U30 & U30T
I N S TA L L AT I O N M A N U A L
For Models: U30I-LP / U30I-LP-LED / U30I-NG / U30I-NG-LED
WARNING: If the information in this manual is not followed exactly, a fire or explosion
may result causing property damage, personal injury or loss of life. Installation and
service must be performed by a qualified installer, service agency or the gas supplier.
CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS
C-16101
C#4 001609
CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the U30T and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Urbana U30T

Summary of Contents for Urbana U30T

  • Page 1 U30 & U30T I N S TA L L AT I O N M A N U A L For Models: U30I-LP / U30I-LP-LED / U30I-NG / U30I-NG-LED WARNING: If the information in this manual is not followed exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 2 Safety Information WARNING: FIRE OR EXPLOSION HAZARD Failure to follow safety warnings exactly could result in serious injury, death, or property damage. - Do not store or use gasoline or other flammable vapours and liquids in the vicinity of this or any other appliance. - WHAT TO DO IF YOU SMELL GAS •...
  • Page 3 • Do not abuse the glass by striking it or slamming the door NEVER ALLOW CHILDREN shut. If the Urbana unit is pulled out of its installation, and the vent-air intake system is disconnected for any reason, ensure TO TOUCH GLASS.
  • Page 4 CERTIFIED TO: ANSI Z21.88 / CSA 2.33 VENTED GAS FIREPLACE HEATERS CSA 2.17 GAS FIRED APPLIANCES FOR HIGH ALTITUDES This Urbana Fireplace: • Has been certified for use with either natural gas or propane (see rating label). • Is not for use with solid fuels.

  • Page 5: Table Of Contents

    Vertical Termination ......40 Unpacking and Initial Setup Venting Clearances ......42 Approved Rigid Venting .
  • Page 6 Unit Dimensions 6 5/8" [168mm] 16 " 27mm 8 " 391mm 4" [102mm] 2 " 190mm 16 " 341mm 16 " 532mm 8 " 575mm 4 " 781mm HANGING BRACKETS GAS INLET INPUT POWER 2" 51mm 16 " 567mm POWER VENT ACCESS 4 "...
  • Page 7 Operating Instructions For Your Safety, Read Safety Precautions And Lighting Instructions Before Operating WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY THEN A FIRE OR EXPLOSION MAY RESULT, CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE. FOR YOUR SAFETY READ BEFORE OPERATING WARNING: IF YOU DO NOT FOLLOW THESE INSTRUCTIONS EXACTLY, A FIRE OR EXPLOSION MAY RESULT CAUSING PROPERTY DAMAGE, PERSONAL INJURY OR LOSS OF LIFE.

  • Page 8: Crate Unpacking

    Unpacking & Initial Setup Crate Unpacking Unpacking Parts 1 Steel Bezel Plate Heat Sheilds Switch Tool 2 Media Stops 10 Wifi Enabled Remote Control Burner Media (Vermiculite or Glass) 3 Finishing Edges Documentation 11 Outside Glass 4 Steel Fascia Carrying Handles 1 - Media stops only required on Non-LED units if an optional media is used instead of the painted steel bezel set.

  • Page 9: Unpacking And Initial Setup

    Unpacking and Initial Setup Lift Handle Assembly Glass Shipping Brace Removal The lifting handles come attached to the unit. You will The unit comes with glass shipping brackets to protect the need to assemble the brackets using the bend tabs in glass while in transit.

  • Page 10: Heat Shield Installation

    Unpacking and Initial Setup Leg Height Adjustment (Optional) Urbana units have adjustable legs and can raise the height an additional 3" (76mm) in 1/2" (12.7mm) increments. This may be desired depending on the install Heat Shield Installation configuration. Adjust as follows: The fireplace comes with two heat shields.

  • Page 11: Fireplace Leveling

    1: It is essential to level the unit from proper operation. 2: This step is not necessary when wall mounting unit. All Urbana units come with leveling feet to accomodate uneven surfaces. The leveling feet can also be used to raise the height of the fireplace up an additional 1"...

  • Page 12: Gas Connection

    Unpacking and Initial Setup Wire the receptacle including ground wire. 120V Plug the fireplace power cord back into the receptacle and re-install the junction box. Use a 7/16" socket to remove the two 1/4-20 nuts retaining the electrical junction box and unplug the fireplace power cord from the receptacle.
  • Page 13 (see page 22). Remove outer glass To remove the plate, lift it up off the key slots and tilt it inward and out through the opening. (see page 23) and Remove the right louver locate the gas shut-off valve. Route the incoming gas line as desired and connect to the 1/2”...

