ByTecnoplus
s.r.l.
CENTRAL VACUUM SYSTEMS
TECNO Style
INDEX
1 HOW TO USE THE MANUAL
2 DESCRIPTION OF THE CENTRAL VACUUM CLEANER
3 TECHNICAL DATA
4 CONSTRUCTION CHARACTERISTICS
4.1 TECNO Style MINI
4.2 TECNO Style 150/250
4.3 TECNO Style 350/450
5
SAFETY FEATURES
5.1 IP protection degree
5.2 Electrical insulation degree
5.3 Declaration of absence of dangerous substances
5.4 Fixed closure guards safety
5.5 Movable closure guards safety
5.6 Identifi cation plate
6
AUTHORIZED USE OF THE VACUUM CLEANER
7
UNAUTHORIZED USE OF THE VACUUM CLEANER
8
EQUIPMENT AND ACCESSORIES
9
INSTALLATION
9.1 Preliminary operations
9.2 Place of installation
9.3 Transport and unpacking
9.4 Positioning of the vacuum cleaning unit
9.5 Transforming DX version (outlet pipes fi tted on the right) into SX version
(outlet pipes fi tted on the left)
9.6 Fixing the system to the wall
9.7 Connection to the pipe network
9.7.1 Connection and use of the service inlet
10 STARTING THE VACUUM CLEANER
10.1 Control board
10.2 Electrical connection
11 USE OF THE VACUUM CLEANER
11.1 Switching on the vacuum cleaner
11.2 Using the vacuum cleaner
11/01/12 Rev:1.0.0
INSTRUCTION MANUAL
• Type: domestic vacuum cleaner
• Model: Tecno Style
• Revision 1.0.0
3
3
4
6
7
8
9
10
11
11
11
11
12
12
13
13
14
15
15
15
16
17
17
19
21
22
22
22
23
24
24
24
1
Advertisement
Table of Contents
Related Manuals for SISTEM AIR TECNO Style
Summary of Contents for SISTEM AIR TECNO Style
- Page 1 ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS INSTRUCTION MANUAL • Type: domestic vacuum cleaner TECNO Style • Model: Tecno Style • Revision 1.0.0 INDEX 1 HOW TO USE THE MANUAL 2 DESCRIPTION OF THE CENTRAL VACUUM CLEANER 3 TECHNICAL DATA 4 CONSTRUCTION CHARACTERISTICS 4.1 TECNO Style MINI...
- Page 2 INTRODUCTION Dear Customer, TECNOPLUS S.r.l., owner of the SISTEM AIR Trademark, would fi rst of all like to thank you for having chosen to buy TECNO Style unit, the new Tecno-Line vacuum cleaner. We are sure that the characteristics described in this manual will satisfy your needs.
-
Page 3: General Information
PVC trace pipes, housed in walls or in false ceilings running through the various rooms; at the end of the pipes suction sockets are positioned. The SISTEM AIR vacuum cleaner is usually placed in a utility room, garage or other storeroom and connected to the suction pipes’ network. -
Page 4: Technical Data
Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 3- TECHNICAL DATA Model TECNO Style 150/250/350/450 Model TECNO Style MINI Tecno Style Model Sound-absorbing dome Printed circuit board ( = mod. 350/450 = mod. MINI/150/250 Printed Circuit Board holding panel... - Page 5 TECNO Style TECNO TECNO TECNO TECNO TECNO Style MINI Style 150 Style 250 Style 350 Style 450 Model Article 3107.1TER 3110.1TER 3112.1TER 3113.1TER 3115.1TER Service inlet Air inlet Ø mm IP Protection Degree Power supply V ac 220/240 220/240 220/240...
