Heat-N-Glo 6000TRS-CE Installer's Manual

Heat-N-Glo 6000TRS-CE Installer's Manual

Fireplace
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Model:
6000TRS-CE
WARNING:
IF THE INFORMATION IN THESE
INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT
CAUSING PROPERTY DAMAGE,
PERSONAL INJURY, OR DEATH.
-
Do not store or use petrol or other flam-
mable vapors and liquids in the vicinity of
this or any other appliance.
-
What to do if you smell gas
• Do not try to light any appliance.
• Do not touch any electrical switch.
• Do not use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions
• If you cannot reach your gas supplier,
call the fire department.
-
Installation and service must be performed
by a qualified installer or competent
person.
Printed in U.S.A. Copyright 2004
Heat-N-Glo, a brand of Hearth & Home Technologies Inc.
20802 Kensington Blvd., Lakeville, MN 55044, USA
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
READ THIS MANUAL BEFORE INSTALLING OR
OPERATING THIS APPLIANCE. THIS INSTALLERS
GUIDE MUST BE LEFT WITH APPLIANCE FOR
FUTURE REFERENCE.
WARNING: IMPROPER INSTALLATION,
ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY
OR PROPERTY DAMAGE. REFER TO
THIS MANUAL. FOR ASSISTANCE OR
ADDITIONAL INFORMATION CONSULT A
QUALIFIED INSTALLER OR
COMPETENT PERSON.
These instructions are only valid if the
following country symbol is on the appliance.
If this symbol is not present on the appliance,
it is necessary to refer to the technical
instructions which will provide the necessary
information concerning the modification of the
appliance to the conditions of use for the
country.
These instructions are valid for the following
countries: GB, IE
Please contact your Heat-N-Glo dealer with any
questions or concerns. For the number of your nearest
Heat-N-Glo dealer, please call 1-888-427-3973.
Installers Guide
0087
2049-900F 11/04

Advertisement

Table of Contents
loading

Related Manuals for Heat-N-Glo 6000TRS-CE

Summary of Contents for Heat-N-Glo 6000TRS-CE

  • Page 1 GB, IE Printed in U.S.A. Copyright 2004 Please contact your Heat-N-Glo dealer with any Heat-N-Glo, a brand of Hearth & Home Technologies Inc. questions or concerns. For the number of your nearest 20802 Kensington Blvd., Lakeville, MN 55044, USA Heat-N-Glo dealer, please call 1-888-427-3973.

  • Page 2: Safety And Warning Information

    SAFETY AND WARNING INFORMATION READ and UNDERSTAND all instructions carefully before starting the installation. FAILURE TO FOLLOW these installation instructions may result in a possible fire hazard and will void the warranty. Prior to the first firing of the fireplace, READ the Using Your Fireplace section of the Users Guide.

  • Page 3: Table Of Contents

    Installation Regulations ..........7 Table of Contents Section 2: Getting Started ..........8 Introducing the Heat-N-Glo Gas Fireplaces ....8 Pre-installation Preparation .......... 8 Section 3: Installing the Fireplace ......10 Step 1 Locating the Fireplace ........10 Step 2 Framing the Fireplace ........11 Step 3 Installing the Flue System ......

  • Page 4: Service Parts List

    6000TRS-CE Service Parts (NG, LP) Exploded Parts Diagram Beginning Manufacturing Date: 1/04 Ending Manufacturing Date: ______ 9 Log Set Assembly * Part number list on following page.
  • Page 5 (NG) Service Parts List 6000TRS-CE IMPORTANT: THIS IS DATED INFORMATION. The most current information is located on your dealers VIP site. When ordering, supply serial and model numbers to ensure correct service parts. ITEM PARTS SERIAL # PART NUMBER Junction Box...
  • Page 6 6000TRS-CE Service Parts (NG) Exploded Parts Diagram Beginning Manufacturing Date: 1-04 Ending Manufacturing Date: ______ Standing Pilot Valve Assembly ITEM DESCRIPTION SERIAL # PART NUMBER Pilot Assembly NG 529-510A Pilot Bracket 2049-105 Orifice NG (#33) 582-833 30.5 cm Flex 383-302A...