  • Page 14: Gas Supply Varification

    Unpacking and Initial Setup Natural Gas Main Orifice Manifold Pressure 3.5” W.C. (0.89 KPa) Gas Supply Varification Min. Manifold Pressure 1.6” W.C. (0.39 KPa) Max Supply Pressure 7.0” W.C. (1.74 KPa) Min. Supply Pressure 4.5” W.C. (1.12 KPa) Do not spray leak-testing liquid in pressure taps or NOTE: results will not be accurate.

  • Page 15: Maintenance And Service

    Maintenance and Service Maintenance and Service WIRE HARNESS RETAINING FINGERS Run through the procedures in this section to ensure the fireplace system is clean and working properly at least once a year. Inspect the following: • Check the burner to see if all the ports are clear and clean.

  • Page 16: Sail Switch Removal And Maintenance

    Maintenance and Service Sail Switch Removal and Maintenance The sail switch is integral to the safety circuit system; it detects sufficient air flow is produced from the cooling fan (see page 19 for detailed information). There is a sail Bench test sail switch by checking continuity across switch located on the center fan as well as the chase fan AB terminals.

  • Page 17: Component Tray Map

    Maintenance and Service Component Tray Map Fuse Replacement - Fan and Top Light The component tray is fixed underneath the firebox. Determine what caused fuse to blow before replacement. All components are afixed to the tray using velcro for Replace fuse as follows: servicing ease.

  • Page 18: Pilot Light

    Maintenance and Service Air Shutter (Venturi) The air shutter plays a very important role in flame appearance and combustion quality. The shutter adjusts how much air gets mixed with the gas before it ignites. Pilot Light We recommend starting the fireplace and allowing it to heat up for 15 minutes before making final adjustments.

  • Page 19: Remote Syncing

    Maintenance and Service Remote Syncing Power Vent (PV) Switch The remote should be synced to your fireplace by your For convience, the fireplace comes pre-wired for installer during installation. power vent applications. If needed, to switch into power vent (PV) mode locate the PV switch next to Your remote may gradually lose its RF connection strength the Remote Sync Button.

  • Page 20: Top Light Replacement

    Maintenance and Service Burner Removal The burner may need to be replaced if defected or damaged. Replace burner as follows: Top Light Replacement (see page 22). Remove outer glass (see page 23). Remove louvers Occasionally the top light bulb(s)good will need to be replaced.

  • Page 21: Safety Circuit System

    Maintenance and Service Safety Circuit System Timing Relay: Switches system from bypass mode to operating mode when powered via snap disc. There is a 5 Your fireplace has a safety circuit system designed second delay to give fans time to build speed. to protect you and your home from damage due to unmanaged heat.

  • Page 22: Outer Glass Removal

    Maintenance and Service Familiarize yourself with the glass hooking method in the following steps before proceeding. NOTE: Outer Glass Removal Left and right side glass must be removed before front Initial paint curing of the appliance can leave a slight glass.

  • Page 23: Louver Removal

    Maintenance and Service Louver Removal Louver assemblies will need to be removed to access components and firebox. There are two side louver assemblies and one front; the sides need to be removed first. Remove louvers as follows: Remove front glass using same method after boh side glass sections have ben removed.

  • Page 24: Inner Glass Removal

    Maintenance and Service Inner Glass Removal The 5mm thick inner glass is ceramic. Handle glass with care; breaking will result in a dangerous mess. Use a shop vacuum to clean if a break occurs. All glass should be handled with quality suction cups such as 50-3837. Two suctions cups must be used for larger glass segments.

  • Page 25: Media Placement

    Initial Setup Media Placement (LED Unit) Media Placement (Standard Unit) The unit comes with a measured amount of clear diamond The unit comes with a steel bezel and a measured amount glass to cover the burner and the burner platform. Install of vermiculite to cover the burner.

  • Page 26: Final Firebox Sealing

    Initial Setup (U30T ONLY) Final Firebox Sealing The Urbana Tall units require 1 additional step too seal the firebox. Follow the instructions on the left first, then; Final Firebox Sealing Apply a light application of silicone along the edge where the...

  • Page 27: Framing And Installation

    Framing and Installation Chase Framing WARNING IT IS ESSENTIAL THAT THE CHASE IS VENTED IN A MANNER THAT RELIEVES THE ADDITIONAL HEAT ENTERING THE CHASE. ENSURE ONE OF THE AVAILABLE FRAMING OPTIONS HAVE BEEN CONSTRUCTED IN ACCORDANCE WITH THIS MANUAL. FAILURE TO DO SO CAN CREATE AN OVERHEATING SITUATION THAT COULD LEAD TO BUILDING FIRE. Ensure your chase has been constructed in a manner that vents the chase into the same room.

