INSTRUCTION MANUAL
WB-800 S plus
<Usage Conditions>
Temperature Range for Use
Relative Humidity
<Storage Conditions>
Temperature Range of Environment : 14˚F – 122˚F / -10°C – 50°C
Range of Relative Humidity
To avoid malfunctions, avoid storing the equipment where there is direct sunlight, significant temperature
changes, the risk of dampness, a large amount of dust, in the vicinity of fires, or where there is the risk
of receiving vibrations or shocks.
ELECTRONIC SCALE
CLASS III
NTEP APPROVED
: 41˚F – 95˚F / 5°C – 35°C
: 30% – 80% (without condensation)
: 10% – 90% (without condensation)
Please read this Instruction Manual carefully and keep it
handy for future reference.
en

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WB-800AS plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tanita WB-800AS plus

  • Page 1 INSTRUCTION MANUAL ELECTRONIC SCALE WB-800 S plus CLASS III NTEP APPROVED <Usage Conditions> Temperature Range for Use : 41˚F – 95˚F / 5°C – 35°C Relative Humidity : 30% – 80% (without condensation) <Storage Conditions> Temperature Range of Environment : 14˚F – 122˚F / -10°C – 50°C Range of Relative Humidity : 10% –...
  • Page 2: Table Of Contents

    1. Table of Contents 2. Safety Notes 7. Operation •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 3. Part Names 8. Based on NIH/WHO BMI Guidelines ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• ••••••••••••••••••••••••••••••••• 4. Functions 9. Output data format ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 5. Set up 10. Troubleshooting •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 6. Power supply 11.Specifications •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••...
  • Page 3 Caution Keep away from water. Do not jump on the equipment. Do not insert fingers into gaps and holes. Do not apply force to the display. The screen panel may break and cause injury. Do not hang heavy objects on a wall-mounted display. Prohibited Do not pull on a wall-mounted display.
  • Page 4 Errors in measurements may occur if the device is used in an unstable location. Scheduled Maintenance TANITA recommends that each facility conduct periodic checks of each unit. 1. Check the following at least daily: • The unit is on a stable and level surface ie on a firm flooring, not on a thick carpet 2.
  • Page 6: Part Names

    3. Part Names Display Box Level Gauge Platform Supporting Feet ×2 djustable Feet ×4 ccessories Display Box C dapter CD ROM Battery Box (This Manual) Bracket Screws...
  • Page 7 Control Panel Symbols and their Meanings Caution Display Unit On Refer to the attached notes. Zero reset Output Changing Measurement Direct current Units Select BMI mode Adjust height for BMI Display Unit Off...
  • Page 8: Functions

    4. Functions utomatic Power Off This equipment has an automatic power off function that automatically turns off the power in order to reduce battery consumption. If the display does not change for 30 seconds, the power will be automatically turned off. Temporarily Disabling utomatic Power Off This function can be temporarily disabled using the following procedure.
  • Page 9: Power Supply

    When using the stand Please pull out the stand at the back of the display box. When putting away the display box, please insert the stand in the slot on the back of the display box. When installing the display box on the wall 1) Attach bracket to wall using included screws.
  • Page 10: Operation

    7. Operation 1. Standard Weighing Procedures 1) Turn on the power by pressing the key. fter all the segments flash, [0.0lb / 0.0kg] is displayed. 3) The person to be weighed should stand still in the middle of the platform. 4) The weight will be stable and displayed on the display.
  • Page 11: Based On Nih/Who Bmi Guidelines

    7) The person to be weighed should stand still in the middle of the platform. 8) The weight will be stable and displayed on the display. beep sound will be heard and " " sign will appear in the upper left corner of the display. The weight and BMI calculation will then be displayed.
  • Page 12: Output Data Format

    RS-232C Port RS-232C/USB Select Switch US Port If you want to use the USB output, you must install the necessary driver on to your PC, available to download from http://www.tanita.com Signal Line Name and Connection Method Terminal no. Signal name...
  • Page 13 Output data Header Pattern Name of item Output data (ASCII code) BMI mode Weight mode kg mode lb mode Control data Fix to 16 2 Bytes fixed Control data ˜0 Fix to 1 1 Byte fixed Control data ˜1 Fix to 1 1 Byte fixed Control data ˜2...
  • Page 14: Troubleshooting

    10. Troubleshooting If you are concerned that the scale may not be functioning correctly, please check the following point before requesting repairs. Problem Check Points •Check the connection of the AC adapter jack to the DC jack, and the connection of the AC adapter plug to the power outlet.
  • Page 15: Specifications

    11. Specifications Model WB-800AS plus Measurement System Strain Gauge Load Cell Maximum Capacity / Minimum Graduation 440l / 0.2l 200kg / 0.1kg Weight Measurement Standard 0 - 440l 0 - 200kg Range of Weight Step on 22 - 440l 10 - 200kg...
  • Page 16 • Consult the dealer or an experienced radio or television technician for help. Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Tanita Corporation may void the user's authority to operate the equipment. 174-8630 www.tanita.asia ( Shanghai ) Trading Co., Ltd.