  • Page 7: Section 1: Approvals And Regulations

    Appliance Certification The Heat-N-Glo fireplace models discussed in this Installers Guide have been tested to certification standards and listed by the applicable laboratories. CERTIFICATION MODEL LABORATORY TYPE STANDARD 6000TRS-CE Advantica Gas Fireplace 90/396/EEC Approvals Regulations Installation Regulations Before installation check that local distribution conditions, nature of gas and pressure, and adjustment of the appliance are compatible.

  • Page 8: Section 2: Getting Started

    Heat-N-Glo direct flue gas fireplaces are designed to Introducing the operate with all combustion air siphoned from outside Heat-N-Glo of the building and all exhaust gases expelled to the Gas Fireplaces outside. The information contained in this Installers Guide, unless noted otherwise, applies to all models and gas control systems.
  • Page 9 (6.4 cm) GAS LINE 31-5/8” ACCESS ELECTRICAL 6-7/8” (80.3 cm) (17.5 cm) ACCESS 41” 5 ” (104.1 cm) (12.7 cm) TOP STANDOFFS CERAMIC COLLARS FIBER PAD VENT HOOD RATING PLATE/LABELS ELECTRICAL CONTROLS ACCESS ACCESS Figure 1. Diagram of the 6000TRS-CE...

  • Page 10: Section 3: Installing The Fireplace

    The minimum clearance to a perpendicular wall extending past the face of the fireplace is 7.62cm. The back of the fireplaces may be recessed into combustible construction (see Figure 3). MODEL: 6000TRS-CE RECESSED DEPTH: 54.6cm Minimum Clearances from the Fireplace to Combustible Materials Glass...

  • Page 11: Step 2 Framing The Fireplace

    Step 2 Fireplace framing can be built before or after the fireplace is set in place. Framing should be positioned Framing the to accommodate wall coverings and fireplace facing Fireplace material. The diagram below shows framing reference dimensions. CAUTION MEASURE FIREPLACE DIMENSIONS, AND VERIFY FRAMING METHODS AND WALL COVERING DETAILS, BEFORE FRAMING CONSTRUCTION BEGINS.

  • Page 12: Step 3 Installing The Flue System

    A. Flue System Approvals Step 3 Installing the These models have flue starting collars on both the top and the back of the unit. Depending upon the Flue System installation, decide which ONE set of starting collars will be used to attached the flue system. The starting collar sealing cap must remain on the starting collar NOT used.
  • Page 13 10.2cm 15.2cm 30.5cm DVP4 DVP6 DVP12 36.2cm 31.0cm 5.1cm MAX. MIN. 61.0cm 91.4cm DVP12A 121.9cm 25.1cm DVP24 45.0 26.0cm DVP45 DVP36 28.6cm 18.4cm 3.2cm TYP DVP48 21.7cm 1.3cm TYP 31.9cm NOTE: PIPES OVERLAP 32 mm AT EACH JOINT. FIGURE 6. DVP-Series Balanced Flue Component Specifications (127 mm inner pipe / 203 mm outer pipe)
  • Page 14 STRAIGHT UP VERTICAL FLUE 11.8 m MAX. Figure 7. Straight up Vertical Flue STRAIGHT OUT HORIZONTAL FLUE MIN. RUN MAX. RUN 13.1” (33.2 cm) 24" (61.0 cm) Figure 8. Straight Out Horizontal Flue...
  • Page 15 FLUE WITH ONE (1) 90 ELBOW MIN. 30.5 cm MAX. 61.0 cm MIN. 61.0 cm MAX. 1.22 m MIN. 91.4 cm MAX. 1.86 m MIN. 1.22 m MAX. 2.48 m Figure 9. MAX. 7.3 m MAX. 2.48 m Flue with One 90° Elbow FLUE WITH ONE (1) 90 ELBOW MIN.
  • Page 16 FLUE WITH TWO (2) 90° ELBOWS H + H MIN. 30.5 cm MAX. 61.0 cm MAX. 1.22 m MIN. 61.0 cm MAX. 61.0 cm MAX. 2.48 m MIN. 91.4 cm MAX. 1.22 m MAX. 3.72 m MIN. 1.22 m MAX. 1.8 m MAX.
  • Page 17 FLUE WITH TWO (2) 90° ELBOWS H + H MIN. 30.5 cm MAX. 1.22 m MIN. 61.0 cm MAX. 2.4 m MIN. 91.4 cm MAX. 3.7 m MIN. 1.22 m MAX. 4.9 m V+H+H = MAX. 11.8m = MAX. 4.9m = MAX.
  • Page 18 FLUE WITH THREE (3) 90° ELBOWS H + H MIN. 30.5 cm MAX. 61.0 cm MAX. 1.22 m MIN. 61.0 cm MAX. 1.22 m MAX. 2.48 m MIN. 91.4 cm MAX. 1.86 m MAX. 3.6 m MIN. 1.22 m MAX. 2.48 m MAX.
  • Page 19 FLUE WITH THREE (3) 90° ELBOWS H + H MIN. 30.5 cm MAX. 1.22 m MIN. 61.0 cm MAX. 2.4 m MIN. 91.4 cm MAX. 3.7 m MIN. 1.22 m MAX. 4.9 m V + V + H + H = MAX.