  • Page 28: Minimum Framing Clearances

    Depth 7" Min. Side Wall Clearance Beside Fireplace 4 " 13" Min. to U30 65" Min. Recess U30T 71 5/8" Min. Underside Chase Height U30 56" Min. 2 " Min. U30T 62 5/8" Min. 21" Min. Vent Install Side Wall...
  • Page 29 Framing and Installation LETTER MIN. DIMENSION U30 65” (1651 mm) U30T 71 5/8" (1819 ) 21” (533 mm) 30 3/4” (788 mm) 9 15/16” (253 mm) Minimum 1 1/2” (38 mm) Minimum 120 in2 (774 cm2) Minimum 90in2 (580 cm2) U30 17 3/8”...
  • Page 30 Framing and Installation *Framing illustrations are for example only and are not necessarily meant to be followed exactly. HEAT RELEASE: FRONT AIR INTAKE: FRONT WITH PEDESTAL HEAT RELEASE: OPEN AIR INTAKE: TRADITIONAL ON PEDESTAL 30 |...
  • Page 31 Framing and Installation HEAT RELEASE: TRADITIONAL WITH FALSE CEILING AIR INTAKE: TRADITIONAL HEAT RELEASE: SIDES ONLY AIR INTAKE: SIDES ONLY WITH PEDESTAL *Framing illustrations are for example only and are not necessarily meant to be followed exactly. | 31...

  • Page 32: Framing Pedestal

    Framing and Installation Framing Pedestal An optional pedestal can be added to any installation to raise the unit further off the floor. Minimum opening and pedestal dimensions must be followed to ensure safe 23" heat dissipation. Combustible materiel is acceptable when 584mm constructing the pedestal.
  • Page 33 Framing and Installation *Framing illustrations are for example only and are not Minimum intake dimensions must be taken at the fireplace necessarily meant to be followed exactly. cabinet, not the end of the hearth/plinth. HEAT RELEASE: OPEN AIR INTAKE: TRADITIONAL WITH PLINTH HEAT RELEASE: OPEN AIR INTAKE: OPEN...

  • Page 34: Framing Corner And Extension

    Framing and Installation left side of fireplace (shown below). The framed side wall can be adjacent to the unit, or it can extend indefinetely. If an extension is desired, an interal "false wall" must be constructed beside the unit within the enclosure to maintain chase draft geometry.

  • Page 35: Crawl Space / Basement Intake

    Framing and Installation Crawl Space / Basement Intake Where approved by local codes and the house's HVAC supplier, the chase intake air may be supplied from a basement or conditioned crawl space below to achieve a hidden intake at the bottom of the chase. •...

  • Page 36: Hdtv And Recess Clearances

    Framing and Installation HDTV and Recess Clearances If you're planning to mount a TV or artwork above the fireplace than some considerations must be made to ensure delicate objects are protected from heat. During testing temperatures did not exceed 50°F over ambient on the front exterior wall.

  • Page 37: Finishing Fascia (Optional)

    Framing and Installation Finishing Fascia (Optional) The fireplace is supplied with an optional 3-piece steel finisihing fascia (item #4, page 8) that installs around the perimeter of the outer glass for a cleaner finish. To install the fascia pieces simply place them on top of the bottom tiling edges and glue them to the hearth surface using construction adhesive.

  • Page 38: Venting

    Venting Venting Introduction: Your fireplaces can operate using a natural vent or power vent system (50-3883). Natural Vent (Rigid): 4" x 6 " venting system Natural Vent (Flex): 4" X 7" aluminum flex venting system Power Vent: 4" x 6 "...

  • Page 39: Vent Termination Restrictions

    Venting Vent Termination Restrictions Fixed Closed Fixed Openable Closed Openable Termination Cap Air Supply Inlet Gas Meter Restriction Zone (Termination not allowed) Canadian Installation US Installation Description 12 in (30 cm) Clearance above grade, verandah, porch, deck, or balcony. 12 in (30 cm) 9 in (23 cm) Clearance from window or door that may be opened.

  • Page 40: Vertical Termination

    Venting Roof Pitch Minimum Height (H) Feet Meters Flat to 7/12 Over 7/12 to 8/12 0.46 Vertical Termination Over 8/12 to 9/12 0.61 Over 9/12 to 10/12 0.76 Check “I ” nItIal nstallatIon entIng learanCes Over 10/12 to 11/12 3.25 0.99 for required clearances to combustibles when Over 11/12 to 12/12...
  • Page 41 Venting NOTES: the exterior wall. Attach the vinyl siding standoff to the horizontal termination. The termination 1. If an offset is necessary in the attic to avoid attaches to the flat portion of the standoff which obstructions, it is important to support the vent provides an air space between the wall and the pipe every 3’...

  • Page 42: Venting Clearances

    See below Above First Elbow Above Additional Elbows 3” (76 mm) x” x” 9” Minimum to (NG)8' Maximum (LP) 4’ Maximum Vent Run @ Minimum Rise 1' Single Section Minimum Vent Rise U30 56” (1422mm) U30T 62 5/8” (1590mm) 42 |...

