Kubota PS20 Assembly Instructions Manual

PS20 Seed Cup Speed Increaser Kit
329-181A Assembly Instructions
For PS2072 & PS2086 (S/N 1064204k-)
Before You Start
When you see this symbol, the subsequent
!
instructions and warnings are serious - follow
without exception. Your life and the lives of others
depend on it!
California Proposition 65
WARNING: Cancer and reproductive harm.
!
www.P65Warnings.ca.gov
IMPORTANT: Before you begin, read these
instructions and check to be sure all parts are
accounted for. Please retain these installation
instructions for future reference and parts ordering
information.
The PS20 Seed Cup Speed Increaser Kit has been
designed to speed up the seed rate drive system on your
PS2072 or PS2086 Primary Seeder. Please read these
installation instructions and your Primary Seeder
Operator's Manual thoroughly before beginning. Read
and pay close attention to information relating to safety
concerns. Also included in the Operator's Manual is
important information on operation, adjustment,
troubleshooting, and maintenance for this attachment
(some manual sections do not apply to all accessories).
To order a new Operator's or Parts Manual, contact your
authorized dealer. Manuals can also be downloaded,
free-of-charge, from our website at www.landpride.com.
Have model and serial numbers available when placing
an order.
Manual Part Numbers:
• Operator's Manual . . . . . . . . . . . . . . . 313-805MK
• Parts Manual . . . . . . . . . . . . . . . . . . . . 313-805PK
General Information
These assembly instructions apply to the following
PS20 Seed Cup Speed Increaser Kit listed below:
•329-181A . . . . . . PS20 Seed Cup Speed Increaser Kit
© Copyright 2021 Printed 5/21/21
Manual No. 329-242MK
Further Assistance
Further Assistance
Your Kubota dealer wants you to be satisfied with your
new PS20 Seed Cup Speed Increaser Kit. If for any
reason you do not understand any part of this manual or
are not satisfied with the service received, the following
actions are suggested:
1. Discuss any problems you have with your accessory
with your dealership service personnel so they can
address the problem.
2. If you are still not satisfied, seek out the owner or
general manager of the dealership, explain the
question/problem, and request assistance.
3. For further assistance write to:
Kubota by Land Pride
Service Department
1525 East North Street
P.O. Box 5060
Salina, KS. 67402-5060
E-mail address
lpservicedept@landpride.com
Initial Preparations
A detailed listing of parts for this PS20 Seed Cup Speed
Increaser Kit is provided on page 15. Use the list as a
checklist to inventory parts received. Please contact your
local Kubota dealer for any missing hardware.
The steps listed below must be followed before installing
this kit:
1. Park power machine and Primary Seeder on level,
solid ground.
2. Properly shutdown power machine by following the
shutdown procedure in your Primary Seeder
Operator's Manual.
3. Once all components come to a complete stop,
dismount power machine, then chock the front and
back rollers to keep unit from moving unexpectedly.
4. Refer to the Primary Seeder Operator's Manual for
remaining detailed instructions on unhooking the
attachment from your specific power machine.
5. Once attachment is unhooked, park power machine
away from the seeder.
6. Move onto disassembling the pre-existing drive
assembly.
1
