1.1 - How to get through the User Guide correctly ................................... 2
1.2 - Safety and Security Precautions ........................................................ 2
1.3 - Identification Plate ..............................................................................3
1.4 - Technical Assistance .......................................................................... 3
2.1 - Handling and Transport ...................................................................... 4
2.2 - How to unpack the Suction Unit ......................................................... 5
2.3 - Control of the Accessories ................................................................. 6
3.1 - Operating Principles ........................................................................... 7
3.2 - Allowed and restricted Use ................................................................ 8
3.3 - Compliance with EEC Regulations in force ....................................... 8
3.4 - Security Provisions .............................................................................8
3.5 - Noise Level .................................................................................
3.6 - Construction Features ................................................................. .......... 9
3.7 - Technical Features ...........................................................................10
3.8 - Control Panel Description .................................................................11
4.1 - Safety Measures ...............................................................................12
4.2 - Place of Installation ..........................................................................12
4.3 - Installation Surface ...........................................................................12
4.4 - Installation Options ............................................................................ 12
4.5 - Wall Fitting with JOLLY BOX .................................................... ...........13
4.7 - Electrical Connection .......................................................................20
5
5.1 - Use of the Suction Unit ......................................................................21
5.2 - Starting of the Suction Unit .............................................................. 22
6
6.1 - Programmed Maintenance.................................................................23
6.2 - Dust Bag Replacement ................................................................... 24
7
7.1 - Servicing Criteria ............................................................................. 27
8.1 - Spare Parts List ............................................................................... 27
9.1 - General Provisions ......................................................................... 27
10.1 - Troubleshooting ............................................................................... 28
Jolly-Jolly Contact 01-04/01
Installation, use and maintenance guide
INDEX
1
...........8
.....................................15
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for SISTEM AIR JOLLY
Summary of Contents for SISTEM AIR JOLLY
-
Page 1: Table Of Contents
4.1 - Safety Measures ................12 4.2 - Place of Installation ................12 4.3 - Installation Surface ................12 4.4 - Installation Options ................12 4.5 - Wall Fitting with JOLLY BOX ...............13 4.6 - Wall Fitting without JOLLY BOX ........15 4.7 - Electrical Connection ...............20 How to use the Suction Unit 5.1 - Use of the Suction Unit ..............21... -
Page 2: General Information
1 - GENERAL INFORMATION 1.1 How to get through the user guide correctly The user guide of JOLLY and JOLLY CONTACT suction units is a fundamental document issued by the manufacturer, and must be considered an integral part of the suction unit. -
Page 3: Identification Plate
For any technical information you may need, call the Producer s Technical Service or Authorized Center. Always specify the technical data indicated on the identification plate as well as the serial number of the suction unit. Technical Service Provider Authorized Technical Assistance Center Jolly-Jolly Contact 01-04/01... -
Page 4: Unpacking And Handling
Considering the small size and the limited weight, no special handling/transport means are to be considered essential. If necessary, use a trolley to move the unit or ask somebody to help you. Jolly-Jolly Contact 01-04/01... -
Page 5: How To Unpack The Suction Unit
Take out all the accessories contained in the cardboard box and dispose the packing material in compliance with the relevant provisions in force. ATTENTION !: Keep the cardboard stripe. Jolly-Jolly Contact 01-04/01... -
Page 6: Control Of The Accessories
4 - N° 1 sponge for connection to JOLLY BOX casing or to air exhaust extension. 5 - N° 6 Ø 3x35 screws for fixing the suction unit to JOLLY BOX casing or to wall. 6 - N° 10 Ø 3x14 screws for fitting the frame to the suction unit. -
Page 7: Description Of The Suction Unit
To start the suction unit: Mod. JOLLY: press the start key on the control panel of the suction unit. Mod. JOLLY CONTACT: 1)Fit the coupling of the electrified hose into the special housing of the suction unit. -
Page 8: Allowed And Restricted Use
Installation, use and maintenance guide 3.2 Allowed and restricted use SISTEM-AIR suction unit models «JOLLY » and « JOLLY CONTACT » have been especially designed for wall installation to remove dust, small-sized solid bits and pieces and dry materials. The suction units have not been designed to remove textile stuffs, large-sized bits and pieces, burning and hot materials. -
Page 9: Construction Features
Installation, use and maintenance guide 3.6 Construction features (see picture) The single-phase suction units for the civil sector included in the JOLLY product line can be divided in two main categories: JOLLY Line JOLLY CONTACT Line The two product lines, equipped with the same motor power, feature the same construction technology and grant the same performances. -
Page 10: Technical Features
Installation, use and maintenance guide 3.7 Technical features (see picture and table) Jolly-Jolly Contact 01-04/01... -
Page 11: Control Panel Description
2 - START KEY (Jolly) PLUG-IN KEY (Jolly Contact) (Mod. JOLLY): Press the key: it switches on (red color) when the suction unit has been activated and the unit starts operating (Mod. JOLLY CONTACT): Press the key: it switches on (red color) when the suction unit is plugged. -
Page 12: Installation
4.4 Installation options Consider two different installation options: - wall fitting with pre-installed JOLLY BOX casing (item number 8500.0). - wall fitting without JOLLY BOX casing (finished houses). The two following paragraphs illustrate the two different installation sequences. -
Page 13: Wall Fitting With Jolly Box
Installation, use and maintenance guide 4.5 Wall fitting with pre-installed JOLLY BOX casing (item number 8500.0) (If installed) remove the protection cover of the JOLLY BOX casing by unscrewing the 6 locking screws. ( 2 ) ( 1 ) Insert the sponge (1) in the round housing (2) of the Jolly Box casing. - Page 14 Installation, use and maintenance guide Put the Jolly suction unit to the wall; use ONLY the 6 Ø 3x35 mm screws delivered with the suction unit. N°6 Ø 3 x 35 mm N°10 Ø 3 x 14 Screw the special frame to the Jolly suction unit;...
