin F619P2/3-FT User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 54: Chapter 4 Motherboard Connections

    FatTwin F619P2/3-FT User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A severboard layout indicating component locations may be found in Chapter 1.

  • Page 55: Headers And Connectors

    Chapter 4: Motherboard Connections 8-Pin HDD Power Connectors Two 8-pin HDD power connectors, located at HDD_PWR1/2, provide power to HDD devices. Connect appropriate power cables to use HDD power connectors. See the table below for pin definitions. 8-pin Power HDD_PWR1/2 Pin Definitions Pin# Definitions...
  • Page 56 The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80 card, which is available from Supermicro. A TPM/Port 80 module is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.
  • Page 57 Chapter 4: Motherboard Connections PCI-E/SATA M.2 Hybrid Slots This motherboard has two PCI-E/SATA Hybrid M.2 slots located at M.2-HC0 (J30)/M.2-HC1 (J31). The M.2, formerly known as "Next Generation Form Factor (NGFF)", replaces a mini PCI-E/SATA device and supports a variety of card sizes. M.2 offers increased functionality and improved spatial efficiency.

  • Page 58: Front I/O Ports

    FatTwin F619P2/3-FT User's Manual 4.3 Front I/O Ports See the figure below for the locations and descriptions of the various I/O ports on the front of the motherboard. X11DPFF-SN Rev. 1.00 Figure 4-1. Front Panel I/O Port Locations and Definitions Front Panel I/O Ports Description No.
  • Page 59 UID LED. Please note that the UID switch can also be triggered via IPMI on the motherboard. For more information, please refer to the IPMI User's Guide posted on our website at http://www.supermicro.com.) UID Switch...
  • Page 60 FatTwin F619P2/3-FT User's Manual Super I/O Module (SIOM) A Supermicro proprietary SIOM (Super I/O Module) connector, supported by CPU1, is located at each node's front. This SIOM slot supports PCI-E 3.0 x16 SIOM cards. Connect your SIOM cards into the SIOM slot with approved and qualified for FatTwin SIOM cards, indicated on the SIOM Networking AOC Compatibility Matrix.

  • Page 61: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.

  • Page 62: Led Indicators

    FatTwin F619P2/3-FT User's Manual ME Manufacturing Mode Close pins 1 and 2 of JPME2 to bypass SPI flash security and force the system to use the ME Manufacturing Mode, which will allow you to flash the system firmware from a host server to modify system settings.
  • Page 63 Chapter 4: Motherboard Connections HDD Activity LED An HDD Activity LED is located at HDD_LED1 on the on the motherboard. When this LED is blinking, your hard drive devices are active. See the table below for the LED status. HDD Activity LED Indicator LED State Definition HDD_LED1...

  • Page 64: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 65 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 66: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wdl/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD.

  • Page 67: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 68: Chapter 6 Uefi Bios

    FatTwin F619P2/3-FT User's Manual Chapter 6 UEFI BIOS 6.1 Introduction This chapter describes the AMIBIOS™ setup utility for the X11DPFF-SN motherboard. The BIOS ROM is stored on a chip and can be easily upgraded using a flash program. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted and might not yet be recorded in this manual.

  • Page 69: Main Setup

    Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2014 after RTC reset. Supermicro X11DPFF-SN BIOS Version This item displays the version of the BIOS ROM used in the system.
  • Page 70 FatTwin F619P2/3-FT User's Manual CPLD Version This item displays the version of the CPLD (Complex-Programmable Logical Device) used in the system. Memory Information Total Memory This item displays the total size of memory available in the system.

