Summary of Contents for SIMPLIHOME WyndenHall brooklyn + max 3AXCDRP-10
-
Page 5: Pre-Assembly Information
PRE-ASSEMBLY INFORMATION MODEL # 3AXCDRP-10 PART DESCRIPTION SHELF QTY 1 5/20... - Page 6 PART DESCRIPTION DRAWER BACK DRAWER BOTTOM LEFT BACK PANEL QTY 2 QTY 2 QTY 1 RIGHT BACK PANEL MIDDLE BACK PANEL QTY 1 QTY 1 6/20...
-
Page 7: Hardware Description
HARDWARE DESCRIPTION Required - Flathead screwdriver FURNITURE TIP OVER RESTRAINT Phillips screwdriver QTY 1 SET Not Included 7/20... - Page 9 1. Attach 4 Cam Lock Pins 9 to pre-drilled holes at back of Drawer Front L . 2. Align Cam Lock Pins with pre-drilled holes and attach Drawer Sides 3. Insert 2 Cam Locks 9 into pre-drilled holes on each Drawer Side 4.
- Page 10 1. Align Drawer Back N with Drawer Bottom O and press firmly into slot. 2. Attach Drawer Back N using 2 Allen Key Screws 1 through pre-drilled holes on each Side 3. Use Allen Key 3 to tighten screws. Do not over-tighten. Repeat Step 1-3 for the second drawer.
- Page 11 STEP-4...
- Page 12 1. Align Dowels on Divider of Wine Rack I with pre-drilled holes on Shelf F . 2. Attach Divider of Wine Rack I to Shelf F .
- Page 13 ASSEMBLY MODEL # 3AXCDRP-10...
- Page 14 1. Attach Bottom Shelf C to 2 Sides AL , AR and 2 Dividers DL , DR using 12 Allen Key Screws 1 (3 Screws on each Side and Divider ). 2. Use Allen Key 3 to tighten screws. Do not over-tighten.
- Page 15 1. Attach Legs H1 , H2 to Bottom Shelf C using 8 sets Allen Key Bolts, Lock Washers and Washers 2 (2 sets on each Leg). 2. Use Allen Key 3 to tighten Bolts. Do not over-tighten. 1. Attach Back Panels P , PL , PR to back frame of sideboard by using 26 Phillips Screws 5 .
- Page 16 NOTE: The screwdriver is not included in the hardware pack.
-
Page 20: Warranty
WARRANTY...
