INSTALLATION AND OPERATION INSTRUCTIONS
MODEL: 6000TRS-AUB
AUSTRALIAN GAS ASSOCIATION APPROVED
AGA APPROVAL NUMBER 5668
THIS MANUAL MUST BE USED FOR INSTALLATION AND RETAINED
BY HOMEOWNER FOR OPERATION AND MAINTENANCE.
HEAT-N-GLO, a brand of Hearth & Home Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044, USA 1-888-427-3973
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790;586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
2022-900F 7/04
1
Advertisement
Table of Contents
Related Manuals for Heat-N-Glo 6000TRS-AUB
Summary of Contents for Heat-N-Glo 6000TRS-AUB
- Page 1 THIS MANUAL MUST BE USED FOR INSTALLATION AND RETAINED BY HOMEOWNER FOR OPERATION AND MAINTENANCE. HEAT-N-GLO, a brand of Hearth & Home Technologies Inc. 20802 Kensington Boulevard, Lakeville, MN 55044, USA 1-888-427-3973 This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;...
- Page 2 Failure to follow them will void your AS A BALANCED FLUE HEATER. warranty and may present a fire hazard. The Heat-N-Glo warranty will be voided by, and Heat- Refer to the appliance data plates for gas consump- N-Glo disclaims any responsibility for the following tions and pressures.
-
Page 3: Table Of Contents
TABLE OF CONTENTS 1.0 INSTALLATION INSTRUCTIONS................4 1.1 Locating the Heater ....................5 1.2 Framing the Heater ....................6 1.3 Flue System Approvals and Installations .............8 1.4 Connecting the Gas Supply ...................16 1.5 Fan ...........................17 1.6 Mantel Clearances ....................18 1.7 Log Placement .......................19 1.8 Installer Testing .......................21 2.0 OPERATING INSTRUCTIONS. -
Page 4: Installation Instructions
1.0 INSTALLATION INSTRUCTIONS • Whether optional accessories—devices such as a fan, wall switch, or remote control—are desired. When planning a heater installation, it’s necessary If the heater is to be installed on carpeting or tile, or on to determine: any combustible material other than wood flooring, the •... -
Page 5: Locating The Heater
1.1 Locating the Heater Rear Flue The diagram (See figure 2) shows space and clearance 1”MIN. (25mm) requirements for locating a heater within a room. Clearance Requirements The top, back, and sides of the heater are defined by stand-offs. The minimum clearance to a perpendicular wall extending past the face of the heater is one inch (25 mm). -
Page 6: Framing The Heater
Minimum Clearances from the Flue Pipe to Combustible Materials For Vertical For Horizontal Sections At Wall Firestops Sections Bottom Sides Bottom Sides 1 inch 3 inches 1 inch 1 inch 2-1/2 inches 1/2 inch 1 inch (25mm) (75mm) (25mm) (25mm) (63.7mm) (13mm) (25mm) - Page 7 T = Flue terminal M = Gas meter Shading indicates prohibited I = Mechanical air inlet P = Electricity meter or fuse box areas for flue terminals Below eaves, balconies or other projections: MIN. CLEARANCE (mm) Appliances up to 50 MJ/h input ...................... 300 Appliances over 50 MJ/h input .......................
-
Page 8: Flue System Approvals And Installations
STRAIGHT OUT HORIZONTAL FLUE SYSTEM MODEL FLUE TERMINATION APPROVALS Figure 6 shows straight out horizontal flue systems 6000TRS-AUB DVP-TRAP, DVP-TVHW approved for use on this model. TABLE 1 ELBOWS The flue systems installed on this gas heater may also FLUE SYSTEM APPROVALS AND... - Page 9 1´ MIN. (305 mm) 2´ MAX. (610 mm) 2´ MIN. (610 mm) 4´ MAX. (1.22 M) MIN. RUN MAX. RUN 3´ MIN. (914 mm) 6´ MAX. (1.86 M) 4´ MIN. (1.22 M) 8´ MAX. (2.48 M) 13.1" (331mm) 24" (610mm) 24´...