  • Page 71: Advanced Setup Configurations

    Chapter 4: UEFI BIOS 6.3 Advanced Setup Configurations Use the arrow keys to select the Advanced submenu and press <Enter> to access the submenu items. Warning: Take Caution when changing the Advanced settings. An incorrect value, an incorrect DRAM frequency, or an incorrect BIOS timing setting may cause the system to malfunction. When this occurs, restore the setting to the manufacture default settings.
  • Page 72 FatTwin F619P2/3-FT User's Manual Option ROM Messages Use this feature to set the display mode for Option ROM message settings. Select Keep Current to use the current AddOn ROM display setting. Select Force BIOS to use the display mode that is set by the system BIOS. The options are Force BIOS and Keep Current. Bootup NumLock State Use this feature to set the Power-on state for the Numlock key.
  • Page 73 Chapter 4: UEFI BIOS Restore on AC Power Loss Use this feature to set the power state after a power outage. Select Power-Off for the system power to remain off after a power loss. Select Power-On for the system power to be turned on after a power loss. Select Last State to allow the system to resume its last power state before a power loss.
  • Page 74 FatTwin F619P2/3-FT User's Manual Hyper-Threading (ALL) Select Enable to use Intel Hyper-Threading Technology to enhance CPU performance. The options are Enable and Disable. Core Enabled Use this feature to enable or disable CPU cores in the processor specified by the user. Enter 0 to enable all cores available in the processor.
  • Page 75 Chapter 4: UEFI BIOS DCU (Data Cache Unit) IP Prefetcher If this feature is set to Enable, the IP prefetcher in the DCU (Data Cache Unit) will prefetch IP addresses to improve network connectivity and system performance. The options are Enable and Disable.
  • Page 76 FatTwin F619P2/3-FT User's Manual CPU P State Control (Available when "Power Technology" is set to Custom)  SpeedStep (PStates) EIST (Enhanced Intel SpeedStep Technology) allows the system to automatically adjust processor voltage and core frequency in an effort to reduce power consumption and heat dissipation.
  • Page 77 Chapter 4: UEFI BIOS Enhanced Halt State (C1E) Select Enable to enable "Enhanced Halt State" support, which will significantly reduce the CPU's power consumption by minimizing CPU's clock cycles and reduce voltage during a "Halt State." The options are Disable and Enable. Package C State Control (Available when "Power Technology"...
  • Page 78 FatTwin F619P2/3-FT User's Manual Degrade Precedence Use this feature to select the degrading precedence option for UPI (Ultra Path Interconnect) connections. Select Topology Precedent to degrade UPI features if system options are in conflict. Select Feature Precedent to degrade UPI topology if system options are in conflict. The options are Topology Precedence and Feature Precedence.
  • Page 79 Chapter 4: UEFI BIOS LLC Dead Line Alloc Select Enable to opportunistically fill the deadlines in LLC (Last Level Cache). The options are Enable, Disable, and Auto. Isoc Mode Select Enable to enable Isochronous support to meet QoS (Quality of Service) requirements. This feature is especially important for Virtualization Technology.
  • Page 80 FatTwin F619P2/3-FT User's Manual Enable ADR (Available when an NVDIMM is detected) Select Enable for ADR (Automatic Diagnostic Repository) support to enhance memory performance. The options are Enable and Disable. Erase-Arm NVDIMMs (Available when an NVDIMM is detected & the item above: Enable ADR is set to Enable) If this feature is set to Enable, the function that arms the NVDIMMs for save operations in the event of a power loss will be removed.
  • Page 81 Chapter 4: UEFI BIOS Memory Topology  This item displays the information of onboard memory modules as detected by the BIOS. • P1DIMMA1/P1DIMMB1/P1DIMMC1/P1DIMMD1/P1DIMME1/P1DIMMF1 • P2DIMMA1/P2DIMMB1/P2DIMMC1/P2DIMMD1/P2DIMME1/P2DIMMF1 Memory RAS (Reliability_Availability_Serviceability) Configuration  Use this submenu to configure the following Memory RAS settings. Static Virtual Lockstep Mode Select Enable to support the Static Virtual Lockstep mode to enhance memory performance.
  • Page 82 FatTwin F619P2/3-FT User's Manual Correctable Error Threshold Use this item to enter the threshold value for correctable memory errors. The default setting is 100. Intel Run Sure (Available when this feature is supported by the CPU) Select Enable to support Intel® Run Sure Technology to further enhance critical data protection and to increase system uptime and resiliency.
  • Page 83 Chapter 4: UEFI BIOS IIO Configuration  EV DFX (Device Function On-Hide) Features When this feature is set to Enable, the EV_DFX Lock Bits that are located in a processor will always remain clear during electric tuning. The options are Disable and Enable. CPU1 Configuration/CPU2 Configuration ...
  • Page 84 FatTwin F619P2/3-FT User's Manual IOAT Configuration Disable TPH (TLP Processing Hint) TPH is used for data-tagging with a destination ID among other important attributes. It can send critical data to a particular cache without writing through to memory. Select No in this item for TLP Processing Hint support, which will allow a "TPL request"...
  • Page 85 Chapter 4: UEFI BIOS ATS (Available when the item: Intel VT for Directed I/O ((VT-d)) is set to Enable) Select Enable to enable ATS (Address Translation Services) support for the Non-Iscoh VT-d engine to enhance system performance. The options are Enable and Disable. Posted Interrupt (Available when the item: Intel VT for Directed I/O ((VT-d)) is set to Enable) Select Enable to support VT_D Posted Interrupt which will allow external interrupts to be...
