Models:
7000XLS
6000XLSB
WARNING: IF THE INFORMATION
IN THESE INSTRUCTIONS IS NOT
FOLLOWED EXACTLY, A FIRE OR
EXPLOSION MAY RESULT CAUS-
ING PROPERTY DAMAGE, PER-
SONAL INJURY, OR DEATH.
Printed in U.S.A. Copyright 2000,
Heat-N-Glo, a division of Hearth Technologies Inc.
20802 Kensington Boulevard, Lakeville, MN 55044
This product is covered by one or more of the following patents: (United States) 4,112,913; 4,408,594; 4,422,426; 4,424,792; 4,520,791; 4,793,322;
4,852,548; 4,875,464; 5,000,162; 5,016,609; 5,076,254 5,191,877; 5,218,953; 5,328,356; 5,429,495; 5,452,708; 5,542,407; 5,613,487; (Australia)
543790; 586383; (Canada) 1,123,296; 1,297,746; 2,195,264; (Mexico) 97-0457; (New Zealand) 200265; or other U.S. and foreign patents pending.
GUIDE
WARNING: IMPROPER INSTALLA-
TION, ADJUSTMENT, ALTERATION,
SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR PROPERTY DAM-
AGE. REFER TO THIS MANUAL. FOR
ASSISTANCE OR ADDITIONAL INFOR-
MATION CONSULT A QUALIFIED IN-
STALLER, SERVICE AGENCY, OR THE
GAS SUPPLIER.
1. This appliance may be installed in an af-
termarket, permanently located, manufac-
tured (mobile) home, where not prohibited
by local codes.
2. This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
Please contact your Heat-N-Glo dealer for any
questions or concerns. For the number of your
nearest Heat-N-Glo dealer, please call 952-985-6000.
1
Installers Guide
Underwriters
Laboratories Listed
INSTALLERS
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Heat-N-Glo 7000XLS
Summary of Contents for Heat-N-Glo 7000XLS
- Page 1 Printed in U.S.A. Copyright 2000, Please contact your Heat-N-Glo dealer for any questions or concerns. For the number of your Heat-N-Glo, a division of Hearth Technologies Inc.
-
Page 2: Safety And Warning Information
SAFETY AND WARNING INFORMATION These units MUST use one of the vent systems READ and UNDERSTAND all instructions carefully described in the Installing the Fireplace section of before starting the installation. FAILURE TO the Installers Guide. NO OTHER vent systems or FOLLOW these installation instructions may result components MAY BE USED. -
Page 3: Table Of Contents
Appliance Certification..............8 Installation Codes ................8 High Altitude Installations ............... 8 Section 2: Getting Started ............9 Introducing the Heat-N-Glo Gas Fireplaces ........9 Pre-installation Preparation ............9 Section 3: Installing the Fireplace ........... 11 Step 1 Locating the Fireplace ..........11 Step 2 Framing the Fireplace........... -
Page 4: Section 1: Approvals And Codes
Approvals and Codes High Altitude Installations Appliance Certification Installers Guide Certification Installation Codes Heat-N-Glo Quality Systems registered by SGS ICS... -
Page 5: Section 2: Getting Started
Getting Started Introducing the Heat-N-Glo Gas Fireplaces Installers Guide Pre-install Preparation Installers Guide... -
Page 7: Section 3: Installing The Fireplace
Vertical Sections Installing the Fireplace Horizontal Sections Step 1. Locating the Fireplace At Wall Firestops Step 2. Framing the Fireplace CAUTION: MEASURE FIREPLACE DIMENSIONS AND VERIFY FRAMING METHODS AND WALL COVERING DETAILS BEFORE FRAMING. Shows center of 12” x 12” vent framing hole for rear venting. - Page 8 8 5/8” (220mm) DV-45D 35 3/4” 47 3/4” (908mm) (1.2m) 11 3/4” (298mm) 8 3/4” 5 3/4” (222mm) (146mm) DV-09D DV-12D DV-06D NOTE: PIPES OVERLAP 1-3/8 INCHES (34.93mm) AT EACH JOINT.
-
Page 9: Step 3 Installing The Vent System
DVK-01TRD 24" (610 mm) 90-DEGREE ELBOWS Installers Guide 45-DEGREE ELBOW Identifying Vent Components NOTE: 7000XLS & 6000XLSB models are not approved to use 45° elbows in corner installations. Use 90° elbows. VERTICAL TERMINATION STORM COLLAR ROOF FLASHING DVK-TVCD DVK-01D HORIZONTAL... - Page 10 VENTING WITH ONE (1) 90° ELBOW Figure 7. Venting with One 90° Elbow VENTING WITH TWO (2) H + H 90° ELBOWS 1´ MIN. (305 mm) 2´ MAX. (610 mm) 6´ MAX. (1.82m) 2´ MIN. (610 mm) 4´ MAX. (1.22 m) 12´...
