Congratulations on your purchase of the HDMI Switcher. Your satisfaction is very important to us.
Our series of HDMI Switchers are designed to make the use of your HDTV equipment more
comfortable.
HD-411E3 Switcher can expand HDMI input of your HDMI display device up to 4 HDMI inputs.
The Switcher offers single cable connection solution to TV; instead of connecting 4 HDMI cables
to your HDTV. You will find this is a useful application when you try to hang a TV on wall.
The switch box can support HDMI CEC function and compliant with your CEC enable devices.
Y
ou can enjoy the convenience of CEC features without the interruption from switch box.
For the best performance of this switch box, please read this manual carefully and keep it for
f
urther information.
Features:
HDMI CEC Supported
Expand 4 HDMI sources on your HDTV devices or Home Theater system
Support 1080P/12-bit Deep color HDTV
Support Pixel clock rate upto 225 MHz
HDCP Compliant
DTS-HD™, Dolby® TrueHD lossless compressed digital audio Compliant
Gold plated connectors
IR Remote Control
Switch box CEC function enable/disable control
HDMI CEC functions supported:
- Routing change
- One touch play
- Stand by
- Pass through CEC commands

Content of Package

5V DC 1A power adaptor
Remote control unit
HDMI 4-IN-1-OUT switcher
User's Manual
