3.11 PS-900EMS EMS Remote Station

3.12 JS-900-xx Jump Seat Station

3.13 JS-900W-xx Jump Seat Station

The PS-900EMS EMS Remote Station extends the
"Auxiliary Input" port of an IM-900E to a remote location.
It is most commonly used in an EMS/Rescue rig to
provide a radio transmit station for the medical
technician in the rear compartment.
The JS-900-xx Jump Seat Station provides two jumpseat intercom
access/radio listen positions. Due to the 15ft. coil cord length of the
Series 900 Headsets, a convenient position mid-way between two
crewmembers can easily be located. One end of the JS-900-xx is
fitted with a twist-lock connector that mates with the "REMOTES"
port of the IM-900 or the expansion port of a JS-901-xx. There are a
variety of lengths for the JS-900-xx, with xx denoting the length. A
red washer is used behind the Tip-Ring-Sleeve (TRS) female panel
mount jack to indicate this is an intercom-access/radio-listen port. A
CSB-900 or 8B-900 Series Radio Transmit Headset can be plugged
into this station; however, the radio PTT black button will not
function and the MIC will be Hot (Always On).
The JS-900W-xx is a weatherproof version of the Jump Seat
Station. It provides two jumpseat intercom access/radio listen
positions in a weatherproof enclosure. Due to the 15 coil cord length
of the Series 900 Headsets, a convenient position mid-way between
two crewmembers can easily be located. One end of the JS-900w-
xx is fitted with a twist-lock connector that mates with the
"REMOTES" port of the IM-900 or the expansion port of a JS-901-xx
or JS-901W-xx. There are a variety of lengths for the JS-900-xx,
with xx denoting the length. A CSB-900 or 8B-900 Series Radio
Transmit Headset can be plugged into this station; however, the
radio PTT black button will not function and the MIC will be Hot
(Always On).