-
Page 15: Wall Fitting Without Jolly Box
Installation, use and maintenance guide Wall fitting without JOLLY BOX casing (finished houses) ATTENTION: before installing, read carefully the installation instructions detailed in paragraphs 4.1, 4.2, 4.3 and 4.4. Cut the edge of the cardboard stripe; use a pair of scissors and carefully follow the dotted line. - Page 16 Use an angle grinder (shown in the picture) to drill accurately. Make a hole in the wall for the housing of the Jolly suction unit. IMPORTANT: Depth of the housing: 15 cm Enlarge to Ø 90 the Ø 10 hole Ø...
- Page 17 Installation, use and maintenance guide Put the Jolly suction unit into the housing, position it on the wall and check the correct perpendicularity with reference to the floor. 90° 90° Use a pencil and draw the position of the six holes to be drilled for fixing the suction unit to the wall.
- Page 18 Installation, use and maintenance guide Arrange the Jolly unit in the housing and fit the extension in the Ø 90 hole by paying great attention to cable position. Fix the Jolly suction unit to the wall. N°6 Ø 3 x 35 mm Use ONLY the 6 Ø...
- Page 19 A weak click confirms the correct assembly. Arrange the dust bag container. Arrange the lower cover by positioning the two guides in the slots of the frame. Push gently the cover towards the frame until the two upper hooks engage. Jolly-Jolly Contact 01-04/01...
-
Page 20: Electrical Connection
Follow the instructions to carry out this operation correctly (see picture below). 1 - Connect the power supply cables L - N to terminals 1 and 2, as shown in picture (see below). 230V 1.5 mm 230V IPX 2 Jolly-Jolly Contact 01-04/01... -
Page 21: How To Use The Suction Unit
Fit the opposite end of the hose in the suction inlet; pay attention to the correct position of the guide between the hose and the unit. Jolly-Jolly Contact 01-04/01... -
Page 22: Starting Of The Suction Unit
(JOLLY CONTACT MODEL) The red start push-button switches on and confirms that the suction unit is plugged to the power supply. JOLLY CONTACT MODEL ONLY Move to I the switch at the end of the electrified hose. The suction unit switches on and starts hoovering. -
Page 23: Maintenance
In order to keep the system perfectly operating and to avoid possible mechanic trouble, the user must overhaul the whole system at precise time intervals. The JOLLY and JOLLY CONTACT suction units are equipped with a maintenance control system. In particular, the system indicates when the dust bag must be replaced by means of a red led assembled on the front side of the suction unit. -
Page 24: Dust Bag Replacement
6.2 Replacement of the dust bag Lift the upper cover. Stop the upper cover in open position. Press the two closing hooks of the lower cover downwards. Remove the lower cover . Detach the dust bag from the housing Jolly-Jolly Contact 01-04/01... - Page 25 Check that the dust bag does not appear under the container! Check if the bag is correctly positioned and the bag fitting perfectly suits the pipe union by gently moving the whole container perpendicularly. Jolly-Jolly Contact 01-04/01...
- Page 26 Installation, use and maintenance guide Reassemble the cover of the dust bag by fitting the two lower guides into the small cavities on the frame. Press the cover towards the frame until the two closing hooks engage. Jolly-Jolly Contact 01-04/01...
-
Page 27: Servicing
Quantity Spare Part Code Suction Unit Model Dust bag package 1 pack. 8402.0 - Jolly (5 dust bags) - Jolly Contact Motor protection 8406.0 - Jolly filter - Jolly Contact 9 - DISMANTLING AND DISPOSAL General instructions When dismantling the suction system, dispose appropriately of used parts or material, which could endanger human health or well-being as well as the environment if handled improperly. -
Page 28: Technical Problems
The start push-button of the Press the start push-button unit is not activated The electrified hose is plugged Plug correctly the electrified incorrectly (Jolly Contact only) hose in the housing The thermal relay of the motor Allow several minutes for triggers...