-
Page 6: Construction Characteristics
CENTRAL VACUUM SYSTEMS 4 - CONSTRUCTION CHARACTERISTICS The Tecno Style vacuum cleaners are manufactured with plastic materials, polypropylene and ABS, in order to resist atmospheric agents. The vacuum systems have been designed and manufactured in compliance with all the criteria imposed by the current regulations and the European directives while carefully paying attention to crucial elements like performance, power and operating capacity. - Page 7 4.1 TECNO Style mod. MINI Cover Sound-absorbing dome Thermal safety sensor Motor Air exhaust Cilynder motor body Fixing plate Front sticker Main switch Dust inlet Filter cartridge Conveyor cone Closing handle and hook Dust bin 05/05/11 Rev:1.0.0...
- Page 8 Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 4.2 TECNO Style mod. 150/250 Cover Sound-absorbing dome Thermal safety sensor Air exhaust Motor Fixing plate Main switch Dust inlet Service inlet switch Gasket Cilynder motor body Service inlet Conveyor cone...
- Page 9 4.3 TECNO Style mod. 350/450 Cover Sound-absorbing dome Air exhaust Thermal safety sensor Motor Fixing plate Main switch Dust inlet Service inlet switch Gasket Cilynder motor body Service inlet Conveyor cone Filter cartridge Closing handle and hook Dust bin 05/05/11 Rev:1.0.0...
-
Page 10: Safety Features
In compliance with safety regulations detailed in the Machinery Directive 2006/42/CE (transposed into the Italian Legislation by Decree Law 17/10), in the Low Voltage Directive 2006/95/CE, and in the Electromagnetic Compatibility Directive 2004/108/CE, the TECNO Style complies with the standard established for electrical appliances for household and similar purposes EN 60335-1 (2008) and with the Regulation C EN 60335-2-2 (2011), specially conceived for vacuum cleaners for household and similar purposes with rated voltage not exceeding 250 V. - Page 11 WARNING: TECNOPLUS S.R.L. declines any form of responsibility or guarantee if the purchaser, or anyone in his stead, makes even the slightest modifi cation or adjustment to the purchased product. The unit has been designed to satisfy at best the present needs of the domestic central vacuum cleaners market, both in terms of quality and operating capacity.
- Page 12 Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 5.5 Movable closure guards safety There are no movable closure guards assembled on the appliance. Every guard assembled is considered a fi xed guard and is fastened with special screws. TECNOPLUS s.r.l. reminds you that it is absolutely forbidden to replace the screws used for the design and manufacture the appliances with screws with feature different characteristics.
- Page 13 6 - AUTHORIZED USE OF THE VACUUM CLEANER The TECNO Style vacuum cleaner has been designed exclusively to vacuum clean dust, very small-size solids and dry materials. The use of the central vacuum cleaner is authorized for household and civil uses, connected to a PVC wall-traced piping network and to a standard home electrical wiring.
-
Page 14: Equipment And Accessories
Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 8- EQUIPMENT AND ACCESSORIES Together with the unit, delivered with this instruction manual, the following accessories are supplied in the packaging as follows N°1 metal bracket to fi x the system to the wall N°2 rubber sleeves for the connection to the suction pipe network... -
Page 15: Preliminary Operations
9 - INSTALLATION - WARNING - THESE PROCEDURES MUST BE CARRIED OUT BY QUALIFIED PERSONNEL 9.1 Preliminary operations The suction system is shipped to the customer completely assembled and packed. Before switching the machine on, the following checks are advisable: •... -
Page 16: Transport And Unpacking
Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 9.3 Transport and unpacking For transport and handling always maintain the system inside its own packaging until it reaches the place of installation. If necessary, use a hand-truck or ask someone to help you. - Page 17 (outlet pipes fi tted on the left) The TECNO Style vacuum cleaners are generally supplied with suction and exhaust pipes on the right side (RIGHT version). Upon request, the system can be transformed so to have the pipe connection on the left side (LEFT version).
- Page 18 Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Remove the plate, remove the screws underneath and remove the front panel. Replace the panel on the opposite side. Replace the upper dome, position the electric cable in the special grooves...