- Page 10 V FT.) H (FT.) (FT.) 1' MIN. (350mm) 2' MAX. (610mm) 4' MAX. (1.22m) 2' MIN. (610mm) 2' MAX. (610mm) 8' MAX. (2.48m) 3' MIN. (914mm) 4' MAX. (1.22m) 12' MAX. (3.72m) 4' MIN. (1.22m) 6' MAX. (1.8m) 16' MAX. (4.9m) 20' MAX.
- Page 11 FLUEING WITH THREE (3) 90° ELBOWS H + H 1´ MIN. (305 mm) 2´ MAX. (610 mm) 4´ MAX. (1.22 m) 2´ MIN. (610 mm) 4´ MAX. (1.22 m) 8´ MAX. (2.48 m) 3´ MIN. (914 mm) 6´ MAX. (1.86 m) 12´...
- Page 12 FLUEING WITH THREE (3) 90° ELBOWS V (FT.) H + H (FT.) 1' MIN. (305mm) 4' MAX. (1.22m) 2' MIN. (610mm) 8' MAX. (2.4m) 3' MIN. (914mm) 12' MAX. (3.7m) 4' MIN. (1.22m) 16' MAX. (4.9m) NOTE: H + H = 16' MAX.
- Page 13 Installing Flue Components 1. Attach the First Flue Component to the Starting Collars After determining which set of starting collars will be used To attach the first flue component to the starting col- (top or rear), follow flueing instructions accordingly. lars of the fireplace: Flueing Out the Rear Flue •...
- Page 14 WARNING: ENSURE THAT THE HEATER GASKET 4. Install Firestops SUPPLIED WITH THE HEATER SEALS BETWEEN For Horizontal Runs - Firestops are REQUIRED on THE FIRST FLUE COMPONENT AND THE OUTER both sides of a combustible wall through which the flue HEATER WRAP.
- Page 15 C. Flue Termination 10" (254mm) 10” (254mm) For Horizontal Terminations - To attach and secure the termination to the last section of horizontal flue: • The rear flue heat shield MUST be placed one inch CHIMNEY HOLE above the top of the flue between the wall shield and the base of the termination cap.
-
Page 16: Connecting The Gas Supply
1” (25mm) 7-1/2” (192mm) GAS LINE MINIMUM ACCESS FIGURE 23. Termination Cap For Vertical Terminations - To locate the flue and install the flue sections: • Locate and mark the flue center point on the under- FIGURE 24. side of the roof, and drive a nail through the center point. -
Page 17: Fan
JUNCTION BOX NOTE: IF ANY OF THE ORIGINAL WIRE AS SUPPLIED WITH THE APPLIANCE MUST BE REPLACED, IT MUST BE REPLACED WITH TYPE FAN SPEED • C RATED WIRE. CONTROL TEMPERATURE SENSOR SWITCH SPEED CONTROL FAN WIRING DIAGRAM TEMP. SENSOR SWITCH BLUE BLUE... -
Page 18: Mantel Clearances
1.6 MANTEL CLEARANCES Clearance to a mantelpiece is 12-inches (305mm). See FINISH WALL MATERIAL MAY BE COMBUSTIBLE - TOP AND SIDES Figure 27. NON-COMBUSTIBLE BOARD TOP FRONT EDGE OF FIREPLACE NOTE: ALL DIMENSIONS ARE SHOWN IN MILLIMETERS FIGURE 28. FIGURE 27. IF JOINTS BETWEEN THE FINISHED WALLS AND THE FIREPLACE SURROUND (TOP AND SIDES) ARE SEALED, A 150°... -
Page 19: Log Placement
Log Assembly: LOG-6TRS-AUB 1.7 LOG PLACEMENT INSTRUCTIONS LOG LOCATORS TABS TABS Carefully remove the logs from the packaging. CAUTION: Logs are fragile! LOG #1 (SRV2022-701): Locate log #1 on grate with notches and push log against rear log locators. LOG #2 (SRV382-702): Locate log #2 on grate with notches. - Page 20 LOG #4 (SRV675-723): Place log #4 between log #2 and grate tab. Rest the right end on top of log #2. LOG #5 (SRV382-705): Place bottom of log #5 between the 4th and 5th grate bars and rest the top onto log #1. LOG #6 (SRV438-724): Place the "Y"...