  • Page 86 FatTwin F619P2/3-FT User's Manual VMD port 3C~VMD port 3D (Available when the device is detected by the system) Select Enable to use the Intel Volume Management Device Technology for this specific root port. The options are Disable and Enable. Hot Plug Capable (Available when the device is detected by the system) Use this feature to enable hot plug support for PCI-E root ports 3A~3D.
  • Page 87 Chapter 4: UEFI BIOS Intel® VMD for Volume Management Device Select Enable to use the Intel Volume Management Device Technology for this stack. The options are Disable and Enable. *If the item "Intel VMD for Volume Management Device" above is set to Enable, the following items will be displayed: VMD port 3A~VMD port 3D (Available when the device is detected by the system) Select Enable to use the Intel Volume Management Device Technology for this specific root...
  • Page 88 FatTwin F619P2/3-FT User's Manual PCI-E PLL SSC Select Enable for PCH PCI-E Spread Spectrum Clocking support, which will allow the BIOS to monitor and attempt to reduce the level of Electromagnetic Interference caused by the components whenever needed. The options are Enable and Disable. Server ME (Management Engine) Configuration ...
  • Page 89 Chapter 4: UEFI BIOS Aggressive Link Power Management When this item is set to Enabled, the SATA AHCI controller manages the power use of the SATA link. The controller will put the link in a low power mode during an extended period of I/O inactivity, and will return the link to an active state when I/O activity resumes.
  • Page 90 FatTwin F619P2/3-FT User's Manual sSATA RSTe Boot Info (Available when the item: "Configure sSATA as" is set to RAID) Select Enable to provide the full int13h support for sSATA controller attached devices. The options are Disable and Enable. Aggressive Link Power Management When this item is set to Enable, the sSATA AHCI controller manages the power use of the SATA link.
  • Page 91 Chapter 4: UEFI BIOS SR-IOV Support (Available if the system supports Single-Root Virtualization) Select Enabled for Single-Root IO Virtualization support. The options are Enabled and Disabled. MMIO High Base Use this feature to select the base memory size according to memory-address mapping for the IO hub.
  • Page 92 FatTwin F619P2/3-FT User's Manual Onboard Video Option ROM Use this feature to select the Onboard Video Option ROM type. The options are Disabled, Legacy and EFI.  Network Stack Configuration Network Stack Select Enabled to enable PXE (Preboot Execution Environment) or UEFI (Unified Extensible Firmware Interface) for network stack support.
  • Page 93 Chapter 4: UEFI BIOS  Super IO Configuration Super IO Chip AST2500  Serial Port 1 Configuration Serial Port 1 Select Enabled to enable the onboard serial port specified by the user. The options are Enabled and Disabled. Device Settings (Not Available when Serial Port 1 is set to Disabled.) This feature displays the base I/O port address and the Interrupt Request address of a serial port specified by the user.
  • Page 94 FatTwin F619P2/3-FT User's Manual Serial Port Console Redirection  COM 1 Console Redirection Select Enabled to enable COM Port 1 for Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking. The options are Enabled and Disabled.
  • Page 95 Chapter 4: UEFI BIOS Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow. Send a "Stop" signal to stop sending data when the receiving buffer is full. Send a "Start" signal to start sending data when the receiving buffer is empty. The options are None and Hardware RTS/CTS.
  • Page 96 FatTwin F619P2/3-FT User's Manual Console Redirection Settings (for SOL/COM2)  Use this feature to specify how the host computer will exchange data with the client computer, which is the remote computer used by the user. Terminal Type Use this feature to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII Character set.
  • Page 97 Chapter 4: UEFI BIOS Recorder Mode Select Enabled to capture the data displayed on a terminal and send it as text messages to a remote server. The options are Disabled and Enabled. Resolution 100x31 Select Enabled for extended-terminal resolution support. The options are Disabled and Enabled.
  • Page 98 FatTwin F619P2/3-FT User's Manual (EMS) Console Redirection Settings Out-of-Band Management Port The feature selects a serial port in a client server to be used by the Windows Emergency Management Services (EMS) to communicate with a remote host server. The options are COM1 (Console Redirection) and SOL (Console Redirection).
  • Page 99 Chapter 4: UEFI BIOS High Precision Event Timer Select Enabled to activate the High Precision Event Timer (HPET) that produces periodic interrupts at a much higher frequency than a Real-time Clock (RTC) does in synchronizing multimedia streams, providing smooth playback and reducing the dependency on other timestamp calculation devices, such as an x86 RDTSC Instruction embedded in the CPU.
  • Page 100 FatTwin F619P2/3-FT User's Manual Security Device Support If this feature and the TPM jumper (JPT1), if available, are both enabled, the onboard security (TPM) device will be enabled in the BIOS to enhance data integrity and system security. Please note that the OS will not show the security device. Neither TCG EFI protocol nor INT1A interaction will be available for use.
  • Page 101 Notes. 1: If the option for this item (TXT Support) is set to Enabled, be sure to disable EV DFX (Device Function On-Hide) support for the system to work properly. (EV DFX is under "IIO Configuration" in the "Chipset/North Bridge" submenu). 2: For more information on TPM, please refer to the TPM manual at http://www.supermicro.com/manuals/other. iSCSI Configuration ...

