CONPROSYS
Digital Input/Output Module
CPS-MC341-DS1 -111
Hardware Manual
CONTEC CO.,LTD.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPS-MC341-DS1 -111 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Contec CPS-MC341-DS1 -111

Summary of Contents for Contec CPS-MC341-DS1 -111

  • Page 1 CONPROSYS Digital Input/Output Module CPS-MC341-DS1 -111 Hardware Manual CONTEC CO.,LTD.
  • Page 2 To the customer Before using the product, visit our website to check the firmware version and be certain to use the latest one.
  • Page 3 (Digital) *This product was authenticates the standard with a power supply of our recommended. Accordingly, when you use other than power supply of our recommended, doing so may become non-standard. Information about recommended power supply, see the Contec’s website. CPS-MC341-DS1-111 Hardware Manual...
  • Page 4 No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CONTEC CO., LTD. makes no commitment to update or keep current the information contained in this document.

  • Page 5: Table Of Contents

    Index Check Your Package ............................ i Index ................................iii Before Using the Product About the Unit ............................. 1 Features ..............................1 How to use ............................2 Customer Support ............................3 Limited Two-Years Warranty ........................3 Safety Precautions ............................4 Safety Information ..........................4 Handling Precautions ..........................
  • Page 6 DIP Switch (SW1, SW2) ........................28 LAN Port (LAN A, LAN B) ......................29 Isolation Digital Output Connector (DO0, DO1, DO2, DO3 DO4, DO5, DO6, DO7) ....30 Isolation Digital Input Connector (DI0, DI1, DI2, DI3 DI4, DI5, DI6, DI7)....... 31 Isolated RS-422A/485 Connector (COM A) ...................

  • Page 7: Before Using The Product

    1 Before Using the Product 1. Before Using the Product This chapter provides information you should know before using the product. About the Unit The product is an IoT/M2M controller with isolated RS-422A/485, isolated digital input, isolated digital output, Ethernet Hub. It is equipped with ARM®Cortex®-A8 processor (600MHz) and onboard 512MB DDR3-SDRAM.
  • Page 8 1 Before Using the Product - A wide range of power supplies (12 to 24VDC) supported As the product supports a wide range of power (10.8 to 31.2VDC), it can be used in a variety of power environments. Power connector is equipped with FG terminal. - Adopted two pieces terminal and DIN rail installation It is possible to remove terminal connector without screwdriver in a short time even if this product is Because of DIN rail Installation, it is easy to exchange the product.

  • Page 9: Customer Support

    You can download updated driver software and differential files as well as sample programs available in several languages. Note! For product information Contact your retailer if you have any technical question about a CONTEC product or need its price, delivery time, or estimate information. Limited Two-Years Warranty CONTEC products are warranted by CONTEC CO., LTD.

  • Page 10: Safety Precautions

    - Do not use or store this product in the presence of chemicals. - CONTEC reserves the right to refuse to service a product modified by the user. - In the event of failure or abnormality (foul smells or excessive heat generation), unplug the power cord immediately and contact your retailer.
  • Page 11 - To avoid electric shock, please do not touch the system with a wet hand. - The specification of this product is subject to change without notice for enhancement and quality improvement. Even when using this product continuously, be sure to read the manual of CONTEC’s website and understand the contents.
  • Page 12 1 Before Using the Product CPS-MC341-DS1-111 Hardware Manual...

  • Page 13: Setup

    2 Setup 2. Setup Before using the product for the First Time Follow the next steps to set up this product. STEP1 Switch Setup STEP2 Installation procedure In accordance with Installation procedure of this product, please install correctly it. STEP3 Cable connection STEP4 Turn on the power.
  • Page 14 2 Setup Setting the Terminator When inserting a terminator, use the terminator setting switch. Set the terminator depending on the external device to which to connect this product. This product contains a 100Ω resistor as a terminator. SW-bit one is for TX. To set the terminal to a resistor other than 100Ω, set the terminator setting switch to OFF and insert an external terminator.

  • Page 15: Rs-422A/485 Full Duplex Setup

    2 Setup RS-422A/485 Full duplex setup Table 2.2. RS-422A/485 Switch setup for full duplex Data Full duplex transmission mode By the RTS signal of this product be become activate, CTS signal becomes active. Setup method Setting the Terminator When inserting a terminator, use the terminator setting switch. Set the terminator depending on the external device to which to connect this product.

