Reference Manual
(Hardware)
Measurement Module
CPS-MM-LC
CONTENTS
Introduction .................................................................. 4
Safety Precautions .................................................... 10
Product Nomenclature and Function................ 16
Installation ................................................................... 20
Appendix ...................................................................... 35
Optional Products .................................................... 41
Customer Support and Inquiry ........................... 43
Index .............................................................................. 45
Advertisement
Table of Contents
Related Manuals for Contec CONPROSYS CPS-MM-LC
Summary of Contents for Contec CONPROSYS CPS-MM-LC
- Page 1 Reference Manual (Hardware) Measurement Module CPS-MM-LC CONTENTS Introduction ..............4 Safety Precautions ............ 10 Product Nomenclature and Function....16 Installation ..............20 Appendix ..............35 Optional Products ............ 41 Customer Support and Inquiry ......43 Index ................45...
-
Page 2: Table Of Contents
Table of Contents Introduction ............... 4 1. Related Manuals ..............................5 2. Check the Firmware Version ..........................6 3. About the Product ..............................7 4. Features ..................................8 1. Hardware features............................8 5. Product Configuration List ..........................9 Safety Precautions ............10 1. - Page 3 Table of Contents 1. Optional Products ............................... 42 Customer Support and Inquiry ........43 1. Services ..................................44 Index .................. 45 — 3 —...
-
Page 4: Introduction
Introduction This section provides necessary information of the product such as the outline, bundled items and manuals before actual use. — 4 —... -
Page 5: Related Manuals
(Printed matter) package. and describes the precautions. Setup Manual Download from Read this when setting up the This describes the required items for the Contec product. setup and configuration procedure. website (PDF) Reference Manual Download from Read this when operating the... -
Page 6: Check The Firmware Version
Before start using the product, visit our website to check the firmware version and update to the latest one if necessary. Updating firmware to the latest version will resolve troubles and stabilize the operation. https://www.contec.com/download/ Download *Refer to the "Reference Manual (Software)" for the details of the firmware updating. -
Page 7: About The Product
— — Introduction CPS- MM-LC Reference Manual (Hardware) 3. About the Product This product is a module to monitor leakage current of the equipment in a live state that is driven by three-phase alternating current power. Set this module to operate along with the CONPROSYS series configurable type CPU module controller. -
Page 8: Features
— — Introduction CPS- MM-LC Reference Manual (Hardware) 4. Features 1. Hardware features Find isolation deterioration in motor This product finds isolation deterioration of the three-phase induction motor by calculating isolation resistance from the measured applied voltage as well as ground fault current to the three-phase induction motor (three-phase motor). With the Modes-IO measurement method, isolation resistance in a live state can be accurately measured, and it is applicable to detect isolation deterioration of the three-phase induction motor. -
Page 9: Product Configuration List
ZCT Unit…1 *This product is verified in conformity with our recommended power supply. In case you use other power supplies, thus, it may not be able to fulfil certification requirements. Please see the Contec website regarding power supply recommendation (https://www.contec.com/). -
Page 10: Safety Precautions
Safety Precautions Understand the following definitions and precautions to use the product safely. Never fail to read them before using the product. — 10 —... -
Page 11: Safety Information
— — Safety Precautions CPS- MM-LC Reference Manual (Hardware) 1. Safety Information This document provides safety information using the following symbols to prevent accidents resulting in injury or death and the destruction of equipment and resources. Understand the meanings of these labels to operate the equipment safely. DANGER indicates an imminently hazardous situation which, if not DANGER avoided, will result in death or serious injury. -
Page 12: Handling Precautions
— — Safety Precautions CPS- MM-LC Reference Manual (Hardware) 2. Handling Precautions DANGER Do not use the product in locations exposed to a flammable or corrosive gas. It may cause explosion, fire, electrical shock, or malfunction. Do not allow the device to come into contact with foreign substances (metal particles, ... - Page 13 When removing connectors or cables, always unplug the power cables and confirm the LEDs are turned off. Do not modify the product. CONTEC will bear no responsibility for any problems, etc., resulting from modifying the product. In the event of failure or abnormality (foul smells or excessive heat generation), unplug the ...
- Page 14 quality improvement. Even when using the product continuously, be sure to read the manual in the CONTEC’s website and understand the contents. When the product is used in a place that is affected by overcurrent or overvoltage (lightning ...