  • Page 102: Event Logs

    FatTwin F619P2/3-FT User's Manual 6.4 Event Logs Use this feature to configure Event Log settings. Change SMBIOS Event Log Settings Enabling/Disabling Options SMBIOS Event Log Select Enabled to enable SMBIOS (System Management BIOS) Event Logging during system boot. The options are Enabled and Disabled. Erasing Settings Erase Event Log (Available when the item: SMBIOS Event Log is set to Enabled) Select Enabled to erase all error events in the SMBIOS (System Management BIOS) log...
  • Page 103 Chapter 4: UEFI BIOS When Log is Full (Available when the item: SMBIOS Event Log is set to Enabled) Select Erase Immediately to immediately erase all errors in the SMBIOS event log when the event log is full. Select Do Nothing for the system to do nothing when the SMBIOS event log is full.

  • Page 104: Ipmi

    FatTwin F619P2/3-FT User's Manual 6.5 IPMI Use this feature to configure Intelligent Platform Management Interface (IPMI) settings. When you select this submenu and press the <Enter> key, the following information will display: • BMC Firmware Revision: This feature indicates the firmware revision of the BMC (Base- board Management Controller) used in your system.
  • Page 105 Chapter 4: UEFI BIOS Erase SEL (Available when the item: SEL Components is set to Enabled) Select Yes, On next reset to erase all system event logs upon next system reboot. Select Yes, On every reset to erase all system event logs upon each system reboot. Select No to keep all system event logs after each system reboot.
  • Page 106 FatTwin F619P2/3-FT User's Manual IPMI Network Link Status This item displays the IPMI Network Link status. The default setting is Dedicated LAN. Configuration Address Source Use this feature to select the IP address source for this computer. If Static is selected, you will need to know the IP address of this computer and enter it to the system manually in the field.

  • Page 107: Security Settings

    Chapter 4: UEFI BIOS 6.6 Security Settings This menu allows the user to configure the following security settings for the system. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 characters to 20 characters long. User Password Use this feature to set the user password which is required to enter the BIOS setup utility.
  • Page 108 FatTwin F619P2/3-FT User's Manual Secure Boot  When you select this submenu and press the <Enter> key, the following items will display: • System Mode • Secure Boot • Vendor Keys Secure Boot If this feature is set to Enabled, Secure Boot will be activated when a Platform Key (PK) is entered.
  • Page 109 Chapter 4: UEFI BIOS Platform Key (PK)  This feature allows the user to enter and configure a set of values to be used as a platform firmware key for the system. This set of values also indicate the size, the keys numbers, and the key source of the Platform Key.

  • Page 110: Boot Settings

    FatTwin F619P2/3-FT User's Manual 6.7 Boot Settings Use this feature to configure Boot Settings: Boot Mode Select Use this feature to select the type of devices to be used for system boot. The options are Legacy, UEFI (Unified Extensible Firmware Interface), and Dual. Legacy to EFI Support Select Enabled for the system to boot from an EFI OS when the Legacy OS fails.
  • Page 111 Chapter 4: UEFI BIOS • Boot Option #1 - Boot Option #8 *When the item above -"Boot Mode Select" is set to UEFI, the following items will be display for configuration: • Boot Option #1 - Boot Option #9 Add New Boot Option This feature allows the user to add a new boot option to the boot priority features for your system.
  • Page 112 FatTwin F619P2/3-FT User's Manual Delete Boot Option Use this feature to remove an EFI boot option from the boot priority list.  Delete Driver Option Use this item to select a boot driver to delete from the boot priority list. Delete Drive Option Select the target boot driver to delete from the boot priority list.

