K-array Thunder-KS User Manual page 13

A mono loudspeaker system is composed of one
Thunder-KS active subwoofer and one or more Hi/Mid-range
loudspeakers. A stereo loudspeakers system is composed of
Stereo Loudspeakers System
Active Subwoofer
Active Subwoofer
K-framework3
Mixing console PC or MAC
or matrix
Signal Input
Hi/Mid-range
loudspeakers
AES3
OUT
AES3
IN
4-pole speaker cable
SpeakON NL4
Smartphone/Tablet
Remote Control
one Thunder-KS active subwoofer driving both one or more
Hi/Mid-range loudspeakers and one passive Thunder-KS
subwoofer with satellites (Hi/Mid-range loudspeakers).
Passive Subwoofer
Passive Subwoofer
Hi/Mid-range loudspeakers output on channels 1 and 3: SpeakON NL4 +1/–1
Passive Subwoofer output on channel 4: SpeakON NL4 +2/–2
Speaker Output
P R E L I M I N A R Y
Thunder-KS
User Guide
Hi/Mid-range
loudspeakers
2- or 4-pole speaker cable
SpeakON NL4
7