-
Page 15: Display Marking
Do not disassemble the ZCT unit, otherwise troubles may be caused. Regardless of the foregoing statements, CONTEC is not liable for any damages whatsoever (Including damages for loss of business profits) arising out of the use or inability to use this CONTEC product or the information contained herein. -
Page 16: Product Nomenclature And Function
Product Nomenclature and Function This section describes product component names and their functions, pin assignment of each connector. — 16 —... -
Page 17: Nomenclature Of Product Components
— — Product Nomenclature and Function CPS- MM-LC Reference Manual (Hardware) 1. Nomenclature of Product Components Component names of the product are shown in the figure below. Ⅲ Ⅱ Name Function Stack Bus Used for power supply and communication with the configurable type module. LED Indicator This indicates status of the product. -
Page 18: Description Of Product Components
— — Product Nomenclature and Function CPS- MM-LC Reference Manual (Hardware) 2. Description of Product Components Components such as connectors, switches are described. 1. Stack Bus It is used for power supply and communication to the configurable type module. CAUTION Never set or remove the product while power is active. -
Page 19: Zct Connection
— — Product Nomenclature and Function CPS- MM-LC Reference Manual (Hardware) 3. ZCT Connection Measure the zero-phase current flowing into equipment or three-phase induction motor (three- phase motor). Connect the ZCT unit included in the package. Connector type: J.S.T. Mfg. Co.,Ltd S11B-ZESK-2D (or equivalent) CURRENT INPUT 4. -
Page 20: Installation
Installation This section describes how to mount the product on a DIN rail, and to connect to an external device with a cable. — 20 —... -
Page 21: Install The Product
— — Installation CPS- MM-LC Reference Manual (Hardware) 1. Install the Product 1. Installation Conditions Installation Orientation Install the product in the orientations shown below (0 °C). Other orientations may cause problems such as malfunctions due to inadequate heat dissipation. Orientation for DIN rail Mounting —... - Page 22 — — Installation CPS- MM-LC Reference Manual (Hardware) Ambient Temperature The ambient temperature is decided from the multiple measurement points which are a 50mm- distance from the product. During the operation, adjust the air current to make certain that the temperatures measured in the points stay within the specified temperature.
-
Page 23: Setting The Configurable Type Module
— — Installation CPS- MM-LC Reference Manual (Hardware) 2. Setting the Configurable Type Module CAUTION If the modules set side-by side are disconnected during the operation, it can cause damage to the product. Set the controller on DIN rail in order to avoid the trouble. Always confirm the PWR-LED is turned off before setting or removing the modules ... - Page 24 — — Installation CPS- MM-LC Reference Manual (Hardware) Engage the side rail of the setting module to the side rail of the controller (or another module) that is already mounted. When the rails fit, slide the setting module all the way toward the DIN rail. Module side rail 山路を登りながら...
- Page 25 — — Installation CPS- MM-LC Reference Manual (Hardware) How to Remove First, slide the attached end cover from the configurable type module to remove it. Unlock the hooks of the module. If the hooks are stuck, use a slotted screwdriver to unlock. —...
- Page 26 — — Installation CPS- MM-LC Reference Manual (Hardware) Unlock the hook with a slotted screwdriver There are two ways to unlock the hook using a slotted screwdriver. Unlock it by one of the following. Using the screwdriver as leverage Insert a slotted screwdriver (the point should be smaller than 4.5mm) into a hole.
- Page 27 — — Installation CPS- MM-LC Reference Manual (Hardware) With the hooks unlocked, pull the module toward you. Put back the end cover to the controller. — 27 —...
- Page 28 — — Installation CPS- MM-LC Reference Manual (Hardware) How to set the ZCT unit ZCT unit Motor side Secure the unit with screws and the likes Power side Use screws or the likes to secure the ZCT unit. Recommended screws: M4 captive washer (SW+JIS flatW) binding head screw, Length=14 mm or longer Recommended tightening torque: 1.2-1.5[N·m] *Decide the most appropriate tightening torque that suits the actual conditions.
-
Page 29: Connecting To An External Device
— — Installation CPS- MM-LC Reference Manual (Hardware) 2. Connecting to an External Device Use the supplied connector plug to connect the product to an external device. The following example describes how to make the connecting cable with a 4-pin connector. Connection cable The supplied External device... -
Page 30: Cable Connection
— — Installation CPS- MM-LC Reference Manual (Hardware) 3. Cable Connection 1. Measure all the equipment (power mode) By measuring the voltage of the power and the zero-phase current in the control panel, the isolation resistance of all the equipment including the connecting inverters can be measured. ... - Page 31 — — Installation CPS- MM-LC Reference Manual (Hardware) Connecting example with three-phase Wye (3-wire/4-wire, three-phase solidly-grounded neutral system) When connecting to the power of three-phase Wye cable, isolation resistance of all equipment including inverters can be measured. Connect phases (L1, L2, and L3), as well as the ground terminal with the voltage input terminal (L1/T1, L2/T2, L3/T3, and REF) respectively.
