Workshop Service Manual
9924 VE Planter
9924 VE
December 2017
North America
4283618M1
4205 River Green Parkway, Duluth GA 30096 USA
NA
© AGCO 2017
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MASSEY FERGUSON 9924 VE and is the answer not in the manual?

Questions and answers

Summary of Contents for AGCO MASSEY FERGUSON 9924 VE

  • Page 1 Workshop Service Manual 9924 VE Planter 9924 VE December 2017 North America 4283618M1 4205 River Green Parkway, Duluth GA 30096 USA © AGCO 2017 English...
  • Page 2 CALIFORNIA Proposition 65 Warning WARNING: Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, or other reproductive harm. WARNING: Battery posts, terminals and related accessories contain lead and lead compounds, chemicals known to the State of California to cause cancer, birth defects, or other reproductive harm.
  • Page 3: Table Of Contents

    Table of contents 9924 VE Planter 1 General ..............1-1 .
  • Page 4 Table of contents 1.6.12 Maximum transport speed ........1-22 2 Frame .
  • Page 5 Table of contents 4 Electrical system ............4-1 4.1 Basic troubleshooting information .
  • Page 6 Table of contents 5.6.1 Clean the air tubes ..........5-19 6 Row units .
  • Page 7 Table of contents 6.11.3.2 Replace a crop kit ........6-51 6.11.4 Check the disc shims .
  • Page 8 Table of contents 9924 VE Planter 4283618M1 Find manuals at https://best-manuals.com...
  • Page 9: General

    Table of contents 1. General ........... . . 1-3 1.1 General information 1.1.1 Introduction to this service manual .
  • Page 10 Table of contents 1.6.12 Maximum transport speed ..........1-22 9924 VE Planter 4283618M1 Find manuals at https://best-manuals.com...
  • Page 11: General Information

    1. General 1.1 General information GUID-D0FA2E94-0D28-42E9-A80B-6BB593BA9687 [V1] 1.1.1 Introduction to this service manual This service manual gives information from engineering tests, operating data, and the latest service techniques at the time of publication. Read this service manual carefully before doing any service on the machine.
  • Page 12 1. General Do not pour or spill waste onto the ground, down a drain, or into any water source. Air conditioning refrigerants escaping into the air can damage the Earth's atmosphere. Government regulations may require a certified air conditioning service center to recover and recycle used air conditioning refrigerants.
  • Page 13: Safety

    1. General 1.2 Safety GUID-5D9F270E-D748-4741-82B1-BE49B78685F2 [V4] 1.2.1 Safety symbol The safety symbol tells you about a dangerous area! Look for the safety symbol in this manual and on the machine. The safety symbols tell you that there is important safety instructions in the manual.
  • Page 14: A Word To The Operator

    1. General Always make sure that safety signs are in the correct locations and that you can read the safety signs. Illustrations of safety sign locations are at in this section. Keep the safety signs clean. If necessary, use a weak soap and water solution. GUID-F38BCC9A-5A98-41F3-BA3C-2C5AB224EDFB [V6] 1.2.5 A word to the operator It is your responsibility to read and understand the...
  • Page 15: The Service Manual

    1. General GUID-0CC50E5C-AD62-4FFD-9435-62214FEFA5F4 [V1] 1.2.6 The service manual Read the table of contents and basic layout. Become familiar with all parts of this service manual. This service manual gives the technician very important information. Machine movement when in normal use determines right-hand and left-hand. This manual covers general safety practices for this machine.
  • Page 16: Personal Protective Equipment

    1. General Tractor must be equipped with rollover protective structure (ROPS) and a seat belt. use seat belt during operation. Do not dismount from moving machinery. Always operate the machine with the terminal turned on. Never start the tractor with the PTO engaged or terminal turned on.
  • Page 17: Seat Instructions

    1. General GUID-F38524AD-E24F-4FCC-9154-E5357EFDE9D2 [V3] 1.2.7.4 Seat instructions Put on the seat belt before you operate the machine. Always sit in the seat and have the seat belt on while you operate the machine. Replace the seat belts when they become worn or broken. Do not use a seat belt loosely.
  • Page 18: Exhaust Warning

    1. General GUID-AC6BA923-B398-43F4-BFAE-5130AFED6FC5 [V3] 1.2.7.6 Exhaust warning Do not operate the engine in a closed building unless the exhaust is vented to the outside. Do not tamper with or modify the exhaust system with unapproved extensions. GUID-55072A39-D882-4355-8ABA-05660F3F6EDA-high.jpg [High] Fig. 10 GUID-3910D764-BEA7-4A1B-80BF-946E438C6212 [V5] 1.2.7.7 Flying debris WARNING:...
  • Page 19: Travel On Public Roads

    1. General Use the same precautions when you do adjustments, do servicing, clean or store the machine as used when you put chemicals into the hoppers or tanks. Tell all persons who are near chemicals of the possible dangerous results and the safety precautions that are necessary.
  • Page 20: Maintenance