  • Page 113: Save & Exit

    Chapter 4: UEFI BIOS 6.8 Save & Exit Select the Save & Exit tab from the BIOS setup screen to configure the settings below. Save Options Discard Changes and Exit Select this option to quit the BIOS setup without making any permanent changes to the system configuration and reboot the computer.
  • Page 114 FatTwin F619P2/3-FT User's Manual Discard Changes Select this option and press <Enter> to discard all the changes and return to the AMI BIOS setup utility. Default Options Restore Optimized Defaults To set this feature, select Restore Defaults from the Exit menu and press <Enter> to load manufacturer default settings which are intended for maximum system performance but not for maximum stability.

  • Page 115: Appendix A Bios Error Codes

    Appendix A: BIOS Error Codes Appendix A BIOS Error Codes A-1 BIOS Error Beep (POST) Codes During the POST (Power-On Self-Test) routines, which are performed each time the system is powered on, errors may occur. Non-fatal errors are those which, in most cases, allow the system to continue the boot-up process.
  • Page 116 When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 117: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 118 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 119 FatTwin F619P2/3-FT User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 120 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 121 FatTwin F619P2/3-FT User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 122 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 123 FatTwin F619P2/3-FT User's Manual ‫אזהרה מפני ניתוק חשמלי‬ ‫!אזהרה‬ ‫יש לנתק את המערכת מכל מקורות החשמל ויש להסיר את כבל החשמלי מהספק‬ ‫.לפני גישה לחלק הפנימי של המארז לצורך התקנת או הסרת רכיבים‬ ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت...
  • Page 124 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 125 FatTwin F619P2/3-FT User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 126 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 127 FatTwin F619P2/3-FT User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 128 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 129 FatTwin F619P2/3-FT User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 130 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 131 FatTwin F619P2/3-FT User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 132 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 133 FatTwin F619P2/3-FT User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 134 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 135 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 136 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...
  • Page 137 Appendix C: System Specifications Appendix C System Specifications Processors Dual 81xx/61xx/51xx/41xx/31xx and 82xx/62xx/52xx/42xx/32xx processor in an Socket P0 type sockets for each node. Note: Please refer to the motherboard specifications pages on our website for updates to supported processors. Chipset C621 chipset BIOS 32 MB SPI AMI BIOS®...
  • Page 138 FatTwin F619P2/3-FT User's Manual Operating Environment Operating Temperature: 10º to 35º C (50º to 95º F) Non-operating Temperature: -40º to 60º C (-40º to 140º F) Operating Relative Humidity: 8% to 90% (non-condensing) Non-operating Relative Humidity: 5% to 95% (non-condensing) Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6,...
  • Page 139 Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 140 Note: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www. supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 141 Appendix D: UEFI BIOS Recovery 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 142 FatTwin F619P2/3-FT User's Manual 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
  • Page 143 Appendix D: UEFI BIOS Recovery 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process. Note: Do not interrupt this process until the BIOS flashing is complete.
  • Page 144 SuperServer F619P2/3-FT User's Manual Appendix E BSMI Safety Warnings 限用物質含有情況標示聲明書 Declaration of the Presence Condition of the Restricted Substances Marking...
  • Page 145 Appendix E: Traditional Chinese Version of Safety Warnings 限 限 用 用 物 物 質 質 含 含 有 有 情 情 況 況 標 標 示 示 聲 聲 明 明 書 書 Declaration of the Presence Condition of the Restricted Substances Marking 設備名稱：伺服器/ Server Equipment name 型號（型式）：F418-22...
  • Page 146 SuperServer F619P2/3-FT User's Manual * 輸入額定 : 輸入：100-127 V,12-9.5 A,60-50 HZ; 200-240 V, 10-9.8 A,60-50 HZ * 使用者不能任意拆除或替換內部配備 * 報驗義務人之姓名或名稱: 美超微電腦股份有限公司 美超微電腦股份有限公司 * 報驗義務人之地址: 新北市中和區建一路150號3樓 * 報驗義務人之地址: 新北市中和區建一路 150 號 3 樓...

This manual is also suitable for:

Fattwin f619p3-ft

Table of Contents