- Page 32 — — Installation CPS- MM-LC Reference Manual (Hardware) CAUTION The motor should be operating at a constant speed while measuring. Measuring may not start if the cable is unconnected. If the connecting cable is affected by the noise, measuring may not be done accurately. Place ...
-
Page 33: Inverter Output Part Measurement (Inverter Mode)
— — Installation CPS- MM-LC Reference Manual (Hardware) 2. Inverter output part measurement (inverter mode) By measuring the voltage and the zero-phase current of the output part in the inverter, the isolation resistance of the connected three-phase induction motor can be measured. ... - Page 34 — — Installation CPS- MM-LC Reference Manual (Hardware) Connecting example with inverter powered by three-phase Wye (3-wire/4-wire, three-phase solidly-grounded neutral system) When connecting to the inverter output powered by three-phase Wye cable, isolation resistance of three-phase induction motor that is connected to the inverter can be measured. Connect phases (T1, T2, and T3) of inverter output, as well as the ground terminal with the voltage input terminal (L1/T1, L2/T2, L3/T3, and REF) respectively.
-
Page 35: Appendix
Appendix This section lists the specifications and the physical dimensions of the product, and the details of model name. — 35 —... -
Page 36: Specifications
— — Appendix CPS- MM-LC Reference Manual (Hardware) 1. Specifications 1. Specifications Function Specifications <Product> Item CPS-MM-LC Measurement function Leakage current measurement, Isolation resistance measurement Measurement method *1 Modes-IO The number of measurement channels Applied motor type Three-phase induction motor (three-phase motor) Measurement Three-phase Delta (3-wire, three-phase corner-grounded Measurement for the... - Page 37 — — Appendix CPS- MM-LC Reference Manual (Hardware) Item CPS-MM-LC Installation environment Applicable pollution degree 2 *1 The patent theory of TANASHIN DENKI CO.,LTD. is applied. *2 Use in the circuit not exceed CAT III 300V or CAT II 600 V. *3 Value is when adjusted with standard jig *4 Accuracy cannot be guaranteed for Isolation resistance value of 10MΩ...
- Page 38 — — Appendix CPS- MM-LC Reference Manual (Hardware) Installation Environment Requirements Item CPS-MM-LC Operating ambient temperature -20 - +60°C Operating ambient humidity 10 - 90%RH (No condensation) Non-operating ambient -20 - +60°C temperature Non-operating ambient humidity 10 - 90%RH (No condensation) Floating dust particles Not to be excessive Corrosive gases...
-
Page 39: Physical Dimensions
— — Appendix CPS- MM-LC Reference Manual (Hardware) 2. Physical Dimensions 1. Product 25.2 94.7 Ⅲ Ⅱ [mm] 2. ZCT unit 74.5 37.2 [mm] — 39 —... -
Page 40: The Details Of Model Name
— — Appendix CPS- MM-LC Reference Manual (Hardware) 3. The Details of Model Name Details of the model name are described below. CPS - MM - LC CONPROSYS Series Item Description Model MM Measurement Module Function Leakage current — 40 —... -
Page 41: Optional Products
Optional Products This section lists optional items that can be used along with the product. — 41 —... -
Page 42: Optional Products
Fitting power supply 90W supply (Input: 100 - 240VAC, Output: 24VDC 3.8 A) CPS-PWD-30AW24-01 Fitting power supply 30W (Input: 100 - 240VAC, Output: 24VDC 1.3 A) Visit the Contec website for the latest optional products. https://www.contec.com/ Website — 42 —... -
Page 43: Customer Support And Inquiry
Customer Support and Inquiry CONTEC provides the following support services for you to use CONTEC products more efficiently and comfortably. — 43 —... -
Page 44: Services
— — Customer Support and Inquiry CPS- MM-LC Reference Manual (Hardware) 1. Services CONTEC offers the useful information including product manuals that can be downloaded through the Contec website. Download https://www.contec.com/download/ You can download updated driver software, firmware, and differential manuals in several languages. -
Page 45: Index
Index — 45 —... - Page 46 — — Index CPS- MM-LC Reference Manual (Hardware) Revision History MONTH YEAR Summary of Changes September 2018 The First Edition — 46 —...
- Page 47 3-9-31, Himesato, Nishiyodogawa-ku, Osaka 555-0025, Japan https://www.contec.com/ No part of this document may be copied or reproduced in any form by any means without prior written consent of CONTEC CO., LTD. CPS- MM-LC Reference Manual (Hardware) NA06207 (LYWA432) 12052018_rev2 [09072018]...
