Revolution Lift
Manual
9889 Garrymore Ln
Missoula, MT 59808
888-687-3552 | +1-406-549-0769
www.aquacreek.com
PART #: F-702RLNA-04
US PATENT NUMBER: [D507,769 S]
500 LB. [227 kg] MAXIMUM WEIGHT CAPACITY
FOR INDOOR OR OUTDOOR USE
MANDATORY
LEAVE THIS MANUAL WITH LIFT OWNER
ADA COMPLIANT
READ CAREFULLY
Check entire box and all packing materials for parts. Before beginning assembly, read the
instructions and identify parts using the fi gures and parts listed in this document.
It is critical that all parts be carefully inspected prior to installation. If any damage occurred in
transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit.
Proper installation cannot be overstressed, as an improper installation voids Aqua Creek's
warranty and may affect the safety of the user.
1
Copyright © 2020 Aqua Creek Products All Rights Reserved
Revised 1/2/20
Advertisement
Related Manuals for Aqua Creek Products F-702RLNA-04
Summary of Contents for Aqua Creek Products F-702RLNA-04
- Page 1 It is critical that all parts be carefully inspected prior to installation. If any damage occurred in transit, Aqua Creek Products, LLC must be notifi ed within three days of receipt of unit. Proper installation cannot be overstressed, as an improper installation voids Aqua Creek’s warranty and may affect the safety of the user. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20...
- Page 2 REDUCE THE RISK OF DROWNING! Supervise children at all times. No jumping or diving from the lift. Seat may be hot, use caution when entering. Keep covered when not in use. Inspect and clean before use. INDOOR BATTERY CHARGER: AMPERAGE = 0.65 FREQUENCY = 60 24 VOLT BATTERY AMPERAGE = 8 IP RATING = IPX5 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20...
-
Page 3: Table Of Contents
Revolution Assembly Instructions Troubleshooting Guide Revolution Components 1. The Revolution Main Assembly 2. Control Arm 3. Lifting Arm 4. Seat Arm 5. Footrest 6. Actuator 7. Vito Handset 8. 24V Battery Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20... - Page 4 • Anchor setbacks are based on straight pool/spa walls. Curved pool/spa walls will effect the anchor setback. [172.5cm] 68" [122 cm] 48" REQUIRED [91.4 cm] DECK CLEAR DECK 36" SPACE [30.5cm] 12" [73.7 cm] 29" [40.6 cm] 16" MIN. WATER POOL WALL FIGURE 1 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20...
-
Page 5: Anchor Installation: New Construction
TO EXISTING SLAB 10" (4" MIN. EMBED) ITEM NO. OPTION F-730RSA-S2 GURNEY 21” 32” F-706RLSS SLING SEAT 21” 24” F-734RSA SPINE BOARD 21” 34” F-705-S2 WHEELCHAIR ADAPTER 21” 34” Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20... -
Page 6: Ada Fixing Insert Installation
7. Re-install the lift into the anchor and using the 1/2 inch bolt and washer, carefully thread into the installed anchor until snug. TO PREVENT BREAKING THE FIXING BRACKET, DO NOT OVERTIGHTEN! 1/2" X 2" HEX BOLT 1/2" FLAT MAIN ASSEMBLY WASHER POST ANCHOR DECK STEP 1 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20... -
Page 7: Revolution Assembly Instructions
SHOULDER BOLT 3/8" FLAT SHOULDER BOLT WASHER 3/8" NYLOCK NUT CONTROL 5/16" NYLOCK NUT 5/16" FLAT WASHER 3/8" NYLOCK 3/8" X 2" SHOULDER BOLT LIFTING ACTUATOR STEP 2 STEP 3 Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20... -
Page 8: Control Arm
In its highest position the seat will clear a 26 inch [660mm] high wall (with the pull-out legrest. STEP 5 3/8" X 2" SHOULDER BOLT 5/16" FLAT WASHER (3) 5/16" NYLOCK NUT (2) 5/16" X 4 1/2" HEX BOLT Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20... -
Page 9: Footrest
CONTROL STEP 6 BATTERY SEAT ASSEMBLY PLASTIC SLEEVE CONTROL 1/4" FLAT WASHER 1/4" LOCK WASHER FOOTREST 1/4" X 1/2" BUTTON TUBE HEAD BOLT (ADJUSTABLE) STEP 7 Not Seated Seated Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20... - Page 10 Note: the lift will not retract if the battery is not fully charged or if the control box is not working. The emergency button only overrides the remote handset. Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20...
- Page 11 Pinch Point Locations CAUTION! PINCH POINT AREAS! Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20...
- Page 12 3M Scotch Brite™ pad. Use white epoxy paint to touch up the finish. Apply wax to protect when dry. For service and/or replacement parts, contact Aqua Creek Products Toll free: (888) 687-3552 Copyright © 2020 Aqua Creek Products All Rights Reserved...
- Page 13 24 VOLT LINAK BATTERY NN 1/4 NUT, 316 SS, NYLOCK, 1/4-20 F-UBC BATTERY/CONTROL BOX COVER BOLT, 18-8 SS, 1/2 X 2 3/4 BS 1/2 X 2 3/4 18-8 SHOULDER, 3/8-16 THREAD Copyright © 2020 Aqua Creek Products All Rights Reserved Revised 1/2/20...
- Page 14 SHALL AQUA CREEK’S LIABILITY EXCEED THE ENTIRE AMOUNT PAID TO AQUA CREEK BY THE ORIGINAL PURCHASER FOR THE FAILED OR DEFECTIVE PRODUCT. IN NO EVENT SHALL AQUA CREEK PRODUCTS, LLC BE LIABLE FOR ANY INCIDENTAL, CONSEQUENTIAL, SPECIAL, INDIRECT, PUNITIVE OR EXEMPLARY DAMAGES OR LOST PROFITS FROM ANY BREACH OF THIS LIMITED WARRANTY OR OTHERWISE.