  • Page 16: Installation

    2 Setup Installation Mounting on a DIN Rail Mounting procedure (1) Push the fixing hook up using a slotted screwdriver to make it unlockable. Figure2.3. Mounting on a DIN Rail < 1 / 3 > (2) Hook the product from the upper part of the DIN rail, and press the lower part on to the DIN rail. Figure2.3.
  • Page 17 2 Setup Removal procedure (1) Pull down the fixing hook of the unit to unlock it. Figure 2.4. Removing the unit from the DIN Rail < 1 / 3 > (2) With the fixing hook unlocked, pull the lower part of this unit toward you. Figure 2.4.

  • Page 18: Wall Installation

    2 Setup Wall Installation Φ To mount the product on the wall, purchase the commercially available screw (fitting for 3.5) separately. Figure 2.5. Wall Installation CPS-MC341-DS1-111 Hardware Manual...

  • Page 19: Installation Conditions

    2 Setup Installation Conditions Installation orientation This product can be installed as the following installation orientation. Avoid other orientation it might not adequately dissipate heat. In addition, take appropriate measures so that the ambient temperature falls within the range of installation environment conditions, such as keeping the system unit well- ventilated and sufficiently spaced its surroundings DIN rail fixation °...
  • Page 20 2 Setup Installed angle which is recommended ° Installed angle of this product which is recommended is 0 . Except for that, the temperature specification of this product might not be filled. Ambient temperature In this product, the ambient temperature is decided from the multiple measurement points which is to a distance of 50mm from case.
  • Page 21 2 Setup Spacing between the system unit and any surrounding objects (reference) Figure 2.8. Spacing between the system unit and any surrounding objects (reference) CPS-MC341-DS1-111 Hardware Manual...

  • Page 22: How To Set And Remove The Sd Cover

    2 Setup How to set and remove the SD cover In the case of using the SD slot, it is need to set and remove the SD cover wihich is on upside the product - How to set (1) Insert the catch of the SD cover into the opening at tip of the arrow 1 (2) Slide the SD cover in the direction of the arrow 2.

  • Page 23: Cable Connection

    - Build up time time of up to a voltage 12V: within 2ms - 30ms Recommended power supply is CPS-PWD-15AW12-01(CONTEC). CAUTION If the maximum output current of the external power supply can not afford compared with the...

  • Page 24: Rs-422A/485 (Com A)

    2 Setup RS-422A/485 (COM A) RS-422A/485 Cable - Cable: Twisted pair cable with the shield - Cable Diameter: AWG28-16(0.08mm -1.25mm - Cable Length Affected by the communication speed (baud rate) between this product and the external device. Please do not exceed the cable length indicated in the following table. Communication abnormality may occur even if less than length which is shown on the following table because attenuation may be different by the material of the cable.
  • Page 25 2 Setup - Half Duplex Half duplex need three or more pairs of twisted-pair. One set is signal lines, other free line is for the signal ground (SG). Please connect TX + and TX- so that it becomes a pair of twisted pair wire. Product External device TX＋...
  • Page 26 2 Setup - Wiring Specifications Please connect RS-422A/485 according to the specifications of the external device. Communication with the external Communication with the external device of Half Duplex. device of Full Duplex. TX+ TX- RX+ RX - TX+ TX- RX+ RX- RX+ RX- TX+ TX- －...

  • Page 27: Digital Input (Di)

    2 Setup Digital Input (DI) Input equivalent circuit of digital / counter input interface unit is shown in Figure 2.12.DI connects to a device which can be current-driven such as switch or transistor output device. Input the ON / OFF state of a device which can be current-driven as digital value.

  • Page 28: Digital Output (Do)

    2 Setup Digital output (DO) DO connect to the device controlled by the current drive, such as control a relay or LED. The connection requires an external power supply to supply current. ON / OFF of the device to be controlled by the current drive is controlled by digital value. The rated of output current is up to 100mA per point.

  • Page 29: Software Setup

    2 Setup Connection to the LED Output pin (+) External LED 5.1kΩ power supply Minus Common 12 - 24 VDC When “1” is output to a relevant bit, the corresponding LED comes on. When “0” is output to the bit, in contrast, the LED gose out. Figure 2.17.
  • Page 30 2 Setup CPS-MC341-DS1-111 Hardware Manual...

  • Page 31: Component Name And Function

    3 Component Name and Function 3. Component Name and Function Component Name Component name of the products is shown in Figure 3.1. ① ② ③ ④ 12-24VDC COM A CPS-MC341-DS1 ⑥ ⑤ Half Full Half Full ⑦ Isolated RS-422A/485 LAN A LAN B COM A Speed...

  • Page 32: Component Function

    3 Component Name and Function Component Function Power Connector (12-24VDC) It uses the attached connector. Connector type: PHOENIX CONTACT MC 1,5/3-ST-3,5 (Equivalent product) Table 3.1. Power Connector 1 2 3 Pin No. Signal name V-(GND) V+(12-24VDC) Debug Connector Please do not use it. SD slot Insert the SD card and use to store such data.