  • Page 43: Approved Rigid Venting

    Venting Approved Rigid Venting WARNING: Do not mix parts from different vent manufacturers’ systems. Manufacturer Trade Name Nominal Sizes EXCEPTION TO WARNING: This product has been EXCELDirect 4” - 6 ” evaluated by Intertek using a DirectVent Pro starting M&G Dura-Vent Direct Vent Pro 4”...

  • Page 44: Flex Venting

    Only the flex venting and spacers are needed. You Use gear clamps to secure inner and outer must use the flex adapter kit and a certified rigid pipe vent. No sealant required termination cap. Flex Starter Adapter Any Urbana Fireplace 44 |...

  • Page 45: Approved Venting Configurations

    Venting Approved Venting Configurations (NG) : This shows the range of venting options using either vertical or horizontal 40’ terminations; any layout that remains (12.2m) within the shaded area is acceptable. Having the fewest number of elbows is ideal as they restrict air movement. NG Vent Any combination of rise and run can be 35’...
  • Page 46 Venting Approved Venting Configurations (LP) : This shows the range of venting options using either vertical or horizontal terminations; any layout that remains 40’ within the shaded area is acceptable. (12.2m) Having the fewest number of elbows is ideal as they restrict air movement. LP Vent Any combination of rise and run can be 35’...

  • Page 47: Exhaust Restrictor Setting 6

    Venting Exhaust Restrictor Settings: Exhaust Restrictor Adjustment: The restrictor disk is used to regulate draft and To adjust the exhaust restrictor, locate the access hole on combustion air that leads to proper flame quality and the front of the unit. appearance.
  • Page 48 #50-3906 - U30 BURNER PAN PART USED IN ALL UNITS PCE) (NG & LP) 50-3902 - LEFT LOUVER ASSEMBLY #50-3895 - URBANA OUTER SIDE GLASS #50-3914 - U30 OUTER FRONT GLASS PART USED IN ALL UNITS PART USED IN ALL UNITS ASSEMBLY (1 PCE)
  • Page 49 PART USED IN ALL UNITS PART USED IN ALL UNITS #50-3899 - TIMING RELAY #50-3837 - SUCTION CUP HANDLE (1 PC) #50-4056 URBANA IPI PILOT ASSEMBLY PART USED IN ALL UNITS PART USED IN ALL UNITS PART USED IN ALL UNITS...
  • Page 50 Parts List #50-3888 - PF2 WIFI READY TRANSMITTER #50-2682 - SIT 885 VALVE W/ STEPPER MOTOR #50-3887 - PF2 WIFI READY IFC PART USED IN ALL UNITS PART USED IN ALL UNITS (NG) PART USED IN ALL UNITS #50-3889 - LED WIFI CONTROLLER #50-3891 - LED LIGHTING STRIP #50-3890 - LED DRIVER PART USED IN ALL LED UNITS...
  • Page 51 Troubleshooting Troubleshooting: Problem Cause Solution Check Burner doesn’t turn on IFC ON/OFF circuit is OPEN Ensure ON/OFF circuit is complete Check the ON/OFF switch, confirm “-” symbol is pressed down (check with multimeter) Check for continuity across burner switch Check for continuity across timing relay terminal A and B (see "Safety Circuit System") Remote signal not being received Ensure IFC is receiving remote commands (beeping) Re-sync remote...
  • Page 52 Troubleshooting Incorrect media placement Ensure secondary air slots are cleared Check for piled up burner media covering air slots (vermiculite/glass media) Check for logs/rocks covering air slots Check for excessive burner media (no more than 1 layer thick) Check for foreign burner media Leaking burner Ensure burner is sealed Visually inspect burner for leaks;...
  • Page 53 Wiring Diagram Wiring Diagram: | 53...
  • Page 54 Warranty Installation Reference Guide Please fill in and retain this information card for your future reference. Go to www. urbanafireplaces.com/warranty to fill in your warranty registration card. NAME OF DEALER: NAME OF INSTALLER: _________________________________________ _________________________________________ ADDRESS: ADDRESS: _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________ _________________________________________...
  • Page 55 Warranty WARRANTY INFORMATION Sherwood Industries Ltd. (“Sherwood”) hereby warrants, subject to the terms and  Exclusions conditions herein set forth, this product against defects in material and workmanship An expanded list of exclusions is available at www.urbanafireplaces.com/warranty.html during the specified warranty period starting from the date of original purchase at retail. This warranty does not cover: In the event of a defect of material or workmanship during the specified warranty period, ...
  • Page 56 MANUFACTURED BY: SHERWOOD INDUSTRIES LTD. 6782 OLDFIELD RD. SAANICHTON, BC, CANADA V8M 2A3 www.urbanafireplaces.com Winter 2020 C-16101...