  • Page 20: Installing Flue Components

    B. Installing Flue Components After determining which set of starting collars will be used (top or rear), follow venting instructions accordingly. Venting Out the Rear Flue Remove the installed rear seal cap from the rear starting collars by cutting the strap at each end (See Figure 15).
  • Page 21 Installing Flue Components 1. Attaching the First Flue Component to the Starting Collars: A. On the REAR of the heater • To attach the first flue component to the starting collars on the rear of the heater make sure that the heater gasket supplied with the heater seals between the first flue component and the outer heater wrap.
  • Page 22 For Vertical Runs - The flue system must be supported every 240 cm above the heater flue outlet by wall brackets. To install support brackets for vertical runs: • Attach wall brackets to the flue pipe and secure the wall bracket to the framing members with nails or screws.
  • Page 23 10" (25.4 cm) INTERIOR WALL SHIELD 12" (30.5 cm) FIGURE 18. Flue Pipe & Firestop For Vertical Runs - One firestop is REQUIRED at the hole in each ceiling through which the flue passes. To install firestops for vertical runs that pass through ceilings: •...

  • Page 24: Flue Termination

    If the area above the ceiling is NOT an attic, position and secure the ceiling firestop on the ceiling side of the previously cut and framed hole. JOIST CEILING NAILS (4 REQUIRED) CEILING FIRESTOP FIGURE 20. Ceiling Firestop (Ceiling Side) If the area above the ceiling IS an attic, position and secure the firestop on top of the previously framed hole.
  • Page 25 • The heat shield sections will overlap to match the wall thickness (depth). The small leg in the shield rests on top of the flue to properly space it from the pipe sec- tion (see Figure 22). Interior Rear Vent Wall Shield Heat Shield 3.8 cm min.
  • Page 26 FIGURE 23 DVP Termination Cap For Vertical Terminations - To locate the flue and install the flue sections: • Locate and mark the flue centerpoint on the underside of the roof, and drive a nail through the centerpoint. • Make the outline of the roof hole around the centerpoint nail. •...
  • Page 27 WARNING: FOLLOW NA TIONAL REGULATIONS AND CODES OF PRACTICE FOR MINIMUM CLEARANCES FROM GAS TERMINALS, AND PLACEMENT OF GAS TERMINAL. NOTE This also pertains to vertical flue systems installed on the outside of the building. TERMINATION 50.8 cm VERTICAL WALL LOWEST DISCHARGE OPENING...
  • Page 28 91.4 cm below the termination cap. 3. All gravity air intakes within 91.4 cm of a termination cap must Heat-N-Glo assumes no responsibility for the improper perfor- be a minimum of 30.5 cm below the termination cap.

  • Page 29: Securing The Fireplace

    Step 4 The diagram below shows how to properly position, level, and secure the fireplace. Positioning, Leveling, and Securing the Fireplace 1. Place the fireplace into position. 2. Level the fireplace from side to side and from front to back. 3.

  • Page 30: Step 6 The Gas Supply Line

    Step 6 NOTE: Have the gas supply line installed by a qualified service technician in accordance with The Gas all building regulations. Supply Line NOTE: Before the first firing of the fireplace, the gas supply line should be purged of any trapped air. NOTE: Consult local building regulations to properly size the gas supply line leading to the (Rp 1/2”) hook-up at the unit.