-
Page 21: Installer Testing
1.8 INSTALLER TESTING The space heater must be tested and be operating ac- cording to manufacturers specifications prior to the in- staller leaving the site. Note: the tips of the flames should never hit the top of the firebox after the unit has warmed up. - Page 22 3\16" PIGGYBACK BLACK S2 THERMOCOUPLE CONNECTOR REMOTE SWITCH PIGTAIL ON/OFF WHITE T2 SWITCH RED T1 GAS VALVE THERMOPILE BLACK S1 OPTIONAL WALL SWITCH, THERMOSTAT OR REMOTE FIGURE 31. OPERATING CAUTIONS • DO NOT USE THIS APPLIANCE IF ANY PART • THIS APPLIANCE MAY EXHIBIT A SLIGHT CAR- BON DEPOSITION.
-
Page 23: Safety And Lighting Information
2.1 SAFETY & LIGHTING INFORMATION contact your dealer or a qualified service person to re- place the injector or adjust the valve. Follow Section 2.2 SAFETY INFORMATION and 2.3 NOTE: THE TIPS OF THE FLAMES SHOULD NEVER LIGHTING INSTRUCTIONS to light the appliance. HIT THE TOP OF THE FIREBOX. -
Page 24: Lighting Instructions
LIGHTING INSTRUCTIONS LIGHTING INSTRUCTIONS 1. "STOP!" Read the safety information on previous THERMOPILE PILOT BURNER page. 2. To access controls, rotate the bottom grille down. 3. Turn the valve control knob to the "OFF" position. 6. To put the control in the pilot position, turn the To do this, you must turn the knob clockwise control knob counter-clockwise to the... -
Page 25: Fan Operation
2.4 FAN OPERATION The accessory fan is wired in series with a speed con- Visually inspect the pilot periodically. Brush or blow trol switch and a temperature sensor switch. Set the away any dust or linen accumulations. If the pilot ori- speed control to an "ON"... -
Page 26: Removal Of Covers For Servicing
REMOVAL OF COVERS FOR • Disconnect the electrode wire from the piezo ignitor (found adjacent to the gas control valve). SERVICING • Disconnect the attachment nut from the underside A. Control Compartment Grille of the thermopile. The thermopile can then be sepa- rated from the pilot bracket. -
Page 27: Troubleshooting
TROUBLESHOOTING - 6000TRS-AUB With proper installation and maintenance, your new Gas Fireplace should provide years of trouble-free service. If you do experience a problem, refer to the Troubleshooting Guide below. This guide will assist a qualified service person in the diagnosis of problems and the corrective action to be taken. - Page 28 CORRECTIVE ACTION SYMPTOM POSSIBLE CAUSE 3. Check thermopile with millivolt meter. Take reading at “TH- TP&TP” terminals of gas valve. Should read 325 millivolts mini- mum while holding valve knob depressed in pilot position, pilot lit, and on/off switch “OFF”. Re- place faulty thermocouple if read- ing is below specified minimum.
- Page 29 SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION C. Defective valve. 1. Turn valve knob to “ON”. Place ON/OFF switch to “ON”. Check with millivolt meter at thermopile terminals. Millivolt meter should read greater than 100 m.v. If the reading is okay and the burner does not come on, replace the gas valve.
- Page 30 CORRECTIVE ACTION SYMPTOM POSSIBLE CAUSE E. Glass too loose and air tight 1. Tighten corner. gasket leaks in corners after usage. F. Bad thermopile 1. Replace if necessary. G. Improper flue cap installation. 1. Check for proper installation & freedom from debris or blockage. VI.
-
Page 31: Replacement Parts
4.0 Replacement Parts 6000TRS-AUB Exploded Parts Diagram Service Parts List on following page. Log set assembly... - Page 32 6000TRS-AUB Service Parts List IMPORTANT: When ordering, supply serial and model numbers to ensure correct service parts. ITEM PARTS PART NUMBER Valve NG 060-522 Valve LP 060-523 Orifice NG 582-833 Orifice LP 582-818 Burner Tube 383-302A Burner Assembly NG 392-176A...
-
Page 33: Limited Warranty
3. HEAT-N-GLO will replace or repair a defective firebox or heat exchanger, at any time during the 10 years from the date of installation. The decision whether to replace the defective component shall be made at HEAT-N-GLO's sole discretion.
