- Page 1 ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS w w w . s i s t e m a i r . c o m TECHNICAL MANUAL BASIC BASIC...
- Page 2 (outlet pipes fi tted on the left) 14.5 Connection to the pipe network For the best results, we suggest to use SISTEM AIR original accessories and materials. The SISTEM AIR Trademark is a registered trademark and is property of TECNOPLUS S.r.l.
-
Page 3: General Information
PVC trace pipes, housed in walls or in false ceilings running through the various rooms; at the end of the pipes are positioned the suction sockets. The SISTEM AIR vacuum cleaner is usually placed in a utility room, garage or other storeroom and connected to the suction pipes network. -
Page 4: Technical Features
3- TECHNICAL FEATURES Cover Vacuum-breaker valve Connection joint Industrial Motor Filter protection Filter Vacuum installation joint Dust container release handle Handle Dust container Wheels Conveyor cone Base 06/06/2016 Rev:2.0.0... - Page 5 Industrial Clean Basic Instruction manual ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Industrial Clean BASIC BASIC LT 80 LT 160 Model Article 3400.20 3400.21 Safety vacuum-breaker valve Supply V ac 220/240 220/240 Max air fl ow (motor) 1200 Filtering surface 24000 43400...
-
Page 6: Construction Features
4 - CONSTRUCTION FEATURES The Industrial Clean Basic dust separators can be used in different contexts, thanks to their versatility and combination possibilities with the other components of the industrial central vacuum system. The dust containers are available in two versions with different capacity and can be used in both big or small industrial contexts. -
Page 7: Safety Features
Industrial Clean Basic Instruction manual ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5 - SAFETY FEATURES It is recommended to read carefully all the installation, use and maintenance instructions detailed in this manual. Furthermore, the following WARNINGS should always be observed: • Never use the machine for unauthorized purposes. -
Page 8: Authorized Use
Customer. 6 - AUTHORIZED USE The Industrial Clean Basic dust separator has been designed exclusively to vacuum clean dust, very small size solids and dry materials. The use of the dust separator is authorized in industrial contexts through connection to a wall-traced pipe network and to a standard home electrical wiring. -
Page 9: Unauthorized Use
8 - EQUIPMENT AND ACCESSORIES The packaging of the machine also includes a series of accessories as detailed below: N°1 Industrial Clean Basic dust separator N°2 rubber sleeves for the connection to the suction pipe network N°4 metal clamps to fi x the sleeves N°1 installation, use and maintenance manual... -
Page 10: Emptying The Dust Container
9 - EMPTYING THE DUST CONTAINER Use both hands to raise the release handle Remove the dust container Remove the conveyor cone and the bag-stretcher 06/06/2016 Rev:2.0.0... - Page 11 Industrial Clean Basic Instruction manual ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Tie up the dust bag and remove it from the container Introduce a new dust bag and the bag-stretcher Assemble the conveyor cone Put the dust container back in its position Use both hands to lower the clip handle 06/06/2016 Rev:2.0.0...
-
Page 12: Replacing The Filter Cartridge
10 - REPLACING THE FILTER CARTRIDGE Lift the release handle using both hands Remove the dust container Unscrew the blocking knob Replace the fi lter cartridge 06/06/2016 Rev:2.0.0... - Page 13 Industrial Clean Basic Instruction manual ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Screw the blocking knob Reassemble the dust container in its position Use both hands to lower the clip handle 06/06/2016 Rev:2.0.0...
- Page 14 10.1 Regeneration of the fi lter cartridge WARNING DO NOT USE THE VACUUM CLEANER WITHOUT THE FILTER CARTRIDGE. ENSURE YOU HAVE REPLACED A SPARE FILTER CARTRIDGE BEFORE CARRYING OUT THIS OPERATION. The fi lter cartridge can be regener- ated more times by vacuum cleaning the dirt on the fi...
-
Page 15: Spare Part
It is advisable to order in time those spare parts which need to be replaced most often. In order to guarantee the optimal and long working life of the vacuum cleaner it is recommended to use only original SISTEM AIR spare parts, as detailed below. VACUUM... -
Page 16: Installation
12 - IDEAL LOCATION OF THE VACUUM CLEANER TO REDUCE SOUND EMISSION The following suggestions and measures will help reducing the sound emissions of the vacuum cleaner: • You can use sound-absorbing materials on the two side walls if these are very close to each other; this will interrupt the sound wave and avoid resonance phenomena between the two waves which could refl... - Page 17 Industrial Clean Basic Instruction manual ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 14.3 Fixing the unit The unit does not need any special fi xing device. For a correct and safe positioning, it is however nec- essary to check that the location selected for installing the unit features the following min. requirements: - a solid, perfectly fl...
- Page 18 Disassemble the intake of the “C” suction pipe and the “D” closing plate by removing the screws. After exchanging their housings, reassemble the intake of the “C” suction pipe and the “D” closing plate by fastening the screws. Now rotate by 180° the intake of the suction pipe as shown in the picture.
- Page 19 Industrial Clean instruction manual ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 14.5 Connection to the pipe network (see fi gure) The inlets for connection to the pipe network and to the air vent pipe to the outside can be positioned both on the right side and on the left side of the control unit. The intakes for the connection to the suction pipes of the network and to the pipes exhausting the air outside...
- Page 20 F0920529 27020 Gravellona Lomellina (PV) ITALIA - Via Cilavegna, 53 - GPS: N: 45° 19’ 28” ; E: 8° 45’ 32” Tel. + 39 0381 650082 - Fax +39 0381 650120 - info@sistemair.com...
