Plug In And Turn On; Install Ink Cartridges - Epson Stylus Photo RX500 Start Here Manual

4
Unlock the Printer
1
Lift up the entire scanner unit using the
handles on the side.
2
Remove the orange plastic
print head holder.
Caution: You must remove
the orange print head
holder or the RX500
won't work.
3
Store the orange print head
holder in the storage area.
4
Close the scanner unit.
5

Plug In and Turn On

1
Plug the RX500 into a grounded electrical outlet.
Do not connect a USB cable yet.
2
Press and hold the On
button until the green Mode
lights begin to flash.
6

Install Ink Cartridges

1
Press the Color button on the front of the
RX500. The print head moves into
loading position.
2
Lift up the entire scanner unit.
3
Open the cartridge cover by pulling it
toward you.
4
Remove the ink cartridges from their packages.
Caution: You must install all the cartridges and leave them installed
for all types of printing. To avoid damaging the RX500, never move the
print head by hand.
5
Lower each cartridge into the holder marked with the
corresponding color.
On button
continue
