longer than "HARDOFF" (Operating System gets frozen, etc), power will be
shut down hard, turning off all power rails. During the HARDOFF procedure,
the battery levels will be constantly monitored to prevent deep discharge
situations.
5) M4-ATX-HV will go to step 1, if ignition is tuned ON again.
NOTE. When all dip switches are off, M4-ATX-HV acts as a regular power supply.
M4-ATX-HV will also send a gratuitous "ON" pulse (to the ON/OFF motherboard
pins, should you have a wire harness connected to it) when power is applied for the
first time. Do not connect the on/off switch if you don't want your PC to be started
automatically.

M4-ATX-HV Characteristics

Minimum Input Operating. voltage
Maximum input Operating voltage
Deep-Discharge shutdown threshold
Input current limit (fuse protected)
Max Output Power
Deep Sleep Current Consumption.
Storage and operating temperature
MTBF
Efficiency (Input 10-16V)
Input connectors
Output Connector
*Unit shuts down when internal temperature sensor indicates > 85C. This value can be changed with
software.

Maximum Power Characteristics

Output Rail
5V
3.3V
5VSB
-12V
12V
When operating at <8V or >28V or extreme temperatures, de-rate by 30-50%, ventilation might be
required. When operating at constant 160watts or more forced ventilation is required.
M4-ATX-HV User Guide
Current (Max)
12A
12A
1.5A
0.15A
10A (see below)
6V
34V (clamping occurs at 36-38V range)
11.2V
Mini-blade 25A
220 Watts / 275 watts peak
< 1.6mA
-40 to +125 degrees Celsius (storage), -
40 – 65C (operating)
200,000 Hrs
>94%, all rails combined, 50% load.
M4 screw terminal
ATX Power 24 pin (Molex P/N 39-01-
2200)
Current Peak
(<30 seconds)
15A
15A
2A
0.2A
12A (see below)
Embedded PC Solutions
Regulation
1.5%
1.5%
1.5%
10%
2%
