Summary of Contents for AIMS Power PWRIX120012SUL
- Page 1 DC TO AC PURE SINE POWER INVERTER WITH AUTOMATIC TRANSFER SWITCH PWRIX120012SUL / PWRIX200012SUL INSTRUCTION MANUAL ETL Listed to UL 458 and CSA 22.2 NO 107.1...
-
Page 2: Warning And Safety
A. INTRODUCTION The AIMS Power pure sine inverter product line is used for back-up power. The pure sine product line is ideal for sensitive equipment and provides clean power, which is more efficient for back-up power applications. The power inverter... -
Page 3: Inverter Features
inverter. Leave adequate ventilation space underneath the inverter as well; thick carpets or rugs can obstruct air flow, causing the inverter to overheat. 11. Avoid unintentional starting. Be sure the switch is in the OFF position when not in use and before plugging in any appliance. 12. - Page 4 Terminal cover...
-
Page 5: Installation
D. INSTALLATION Ensure there is enough space for the installation, and the location should be meet the following requirements: 1. Water should not access the inverter. 2. The ambient temperature should be 32~104°F, and the preferred temperature is 50-77°F. The lower the better in this range of ambient temperature. 3. - Page 6 requirement 3-5x its running wattage. In this example, 960 watts * 3 = 2880 watts needed from the inverter so don’t size your inverter too small. 2. Battery operating time depends on battery capacity and load. The formula for operating time is: battery capacity divided by the value of the load divided by battery voltage times 1.10%.
- Page 7 3. Hardwire Connection – AC Wiring. Use 12 AWG wire. Input: Hot line + Neutral + Ground Output: Hot line + Neutral + Ground Green – ground White – neutral Black - hot WARNING The output voltage of this unit must never be connected in its input AC terminal, overload or damage may result.
- Page 8 2. Connect your inverter to your battery bank and do not to reverse the polarities of the connection. See Section F. 3. Press the power switch button on your inverter for .5 seconds and a green LED will light up indicating that the inverter is on. 4.
- Page 9 115 VAC inverter is 1,250 VAC. For 230 VAC or dual voltage inverters, the hi-pot voltage is 1,500 VAC. This Aims power inverter is hi-pot tested before it leaves the factory, with a UL Certified hi-pot tester, set to the voltages shown above.
-
Page 10: Troubleshooting Tips
TROUBLESHOOTING TIPS Fault / Display Cause Solutions Low input DC voltage Recharge or replace the battery Do not use it when the battery is charging. Check the rated voltage of the battery and make sure it is in within the range of the input voltage. -
Page 11: Specifications
SPECIFICATIONS PWRIX120012120SUL PWRIX200012120SUL MODEL NO DC Input Voltage 12V (10-16V) 12V (10-16V) Output Wave Form Pure Sine Wave THD Pure Sine Wave THD <3% <3% Output Power 1200W 2000W Surge Power Capacity 2400W for 40 milsec 4000W for 40 milsec Efficiency No Load Current 1.2 A switch on... -
Page 12: Warranty
AIMS be liable for indirect, special or consequential damages. This warranty only applies to AIMS Power branded products. All other name brand products are warranted by and according to their respective manufacturer. Please do not attempt to return non-AIMS Power branded products to AIMS Power.