  • Page 31: Step 7 Gas Pressure Requirements

    Step 7 Gas Pressure Requirements Pressure requirements for Heat-N-Glo gas fireplaces are shown in the table below. Natural Gas Propane Butane Natural Gas (G20) (G31) (G30) (G25) ______________________________________________________________ Inlet Pressure 20mbar 37 or 50mbar 30 or 50mbar 25mbar Manifold Pressure 4-8.7mbar...

  • Page 32: Step 9 Finishing

    WARNING: DO NOT CONNECT 230 V AC TO THE WALL SWITCH OR THE CONTROL VALVE WILL BE DESTROYED. LABEL ALL WIRES PRIOR T O DISCONNECTION CAUTION WHEN SERVICING CONTROLS. WIRING ER- RORS CAN CAUSE IMPROPER AND DANGER- OUS OPERATION. VERIFY PROPER OPERA- TION AFTER SERVICING.

  • Page 33: Step 10 Installing Trim, Logs & Ember Material

    CAUTION IF JOINTS BETWEEN THE FINISHED W ALLS AND THE FIREPLACE SURROUND (TOP AND SIDES) ARE SEALED, A 150° C. MINIMUM SEALANT MATERIAL MUST BE USED. THESE JOINTS ARE NOT RE- QUIRED TO BE SEALED. ONLY NONCOMBUSTIBLE MATERIAL (USING 150° C. MINIMUM ADHESIVE, IF NEEDED) CAN BE APPLIED AS FACING TO THE FIREPLACE SURROUND.

  • Page 34: Positioning The Logs

    LOG PLACEMENT INSTRUCTIONS Log Set Assembly: LOGS-6TRSCE Carefully remove the logs from the packaging. CAUTION: Logs are fragile! LOG #1 (SRV2049-700): Place log #1 at the rear of the unit against the rear grate tabs with the notches on the bottom of the log lining up with the grate bars. LOG #2 (SRV2049-701): Locate the bottom grooves of log #2 over the second and third grate bars.
  • Page 35 LOG #3 (SRV385-723): Rest log #3 on the grooves on log #1 and log #2. LOG #4 (SRV385-721): Rest log #4 in the groove on log #1 with its front next to the left side of the log grate as shown. LOG #5 (SRV385-722): Push log #5 against the grate tabs on the 5th grate bar and rest its top in the groove on log #1.

  • Page 36: Placing The Ember Material

    Placing the Ember Material Two bags of ember material are shipped with this gas fireplace. Use only a portion of each bag for the best appearance and operation. To place the ember material: • Remove latches and tension springs around the glass door. •...

  • Page 37: Step 11 Before Lighting The Fireplace

    Step 11 Before lighting the fireplace, be sure to do the Before Lighting following: the Fireplace Review safety warnings and cautions • Read the Safety and Warning Information section at the beginning of this Installers Guide. Double-check for gas leaks •...

  • Page 38: Section 4: Maintaining And Servicing Your Fireplace

    Fireplace Although the frequency of your appliance servicing and maintenance will depend on use and the type of Maintenance installation, you should have a qualified service technician perform an appliance checkup at the beginning of each heating season. See the table below for specific guidelines regarding each fireplace maintenance task.
  • Page 39 MAKE SURE THE FLAMES ARE STEADY—NOT LIFTING OR FLOATING. Figure 35. Burner Flame Patterns STANDING PILOT Figure 36. Pilot Flame Patterns...

  • Page 40: Section 5: Troubleshooting

    Standing Pilot Troubleshooting Symptom Corrective Action Possible Cause Check the spark at the electrode and 1. After repeated a. Defective ignitor pilot. If no spark and electrode wire is triggering of the red properly connected, replace the ignitor. or black piezo button, the spark Using a match, light the pilot.
  • Page 41 Corrective Action Symptom Possible Cause Check the thermopile with a millivolt 3. (Continued) meter. Take the reading at TH-TP&TP terminals of the gas valve. The meter should read 325 millivolts minimum, while holding the valve knob depressed in the pilot position, with the pilot lit, and the ON/OFF switch in the OFF position.
  • Page 42 Symptom Possible Cause Corrective Action 5. The pilot and main a. No LP in the tank Check the LP (propane) tank. Refill the burner extinguish fuel tank. while in operation. Check for gas leaks. b. Inner flue pipe leaking exhaust gases back into the system The horizontal flue cap should slope...
