electriQ PORTABLE AIR CONDITIONER
Please read this user manual before using this innovative Air Conditioner and keep it
Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals
USER MANUAL
P12C
P15C
Thank you for choosing electriQ
safe for future reference.
12,000 BTU
14,000 BTU
Advertisement
Table of Contents
Related Manuals for ElectrIQ P15C
Summary of Contents for ElectrIQ P15C
- Page 1 P12C 12,000 BTU P15C 14,000 BTU Thank you for choosing electriQ Please read this user manual before using this innovative Air Conditioner and keep it safe for future reference. Visit our page www.electriQ.co.uk for our entire range of Intelligent Electricals...
-
Page 2: Table Of Contents
CONTENTS SAFETY INFORMATION FEATURES PARTS LIST INSTALLATION OPERATION REMOTE CONTROL EMPTYING THE INTERNAL WATER TANK CLEANING AND MAINTENANCE TROUBLESHOOTING ERROR CODES SUPPORT TECHNICAL SPECIFICATION... - Page 3 SAFETY INSTRUCTIONS Important! • Carefully read the instructions before operating the unit • This appliance is for indoor use only. • Rating: This unit must be only connected to a 220-240 V / 50 Hz earthed outlet. • Installation must be in accordance with regulations of the country where the unit is used. •...
- Page 4 • R290 refrigerant gas complies with European environmental directives. • R290 has a low GWP (Global Warming Potential) of 3. • The air conditioners contain around 280 g of R290 refrigerant gas. • Do not use or store in an unventilated space with an area smaller than 13.4 m per unit.
-
Page 5: Features
FEATURES 3 in 1 Cooling, Fan, Dehumidifier. The P12C is great for Rooms up to 30 m and the P15C for rooms upto • 3 speed fan: Balancing quiet operation with performance. • 24 Hours Start / Stop Timer. •... -
Page 6: Installation
INSTALLATION WARNING: Before using this unit, please keep it upright for at least 3-4 hours. This unit can easily be moved from one room to another. While moving the unit please note that it must always be kept upright and then placed on an even surface. Attach the fishtail connector to the end of the hose, by extending the end and twisting until firmly attached (At least 3 full rotations). - Page 7 NOTES: • The window kit is only designed to be installed with sliding or sash windows or doors. The window kit is not designed or to be used with any other style of windows. • The fish tail adaptor can be used without the slide bar with most windows / doors. •...
-
Page 8: Operation
OPERATION Press the POWER button to turn the unit ON or OFF. Press the MODE button to cycle between the 3 modes, the indicator for the selected mode will be illuminated. COOL: The room is cooled with the cold air expelled through the front air outlet while hot air is expelled through the vent pipe. -
Page 9: Remote Control
REMOTE CONTROL POWER Press to turn the unit on or off. Press to decrease the desired temperature or TEMP - timer duration. Press to increase the desired temperature or TEMP + TEMP + POWER timer duration. SPEED Press to change between the three fan speeds. TEMP - SPEED SLEEP... -
Page 10: Emptying The Internal Water Tank
EMPTYING THE INTERNAL WATER TANK MANUAL DRAINAGE: When the internal water tank is full the unit will stop working. Shut off the unit and unplug. Try not to move the model abruptly as this may cause the water in the internal tank to spill out. Place a tray under the lower water plug or place the unit in a drainage area. -
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE PLEASE TURN OFF THE UNIT AND UNPLUG FROM THE MAINS BEFORE CLEANING OR PERFORMING ANY MAINTENANCE CLEAN THE SURFACE Clean the surface of the machine with a wet soft cloth. Do not use chemicals, such as benzene, alcohol, gasoline, etc; otherwise, as this may cause damage to the surface and or the internal workings of the machine AIR FILTER CLEANING If the filter screen is clogged with dust, the effectiveness of the air conditioner is reduced. -
Page 12: Troubleshooting
TROUBLESHOOTING Do not repair or disassemble the air conditioning. Unqualified repair will invalidate the warranty and may lead to failure, causing injuries and property damage. Only use it as directed in this user manual and only perform operations advised here. Problems Reasons Solutions... -
Page 13: Support
Please contact the local council for details of your local household waste recycling centres. electriQ UK SUPPORT www.electriQ.co.uk/support Please, for your own convenience, make these simple checks before calling the service line. If the unit still fails to operate call the number below, or complete the online form. -
Page 14: Technical Specification
TECHNICAL DATA Model P12C P15C Cooling capacity: 12,000 BTU 14,000 BTU Input power: 1300 W 1500 W AC motor with 3 fan speeds. Air flow volume: 420 m³/h Input current: 5.65 A 6.5 A Refrigerant: R290/280g Sound power level: 56 dB(A)
