Contec COM-4CX-USB First Step Manual

Thank you for purchasing the CONTEC product. This product is a serial I/O unit corresponding to the
USB for performing serial communication with external devices.
Check, with the following list, that your package is complete. If you discover damaged or missing
items, contact your retailer.
Product Configuration List
- USB Unit ...1
- Disk [COM Setup Disk] ...1
- USB Cable (1.8m) ...1
- USB Cable attachment ...1
- Ferrite core (small size) *1 ...1
- External toothed lock screw (M4 x 5) *2...1
- AC adapter *3 ...1
- 5-pin connector for RS-422A/485 communication *3 ...4
*1 It is attached to COM-4CX-USB.
*2 It is attached to COM-4CN-USB.
*3 It is attached to COM-4PDHN-USB.
About an User's Guide
The User's Guide of this product is offered as the PDF file in the bundled Disk.
information such as a setup of hardware, connection (signal arrangement of a connector) with external
devices and product specification is indicated, please refer to it if needed.
It is possible to display a "User's
Guide " from the automatic
starting screen of the bundled
Disk.
File storing place:
\UsersGuide
Adobe Reader is required in
order to read a description.
The reference place of the installation method
Information
Installation by Windows
1
Serial I/O Unit for USB
First step guide
CONTEC CO., LTD.
Help files containing the methods to follow in performing installations
on different Windows operating systems are included on the bundled
disk, so refer to the files in the following folder.
\Usb\COM4CXUSB\ InstDoc
- Clamps for prevention of USB cable *1...1
- First step guide (this booklet) ...1
- 3-pin Power connector *1*3...1
- Warranty Certificate...1
- Serial number label ...1
- Rubber feet *2*3...4
- AC cable (1.8m) *3 ...1
Reference place
With it, since