    1. General 1.2.9 Maintenance GUID-93C8628D-B392-4191-80DB-7D54BDAAF61B [V15] 1.2.9.1 General maintenance information Before you do maintenance, lubricate, do servicing, clean, or make adjustments: • Park the machine on a solid, level surface. • Disengage the tractor power take-off. • Make sure that all the controls are in the neutral position and apply the parking brake.
  • Page 21: Fire Prevention And First Aid

    1. General Do not operate the machine with the drive shaft shields open or removed. Entanglement in drive shafts that turn can cause injury or death. Stay clear of components that turn. Make sure that guards that turn can turn freely. A loose yoke can come off a shaft and result in injury to persons or damage to the machine.
  • Page 22: High Pressure Leaks

    1. General crop material and unwanted material from around the area. Make sure that the area below the work area is clear of flammable material because falling molten metal and sparks can cause ignition in the material. If fire occurs, move upwind and away from the smoke from the fire.
  • Page 23: Tire Safety

    1. General GUID-E28CEEE8-E160-49B0-8080-8D193B1B4E86 [V6] 1.2.9.4 Tire safety Examine tires for cuts, bulges, and correct pressure. Replace worn or damaged tires. When tire service is needed, have a qualified tire mechanic service the tire. Tire changing can be very hazardous and must be done by qualified tire mechanic using proper tools and equipment.
  • Page 24: Transport Locks

    1. General 1.3 Transport locks GUID-20B11DB3-D190-4BDC-B10A-CF2A8DFA02B7 [V1] 1.3.1 Cylinder locks Storage for the cylinder locks (1). GUID-2048BD95-6CCA-4B99-ADB4-F1A957CD7682-high.jpg [High] Fig. 24 GUID-7C048DD0-79C2-44BC-81D2-C399865DCE0E [V1] 1.3.2 Transport pins Transport pins must be put in place before transporting and storing the planter. Two pins on the right and left wings, total of four. To lock the row unit toolbar in the raised position, move the transport pin from the storage position (1) to the locked position (2).
  • Page 25: Machine Identification

    1. General GUID-0853B3F6-8A91-438A-9326-C54D60DEDBE0 [V4] 1.4 Machine identification Each machine is identified by a model and a serial number. Record these numbers in the spaces given. Give the model number and serial number to your dealer when parts or servicing are necessary. Machine model number: Machine serial number: Date of delivery:...
  • Page 26: Serial Number Description

    1. General GUID-8EAAEACD-2871-4FC9-AAFB-3C27FF39E5A3 [V2] 1.4.2 Serial number description Description of the serial number for model year 2010 and up. GUID-8D382D5F-9E99-42DE-A5BE-97EC9A41FFB6-high.jpg [High] Fig. 28 Beginning symbol Model year code (A=2010, B=2011, C=2012, World manufacturer code and on) Brand code Plant code Model identifier (model number) Family code Check letter (0 or used if model identifier is...
  • Page 27: Main Machine Components

    1. General GUID-A86C9F07-7FB3-4E4E-858D-289B155F4E57 [V1] 1.5 Main machine components SEHHE0110353201 GUID-4FC787F2-4B18-4811-B762-7D5008021285-low.svg [Low] Fig. 29 Central fill hoppers Original art: /s/TECHNICL/2017 CMS Graphics/_Raw Graphics/Margie Brewster/9924 VE/i0010861 - model drawing.ai Fertilizer tanks, if equipped Belt conveyor to fill central fill hoppers, if equipped Tracks Row unit Seed meter...
  • Page 28: Specifications

    1. General 1.6 Specifications GUID-9756D94E-FBD2-4E3A-A154-F662607BFC07 [V1] 1.6.1 Frame specifications 9924 Main Frame (Toolbar) Size 17.5 x 17.5 cm (7 x 7 in) Secondary Frame Size 7.6 x 17.8 cm (7 x 7 in) Flexibility +/- 21 degrees over total frame width Fold Cylinders Two, 5 x 30 inch double acting Wheel Lift Cylinders...
  • Page 29: Row Unit Specifications

    1. General GUID-5549E7C6-A264-4386-BCCF-ACB0E7980E24 [V1] 1.6.6 Row unit specifications Row unit Gauge wheel tire size 11.4 x 40.6 cm (4.5 x 16 in) Single closing wheel tire size 10.3 x 30.1 cm (4 x 12 in) Dual closing wheel tire size 30.8 cm dia (12 in dia) Single closing wheel down pressure 23 to 61 kg (51 to 134 lb)
  • Page 30: Approximate Shipping Weights

    1. General GUID-6D3BC5E5-5784-4B00-9F7F-85929BFC006D [V1] 1.6.10 Approximate shipping weights Weight with row unit toolbars 18144 kg (40,000 lb) Weight without row unit toolbars 13608 kg (30,000 lb) Row unit toolbars with shipping stands 4536 kg (10,000 lb) Row unit toolbars without shipping stands 3629 kg (8,000 lb) GUID-D9A38D03-D6D4-4C74-9FAB-5A3D0578BD18 [V1] 1.6.11 Tractor requirements...