  • Page 33: Led Indicator

    3 Component Name and Function LED Indicator COM A ST1 ST2 DO7 DO6 DO5 DO4 DO3 DO2 DO1 DO0 Figure 3.2. LED Indicator Table 3.2. LED Indicator (top) Meaning Operation Be supplied Power. PWR(Green) Be not supplied Power. Blinking It blinks at the SD access. SD(Yellow) It put the lights out at the not SD access.

  • Page 34: Dip Switch (Sw1, Sw2)

    3 Component Name and Function DIP Switch (SW1, SW2) DIP switch for system setup and RS-422A/485 setup of COM A. Table 3.3. DIP Switch Meaning SW NO. Operation System Reservation : Please be OFF always. System Reservation : Please be OFF always. System Reservation : Please be OFF always.
  • Page 35 3 Component Name and Function LAN Port (LAN A, LAN B) This product has 2 port of Ethernet. Because the LAN port of this product is set in HUB mode, it is recognized as one port from OS. -Network type : 100BASE-TX/10BASE-T -Transmission speed : 100M/10M bps...

  • Page 36: Isolation Digital Output Connector (Do0, Do1, Do2, Do3 Do4, Do5, Do6, Do7)

    3 Component Name and Function Isolation Digital Output Connector (DO0, DO1, DO2, DO3 DO4, DO5, DO6, DO7) This product has 8 channel of digital output. It uses the attached connector. Connector type: PTR MESSTECHNIK AK1550/10-3.5-GREEN (Equivalent product) Table 3.6. Digital Output Connector 2 3 4 5 6 7 8 Pin No.

  • Page 37: Isolation Digital Input Connector (Di0, Di1, Di2, Di3 Di4, Di5, Di6, Di7)

    3 Component Name and Function Isolation Digital Input Connector (DI0, DI1, DI2, DI3 DI4, DI5, DI6, DI7) This product has 8 channel of digital Input. It uses the attached connector. Connector type: PTR MESSTECHNIK AK1550/10-3.5-GREEN (Equivalent product) Table 3.7. Digital Input Connector 1 2 3 4 5 6 7 8 Pin No.
  • Page 38 3 Component Name and Function CPS-MC341-DS1-111 Hardware Manual...

  • Page 39: System Reference

    4 System Reference 4. System Reference Specification Table 4.1. Function specification Item CPS-MC341-DS1-111 ARM Cortex-A8 600MHz Memory On Board 512MB DDR3 SDRAM On-Board 32MB NOR Flash for OS Transmission standard 10BASE-T/100BASE-TX The number of channels Connector RJ-45 Connector Speed (Yellow), Link / Act (Green) Transmission scheme Asynchronous Serial Transmission(Full Duplex/Half Duplex) The number of channels...
  • Page 40 4 System Reference Item CPS-MC341-DS1-111 RTC equipped (Not equipped battery) Rated input voltage 12 - 24VDC input voltage range 10.8 - 30VDC power consumption 12V 0.7A (Max.), 24V 0.4A (Max.) Power supply *2 Connector 2 piece 3.5mm pitch 3pin Terminal (V+, V-, FG) Applicable wire AWG24 - 16 Surge protection element...

  • Page 41: Power Requirements

    (SPD) at rising the power supply voltage. - If you want to restart the power, please provided the power OFF time for more than 1 second. - Instantaneous voltage drop allowed time at the combination of the CPS-PWD-15AW12-01 (CONTEC) will be 20ms or less.

  • Page 42: External Dimensions (Cps-Mc341-Ds1-111)

    4 System Reference External dimensions (CPS-MC341-DS1-111) 12-24VDC COM A DO7 DO6 DO5 DO4 DO3 DO2 DO1 DO0 CPS-MC341-DS1 Half Full Half Full Isolated RS-422A/485 LAN A LAN B COM A Speed Link/Act Speed Link/Act MCOM MCOM （154） Φ3.5 [mm] Figure 4.1. External dimensions CPS-MC341-DS1-111 Hardware Manual...

  • Page 43: List Of Option

    5 List of Option 5. List of Option Power supply - CPS-PWD-15AW12-01 : Power supply 15[w] SD card - SD-2GB-B : SD card 2GB *Information about the option products, see the Contec’s website. CPS-MC341-DS1-111 Hardware Manual...
  • Page 44 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan Japanese http://www.contec.co.jp/ English http://www.contec.com/ Chinese http://www.contec.com.cn/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. [09252015] [09252015] Management No. NA04457 Parts No.
