The symbols below are used in this document to alert the operating/service personnel to an area of potential hazard or to note
something of importance. The danger, warning, and caution text identifies the hazard type, location, and avoidance.
Indicates an imminently hazardous situation which, if not avoided, will result in death or serious
injury.
Indicates a potentially hazardous situation or practice which, if not avoided, will result in death
or serious injury.
Indicates a potentially hazardous situation or practice which, if not avoided, will result in dam-
age to equipment and/or minor injury.
NOTE:
Indicates an operating procedure, practice, etc., or portion thereof which is essential to highlight.

PREFACE

INTRODUCTION

This manual has been prepared to acquaint the owner and
service personnel with the INSTALLATION, OPERATION,
and MAINTENANCE procedures as recommended by
Johnson Controls-Frick for the Frick Vyper
Drive unit.
For information about the functions of the Quantum
Control panel, communications, specifications, and wiring
diagrams, please see the applicable and most current Frick
documentation.
It is most important that these units be properly applied to
an adequately controlled refrigeration system. Consult an
author ized Frick repre sentative for expert guidance in this
determination.
Proper performance and continued satisfaction with the Frick
Vyper is dependent upon the following:
™
• Correct unit installation
• Correct utilization and operation of the unit in
accordance with the procedures detailed in Frick
manuals.
• Regular and proper unit maintenance.
VYPER
™
INSTALLATION - OPERATION - MAINTENANCE
iMPorTanT!
reaD before ProceeDing!
safeTY PrecauTion DefiniTions
Variable Speed
™
VARIABLE SPEED DRIVE
To ensure correct installation and application, the equipment
must be properly selected and connected to a properly de-
signed and installed system. The engineering plans, piping
layouts, etc. must be detailed in accordance with the best
practices and local codes, such as those outlined in ASHRAE
literature.
The Frick Vyper
trol equipment. All safety precautions consistent with opera-
tion of high current and voltage electrical equipment should
be strictly enforced.
LX
™
Immediately upon arrival of the unit, examine all crates,
boxes, and exposed compressor and component surfaces
for damage. Unpack all items and check against shipping
lists for any possible shortage. Examine all items for damage
from unit transit.

TRANSIT DAMAGE CLAIMS

All claims must be made by consignee. This is an ICC re-
quirement. Request immediate inspec tion by the agent of the
carrier and be sure the proper claim forms are executed.
Contact the Sales Administration Depart ment in Waynesboro,
PA to report dam age or shortage claims. NOTE: Damage
must be photographically documented.
is a sophisticated piece of electronic con-
™

JOB INSPECTION
