Rev. 01-07/21 INDICE: 1. INTRODUZIONE p. 3 2. ISTRUZIONI DI SICUREZZA p. 4 3. APERTURA CONFEZIONE E CONTROLLO p. 6 4. INSTALLAZIONE ED ACCENSIONE p. 7 5. ISTRUZIONI PER L'USO p. 9 6. MANUTENZIONE p. 14 7. SPECIFICHE TECNICHE p. 14 INDEX: 1.
1. INTRODUZIONE Grazie per avere scelto un nostro prodotto! Vi preghiamo di fare riferimento alle istruzioni e alle avvertenze contenute nel presente manuale per l’utilizzo del dispositivo e di conservarlo per future consultazioni. Il presente manuale contiene informazioni riguardanti l’installazione e l’utilizzo del dispositivo. Le informazioni contenute in questo documento sono state attentamente redatte e controllate.
2. ISTRUZIONI DI SICUREZZA Attenzione! Questo prodotto non è adatto ad un uso domestico. Leggere il presente manuale prima di installare e dare corrente all’apparecchiatura, seguire le precauzioni di sicurezza elencate di seguito ed osservare tutti gli avvertimenti indicati nel presente manuale e stampati sull’apparecchiatura.
Page 5
CLASSE DI PROTEZIONE IP20 Il dispositivo è protetto contro la penetrazione di corpi solidi di dimensioni superiori a 12 mm (0.47”) di diametro (prima cifra 2), ma non contro la caduta di gocce d’acqua, pioggia, schizzi o getti d’acqua (seconda cifra 0). Usare solo in ambienti asciutti.
3. APERTURA DELLA CONFEZIONE E CONTROLLO Aprire con cura la confezione, verificare il contenuto e assicurarsi che tutte le parti siano presenti e siano in buone condizioni. Nel caso in cui alcune parti non siano presenti o siano danneggiate, contattare immediatamente il proprio fornitore e conservare l’imballaggio per la verifica.
4. - INSTALLAZIONE ED ACCENSIONE 4.1 - INSTALLAZIONE PRODOTTO - Non scuotere l'apparecchio. Evitare l'utilizzo di forza eccessiva durante le operazioni di installazione o fissaggio dell'unità. - L'unità può essere installata a pavimento, a soffitto o su truss. ATTENZIONE! E'OBBLIGATORIO il montaggio della fune di sicurezza (PLH232 –...
Page 8
4.3 - COLLEGAMENTO ALLA CATENA DMX Utilizzare un cavo conforme alle specifiche EIA RS-485: bipolare intrecciato, schermato, 120Ohm di impedenza caratteristica e bassa capacità (SAGITTER SG DMX3 – SG DMX5). Non utilizzare cavo microfonico o altro cavo con caratteristiche diverse da quelle specificate.
- ISTRUZIONI PER L'UTILIZZO 5.1 - MAPPA DEL MENU' MENU MENU 2 MENU 3 DESCRIZIONE ADDRESS 001 – 512 Indirizzo DMX 3–CHANNEL Modalità 3 canali CONTROL 4–CHANNEL Modalità 4 canali MODE 6–CHANNEL Modalità 6 canali 10–CHANNEL Modalità 10 canali LINEAR Curva dimmer Linear DIMMER SQUARE LAW...
Page 10
Carica le impostazioni personalizzate LOAD dalla memoria 3 CUSTOM 3 Salva le impostazioni personalizzate SAVE nella memoria 3 CHANNEL [000 – 255] Controllo manuale dei singoli canali CANCEL RESET MANUAL Reset proiettore CANCEL UPLOAD Reset allo stato di fabbrica BEAM STATIC Test beam led TEST LED TEST...
6. - MANUTENZIONE Per garantire ottime prestazioni, l’apparecchio deve essere pulito frequentemente. Scollegare l’apparecchio della corrente e lasciarlo raffreddare per almeno 35 minuti onde evitare il rischio di bruciature. Utilizzare un’aspirapolvere o compressore e una spazzola morbida o un panno per lenti per rimuovere la polvere depositata.
1. - INTRODUCTION Thank You for choosing one of Our products! Please refer to the instructions and warnings contained in this user manual, please retain it for future reference. This manual contains information about the installation and use of the device. The information contained in this publication has been carefully prepared and checked.
2. - SAFETY INSTRUCTIONS Caution! This product is not suitable for household illumination. Please read this manual before installing and applying power to the equipment, follow the safety precautions listed below and observe all warnings in this manual and printed on. Please contact a PROEL distributor for assistance with any questions about how to activate the equipment safely.
Page 17
IP20 PROTECTION RATING The device is protected against the penetration of solid bodies larger than 12 mm (0,47 ") in diameter (first digit 2), but not against dripping water, rain, splashes or jets of water (second digit 0). Use only in dry areas. Inside use only. Do not expose the equipment to rain or moisture. PROTECTION AGAIN ELECTRIC SHOCK The device must be connected to a power supply system with efficient earthing.
3. - OPENING AND CONTROL Carefully open the package, check the content and make sure that all the parts are present and are in good condition. In cases where some parts are not present or are damaged, immediately contact Your supplier and retain the packaging for verification. WARNING! If the product has been exposed to drastic temperature changes, let the unit turned off until it reaches room temperature because the...
4. - INSTALLATION AND SWITCH ON 4.1 - PRODUCT INSTALLATION - Do not shake the device. Avoid the use of too much force during installation or unit fixing. - The unit can be installed on the floor, on the ceiling or on a truss. WARNING! IT'S REQUIRED the mounting of the safety rope (PLH232 –...
Page 20
4.3 - CONNECTION TO THE DMX CHAIN Use a cable conforming to specifications EIA RS-485: pole twisted, shielded, 120Ohm characteristic impedance and low capacity (SAGITTER SG DMX3 – SG DMX5). Do not use microphone cable or other cable with different characteristics than those specified.
5. - SETUP 5.1 – MENU MENU SUBMENU 1 SUBMENU 2 DESCRIPTION ADDRESS 001 – 512 Set the DMX address 3–CHANNEL Set channel mode with 3 channels CONTROL 4–CHANNEL Set channel mode with 4 channels MODE 6–CHANNEL Set channel mode with 6 channels 10–CHANNEL Set channel mode with 10 channels LINEAR...
Page 22
LOAD Load custom 3 setting from memory CUSTOM 3 Save current fixture settings as custom SAVE 3 and overwrite existing custom 3 data CHANNEL 000 - 255 Single channel manual control CANCEL RESET MANUAL Reset projector CANCEL UPLOAD Reset to factory setting BEAM STATIC Test beam led BEAM Test strobe beam led...
6. - MAINTENANCE To ensure optimal performance, the unit must be frequently cleaned. Unplug the device from the mains and let it cool for at least 35 minutes to avoid the risk of burns. Use a vacuum cleaner or an air compressor and a soft brush or a lens cloth to remove the dust deposited. The lenses, like any other damaged part, must be replaced with original spare parts.
