Skywalker SWSAS1500 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User's Manual
Model______________
SWSAS1500
WARNING
Read all precautions and
instructions in this manual before
using this equipment. Save this
manual for future reference.
Maximum user weight 250 lbs.
IMPORTANT
CAUTION: Adult Assembly
Required
Trampoline and Enclosures are
susceptible to winds. Be sure to
secure your trampoline and enclosure.
Wind Damage is not covered in the
warranty of your trampoline

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SWSAS1500 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Skywalker SWSAS1500

Summary of Contents for Skywalker SWSAS1500

  • Page 1 User’s Manual Model______________ SWSAS1500 WARNING Read all precautions and instructions in this manual before using this equipment. Save this manual for future reference. Maximum user weight 250 lbs. IMPORTANT CAUTION: Adult Assembly Required Trampoline and Enclosures are susceptible to winds. Be sure to secure your trampoline and enclosure.

  • Page 2: Table Of Contents

    Model_____________ SWSAS1500 A serial decal is found on one of the trampoline legs. Model number decal tag is located on the jumping mat. CONTENTS Important Precautions...........3 Warning Label Placement........4 Before You Begin..........4 Trampoline Safety Information......5 Enclosure Safety Information.......6 Methods of Accident Prevention......7 Important Warnings..........8...

  • Page 3: Important Precautions

    USE INSTRUCTIONS WARNING: To reduce the risk of serious injury, read and follow all of the warnings, precautions, and instructions in this manual before you use the trampoline enclosure. Warnings and instructions for care, maintenance, and use of this trampoline and enclosure are included to promote safe, enjoyable use of this equipment. It is the responsibility of the owner and supervisors of the Do not attach anything to the enclosure barrier that is not a trampoline and enclosure to make sure all users obey the safety...

  • Page 4: Warning Label Placement

    BEFORE YOU BEGIN Thank you for choosing your Skywalker Trampolines brand Trampoline. Skywalker Trampoline square Trampolines are designed and crafted to provide many years of fun and fitness. This trampoline comes equipped with warnings and instructions for the assembly, care, maintenance, and use of the trampoline.

  • Page 5: Trampoline Safety Information

    TRAMPOLINE SAFETY INFORMATION In trampoline use, as in all active recreational sports, participants can be injured. However, there are steps that can be taken to reduce the risk of injury. In this section, primary accident patterns are identified and the responsibilities of supervisors and jumpers in accident prevention are described.

  • Page 6: Enclosure Safety Information

    ENCLOSURE SAFETY INFORMATION NEED FOR TRAMPOLINE ENCLOSURE SAFETY A trampoline enclosure is a recreational product. The information on this page and on pages 7-9 identify important safety precautions. The precautions are not all-inclu- sive, because an enclosure can be used in ways that this manual cannot cover completely. To prevent pinches and cuts during enclosure use, a frame pad must be installed on the trampoline (See the trampoline manufacturer’s instructions).

  • Page 7: Methods Of Accident Prevention

    METHODS OF ACCIDENT PREVENTION The Supervisor's Role in Preventing Accidents It is the responsibility of the supervisors of trampoline users to provide knowledgeable and mature supervision. They need to know and enforce all of the rules and warnings printed in this manual to minimize the likelihood of accidents and injuries.

  • Page 8: Important Warnings

    • Wear clothing that does not have drawstrings, hooks, loops or anything else that could get caught while using the trampoline/enclosure and result in entanglement or strangulation, or both. • Do not attach anything to the netting that is not a Skywalker Trampolines approved accessory or part of the of the trampoline enclosure.

  • Page 9: Use And Instructional Material

    D-ring on the jump mat and that the horizontal clips are attached to the D-rings on the enclosure netting, both during use and after use. For additional information regarding equipment, contact Skywalker Holding, LLC. For additional information regarding skill training, contact a trainer certification organization.

  • Page 10: Instructional Program And Model Lessons

    INSTRUCTIONAL PROGRAM AND MODEL LESSONS The following lessons are examples of an instructional program. They should follow a complete discussion and demonstration of body mechanics between the supervision and the student(s). See also page 11. 1. Mounting and dismounting (getting on and off)-Demonstration and practice of proper techniques. 2.
  • Page 11 Lesson 5: Seat Drop Lesson 6: Front Drop 1. Review and practice of skills already learned. 1. To save time and avoid mat (bed) burns, all students should 2. Land in a sitting position with your legs parallel to the be requested to assume the front drop position on the floor mat.

  • Page 12: Part Identification Chart

    Model No. SWSAS1500 Use below drawings to identify all the parts. Middle Tube (4 pcs) Top Tube with Socket (8 pcs) Corner Tube (4 pcs) Right Leg (4 pcs) Left Leg (4 pcs) Leg extension (8 pcs) Jumping mat (1 pc)
  • Page 13 Model No. SWSAS1500 Use below drawings to identify all the parts. Tensioning Device (3 pcs) M8x42mm Bolt (3 pcs) Ball (1 pc) Lug Bolt (5 pcs) Strap (2 pcs) Upright Ground Stake (1 pc) Volley Ball Net (1 pc) Upper Upright Pole (1 pc)

  • Page 14: Exploded Drawing And Parts List

    SWSAS1500 6 18...
  • Page 15 SWSAS1500 39 38...

