Tanita WB-800 plus Instruction Manual
Tanita WB-800 plus Instruction Manual

Tanita WB-800 plus Instruction Manual

Electronic scale

Advertisement

Quick Links

W -800 plus
<Usage Conditions>
Temperature Range for Use
Relative Humidity
<Storage Conditions>
Temperature Range of Environment : 14˚F – 122˚F / -10°C – 50°C
Range of Relative Humidity
To avoid malfunctions, avoid storing the equipment where there is direct sunlight, significant temperature
changes, the risk of dampness, a large amount of dust, in the vicinity of fires, or where there is the risk
of receiving vibrations or shocks.
ELECTRONIC SCALE
Instruction manual
: 41˚F – 95˚F / 5°C – 35°C
: 30% – 80% (without condensation)
: 10% – 90% (without condensation)
Please read this Instruction Manual carefully and keep it
handy for future reference.

Advertisement

loading
Need help?

Need help?

Do you have a question about the WB-800 plus and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tanita WB-800 plus

  • Page 1 ELECTRONIC SCALE W -800 plus Instruction manual <Usage Conditions> Temperature Range for Use : 41˚F – 95˚F / 5°C – 35°C Relative Humidity : 30% – 80% (without condensation) <Storage Conditions> Temperature Range of Environment : 14˚F – 122˚F / -10°C – 50°C Range of Relative Humidity : 10% –...
  • Page 2: Table Of Contents

    1. Table of Contents 2. Safety Notes 8. Operation •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• •••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 3. Part Names 9. Based on NIH/WHO BMI Guidelines ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• •••••••••••••••••••••••••••••••••• 4. Assembly Instructions 10.Measuring height procedure ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• •••••••••••••••••••••••••••••••••••••••••••••••••••• 5. Functions 11.Output data format ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••• 6. Set up 12.Troubleshooting ••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••••...
  • Page 3 Caution Keep away from water. Do not jump on the equipment. Do not insert fingers into gaps and holes. Do not apply force to the display. Prohibited The screen panel may break and cause injury. Assist persons with disabilities. Another person should assist persons with disabilities who may not be able to take a measurement alone. Be sure clean the scale platform with appropriate disinfectant after each use.
  • Page 4: Scheduled Maintenance

    Errors in measurements may occur if the device is used in an unstable location. Scheduled Maintenance TANITA recommends that each facility conduct periodic checks of each unit. 1. Check the following at least daily: • The unit is on a stable and level surface ie on a firm flooring, not on a thick carpet 2.
  • Page 6: Part Names

    3. Part Names WB-800H plus WB-800P plus Display Box Release Screw Knob Height Rod rm Platform WB-800S plus Display Box Battery Box Platform Display Box DC Jack ccessories <WB-800S plus> <WB-800H plus, WB-800P plus> C dapter CD ROM C dapter Back Cover Front Cover (This Manual)
  • Page 7 Control Panel Symbols and their Meanings Caution Display Unit On Refer to the attached notes. Zero reset Output Changing Measurement Direct current Units Select BMI mode Adjust height for BMI Display Unit Off...
  • Page 8: Assembly Instructions

    4. ssembly Instructions Platform (fully assembled and pre-wired to display assembly) Cable (Platform side) Lower Pole ssembly Screw Cable (Cables) (Top Head Display ssembly Side) Top Head Display ssembly (fully assembled and pre-wired to platform) Back Cover Front Cover Top Height Rod ssembly (fully assembled with pivoting height measuring lever) Height Rod rm Lower Height Rod ssembly...
  • Page 9 For WB-800H plus For WB-800P plus Install the lower pole into the Install the lower pole into the plateform using the four (4) plateform using the four (4) screws. screws. Assemble the top head display into the lower pole inserting the cable into lower pole.
  • Page 10: Functions

    5. Functions utomatic Power Off This equipment has an automatic power off function that automatically turns off the power in order to reduce battery consumption. If the display does not change for 30 seconds, the power will be automatically turned off. 6.
  • Page 11: Power Supply

    7. Power supply C adapter C adapter is much preferable when the scale will be used continuously. For WB-800H plus, WB-800P plus 1) Plug on the AC adapter. Insert 2) Insert the connecter into the the AC adapter jack into the DC Jack on the back of the DC Jack on the back of the display box.
  • Page 12: Operation

    8. Operation 1. Standard Weighing Procedures 1) Turn on the power by pressing the key. fter all the segments flash, [0.0lb / 0.0kg] is displayed. 3) The person to be weighed should still in the middle of the platform. 4) The weight will be locked-in and displayed on the display. “ (Hold)”...
  • Page 13: Based On Nih/Who Bmi Guidelines

    •After pressing the key. •After weight measurement while the weight result remains on the display. 3. Step on Function The scale will turn on automatically when the user steps onto the platform. ote: •If the weight is less than 22lb / 10kg, the “Step-On” function will not work. •If person less than 22lb / 10kg, press the key manually to turn on the scale.
  • Page 14: Measuring Height Procedure

    10. Measuring height procedure For WB-800H plus The user should step on the platform without wearing shoes for accurate measurement. Always have someone assist the user for accurate measurement. djust the Height Rod rm position before the user steps on the platform. Place hand on the Height Rod rm.
  • Page 16: Output Data Format

    RS-232C Port RS-232C/USB Select SW US Port If you want to use the USB output, you must install the necessary driver on to your PC, available to download from http://www.tanita.com Signal Line Name and Connection Method Terminal no. Signal name...
  • Page 17 Output data Header Pattern Name of item Output data (ASCII code) BMI mode Weight mode kg mode lb mode Control data Fix to 16 2 Bytes fixed Control data ˜0 Fix to 1 1 Byte fixed Control data ˜1 Fix to 1 1 Byte fixed Control data ˜2...
  • Page 18: Troubleshooting

    12. Troubleshooting If you are concerned that the scale may not be functioning correctly, please check the following point before requesting repairs. Problem Check Points •Check the connection of the AC adapter jack to the DC jack, and the connection of the AC adapter plug to the power outlet.
  • Page 19: Specifications

    13. Specifications Model WB-800 plus Measurement System Strain Gauge Load Cell Maximum Capacity / Minimum Graduation 660lb / 0.2lb 300kg / 0.1kg Weight Measurement Standard 0 - 660lb 0 - 300kg Range of Weight Step on 22 - 660lb 10 - 300kg...
  • Page 20 Modifications The FCC requires the user to be notified that any changes or modifications made to this device that are not expressly approved by Tanita Corporation may void the user’s authority to operate the equipment. isposal This device features radio interference suppression in compliance with EC This equipment is electronic device.

This manual is also suitable for:

Wb-800h plusWb-800p plus