-
Page 19: Drill The Holes
To do this follow the instructions detailed below: Trace the drilling position using the template provided (drilling template); if this has already been done, proceed to the next step. Height from the ground is detailed in the table below: TECNO Style Tecno Tecno Tecno Tecno... - Page 20 Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS Tighten the screws in the wall plugs and check that the bracket is well anchored to the wall. Hook the vacuum cleaner to the anchoring bracket by lifting it, leaning it against the wall and allowing it to slide down until it fi...
- Page 21 9.7 Connection to the piping network 1. Using the sleeve, connect the dust inlet coupling of the cyclonic vacuum cleaner, identifi ed with (A) in the picture, to the suction pipe from the piping network. 2. Using the sleeve, connect the venting air coupling of the central vacuum cleaner, identifi ed with (B), to the air exhaust pipe of the house.
-
Page 22: Control Board
Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 9.7.1 Connection to the service inlet (not available on the MINI version) 1. After lifting the closing cover, insert directly, if needed, the fl exible hose (E) in the service inlet (D), identifi... -
Page 23: Electrical Connection
10.2 Electrical connection WARNING: the electrical connection must be carried out ONLY by qualifi ed personnel. Before connecting the system to the electrical power supply check that the supply voltage corresponds to that required by the vacuum cleaner (see the identifi cation plate). The manufacturer declines any responsibility for damages to persons and/or objects due to a connection to a non-complying electric wiring. -
Page 24: Use Of The Vacuum Cleaner
11 USE OF THE VACUUM CLEANER When the TECNO Style vacuum cleaner is connected to the power supply, it can be started every time a fl exible hose is plugged into any of the suction inlet in the different rooms. -
Page 25: Maintenance
12 - MAINTENANCE BEFORE CARRYING OUT ANY MAINTENANCE OPERATION, IT IS MANDATORY TO UNPLUG THE POWER SUPPLY CABLE FROM THE POWER SUPPLY INLET. PROTECTIVE MASK AND GLOVES MUST ABSOLUTELY BE WORN 12.1 Programmed routine maintenance Maintenance should be carried out according to the effective running time of the system so to ensure effi... -
Page 26: Emptying The Dust Bin
Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 12.2 Cleaning the suction container (cylinder) Periodically clean the outside casing of the vacuum cleaner with a soft damp cloth with water and neutral soap. Important: only use water or neutral soap and water to clean the vacuum cleaner. The use of other solvents or alcohol can entail damages. - Page 27 Put the conveyor cone back in position Reassemble the dust bin inside its housing under the suction system and lock the closing handles. Switch the suction system on by pressing the ON/OFF switch. Remember to take care when emptying the bin: if there is a huge quantity of dust, make sure you do not throw away the conveyor cone.
-
Page 28: Repairs And Spare Parts
Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 13 - REPAIRS AND SPARE PARTS 13.1 Intervention criteria Any intervention on the vacuum cleaner for repairs and/or maintenance which are not expressly authorized in this manual is absolutely forbidden. Any repair for breakage or malfunctioning must be carried out by qualifi ed Technical Assistance personnel. -
Page 29: Sound Emission
14 - SOUND EMISSION A sound level measurement has been gauged by measuring the acoustic pressure and the sound level of the vacuum cleaner. The test report is held at TECNOPLUS S.r.l. headquarters. 15 - IDEAL LOCATION OF THE VACUUM CLEANER TO REDUCE SOUND EMISSION The following suggestions and measures will help reducing the sound emissions of the vacuum cleaner: •... -
Page 30: Troubleshooting
Instruction manual TECNO Style ByTecnoplus s.r.l. CENTRAL VACUUM SYSTEMS 17 - TROUBLE SHOOTING PROBLEM CAUSE SOLUTION The power cable is Connect the power cable unplugged There is no suction from any of the The micro line cable is not Connect the activation cable...