  • Page 16: Ordering Replacement Parts

    SWSAS1500 Key No. Qty. Description Key No. Qty. Description Ring Top Tube with Socket Middle Tube Backbord Corner Tube Tightening Cord Right Leg Ball Left Leg M8x42mm Bolt Leg estension Tensioning Device Jumping mat Strap Frame Pad Upright Ground Stake...

  • Page 17: Assembly

    ASSEMBLY ASSEMBLY (PUTTING THE TRAMPOLINE AND ENCLOSURE TOGETHER) IMPORTANT ASSEMBLY INFORMATION • Need phillips screw driver (included with trampoline) and 2 adjustable wrenches (for putting the trampoline together). A rubber mallet is also recommended to make assembly easier. • Assembly requires two adults. Keep children away from the trampoline and enclosure until they are completely put together. •...
  • Page 18 Insert the assembled leg into two Leg Extensions(6) as shown, then secure with M6x70mm Bolt(16) , M6 Washer(19) and M6 Nut(18). Press down on both Leg Extensions(6) at the same time and fully insert them into the Socket , then secure with M6x70mm Bolt(16), M6 Washer(19) and M6 Nut(18).
  • Page 19 If the Enclosure net(9) and Jumping mat(7) are not pre-installed, follow below steps to install. Place the Jumping mat(7) on clear ground. Identify the warning label on mat top as shown. the first hole warning label warning label Place the Enclosure net(9) on the Jumping mat(7), the first V-ring make sure the first hole and the first V-ring are aligned as shown.
  • Page 20 If the Enclosure net and Jumping mat are pre-installed, follow below steps to assemble the Jumping mat to frame. 6.1 Inspect the connection of Jumping mat and Enclosure net, make sure all the V-rings are passed through the corresponding net holes. 6.2 Place the Jumping mat(7) on clear ground inside the Enclosure door frame, and then adjust the location to make sure the...
  • Page 21 Count exactly 24 spring holes and V-rings in the clockwise direction, attach the second spring in the same way as 6.3. NOTE: Count exactly the quantity of V-rings and the spring holes on frame top, make sure each of them are corresponding NOTE: There are springs around the edge of Jumping mat(7)
  • Page 22 attach a spring to the left of each spring you have placed. Continue this pattern to evenly place the springs until all springs have been placed. Note: If you place the springs one directly after the other, the tension on the springs will become uneven causing placement of the springs to become increasingly difficult.
  • Page 23 8. Look underneath the trampoline. Locate the straps Inner Straps attached to the underside of the Frame Pad. Position Strap sewn in the outside of each outer strap so that one strap is on each side of the the Joint for the pad bottom frame as shown.
  • Page 24 Follow below steps to attach Curved tube to cap Hexagon hole Holes Identify the hexagon hole on the Pole Cap(14) with a nut buried inside. Insert the Pole Cap(14) into one strap ring on the top Strap ring edge of net. Make sure the Hexagon hole side of the cap is against the net, and the holes on both the strap ring and the caps are aligned.
  • Page 25 Insert the end cap(15) into the bottom hole of the Socket as shown. Socket Using a ladder, reach to the top of the enclosure poles and tie the straps around the pole caps as shown. Make sure to secure the knot tightly. (Do not stand on the edge of the trampoline to do Strap Strap...
  • Page 26 Assembly and Attachment of Basketball Hoop Take one end of the String(21) at the top of the net, Hole and tie a knot in one of the Net(23). Weave the String(21) in and out of the holes of ring(24) to attach the Net(23) completely.
  • Page 27 19. Using a ladder to reach the top of your enclosure net, tie one end of the Tightening Cord (26) to a Pole Cap. Pull the Tightening cord tight, then attach the other end of the Tightening Cord (26) to the next closest Pole Cap. Make sure to keep the Cord pulled tight.
  • Page 28 21. Attach three Lug Bolts (32) to the side of the Upper Upright Pole (34) with three M6 Nuts (18), M6 Washers (19). Attach the Lug Bolts (32) to the other side of the Upper Upright Pole (34) with M6 Nut (18), M6 Washers (19).
  • Page 29 25-26 25. Push the Upright Ground Stake (31) into ground. Make sure the Volley Ball Net (33) is tight. 26. Attach the Upright Ground Stake (31) to Lower Upright Pole (35) with two M8 x45mm Bolts (28), two M8 Washer with Arc (38) and two M8 LockNuts (39). 27.
  • Page 30 Attachment of Bounce Back Game 29. Choose a straight edge to attach the Bounce Back Game (40) between two enclosure uprights. The ball storage pocket is at the bottom of the game. Adjust accordingly for the user’s height. Tighten the straps so the game does not sag or slip down the enclosure poles.

  • Page 31: Care And Maintenance

    WARNING TRAMPOLINE AND ENCLOSURE CARE AND MAINTENANCE Care To avoid damage to the trampoline and enclosure, do not allow pets or animals inside the enclosure. The trampoline is intended to be used by one person at a time who weighs no more than 250 pounds. The user should be either barefoot, wearing socks, or wearing gymnastic shoes.

  • Page 32: Limited Warranty

    Skywalker Holdings, LLC option, the product at one of this authorized service centers. All products for which a warranty claim is made must be received by Skywalker Holdings, LLC at one of its authorized locations. Preauthorization may be obtained by calling Skywalker Holding, LLC Customer Care Hot Line at 1-866-603-Jump(5867).