- Page 11 VENTING WITH THREE (3) 90° ELBOWS H + H 1´ MIN. (305 mm) 2´ MAX. (610 mm) 6´ MAX. (1.82 m) 2´ MIN. (610 mm) 4´ MAX. (1.22 m) 12´ MAX. (3.65 m) 3´ MIN. (914 mm) 6´ MAX. (1.86 m) 18´...
-
Page 12: Installing Vent Components
B. Installing Vent Components STARTING COLLAR STOVE SEALANT BEAD FIRST VENT COMPONENT 1 INCH (25.4mm) - Page 13 CORRECT INCORRECT...
- Page 14 12" (305mm) WALL BRACKET 12" (305mm) WALL STUD 1" (25.4 mm) VENT PIPE 8 FT. (2.4m) FLUE OUTLET HEAT SHIELD TRIM HEAT SHIELD IF TOO LONG, ADD TO SHIELD IF TOO SHORT 1 INCH MIN. (25.4mm) EXTERIOR FIRESTOP INTERIOR FIRESTOP NOTE: Model DVK-01TRD does not need an exterior firestop on an exterior combustible wall.
- Page 15 JOIST CEILING NAILS (4 REQUIRED) CEILING FIRESTOP 11" (280 mm) 11" (280mm) NOTE: Keep insulation away from the vent pipe at least 1 inch (25mm). CHIMNEY HOLE NAILS (4 REQUIRED) EXISTING CEILING JOISTS FRAMING MEMBERS CEILING RAFTER CEILING CEILING FIRESTOP...
-
Page 16: Vent Termination
C. Vent Termination ROUND CAP TERMINATION PERFORATION CANNOT BE INSIDE THE WALL 7 1/2" (191mm) MINIMUM TRAPEZOID CAP TERMINATION 7 1/4" (184mm) - Page 17 openable fixed closed J or K 1 2 3 4 1 2 3 4 1 2 3 4 1 2 3 4 CAUTION: IF EXTERIOR WALLS ARE FINISHED WITH VINYL SIDING, IT IS NECESSARY TO INSTALL THE VINYL PROTECTOR KIT TO THE TOP OF THE EXTERIOR FIRESTOP (FOR ALL ROUND TERMINATION CAPS).
- Page 18 HORIZONTAL OVERHANG 2 FT. 2 FT. MIN. VERTICAL MIN. WALL LOWEST DISCHARGE OPENING TERMINATION ROOF PITCH IS X/ 12 H (MIN.) - MINIMUM HEIGHT FROM ROOF TO LOWEST DISCHARGE OPENING NOTE: This also pertains to vertical vent systems in- stalled on the outside of the building.
-
Page 19: Step
Step 4. Positioning, Leveling, and Step 5. The Gas Control System Securing the Fireplace... -
Page 20: Step 7 Gas Pressure Requirements
Step 7. Gas Pressure Requirements Step 6. The Gas Supply Line Pressure requirements for Heat-N-Glo gas fireplaces are shown in the table below. Pressure Natural Gas Propane Minimum 5.0 inches 11.0 inches Inlet Pressure w.c. w.c. Maximum Inlet 14.0 inches 14.0 inches... -
Page 21: Step 8 Wiring The Fireplace
BLACK S2 REMOTE SWITCH 3/16” PIGGYBACK CONNECTOR PIGTAIL ON/OFF WHITE T2 SWITCH GAS VALUE RED T1 THERMOPILE THERMOCOUPLE OPTIONAL WALL SWITCH, BLACK S1 THERMOSTAT OR REMOTE Step 8. Wiring the Fireplace CAUTION: DISCONNECT REMOTE CONTROLS IF AB- SENT FOR EXTENDED TIME PERIODS. THIS WILL PRE- VENT ACCIDENTAL FIREPLACE OPERATION. -
Page 22: Step 9 Finishing
CAUTION: IF JOINTS BETWEEN THE FINISHED WALLS Step 9. Finishing AND THE FIREPLACE SURROUND (TOP AND SIDES) ARE SEALED, A 300° F. MINIMUM SEALANT MATE- RIAL MUST BE USED. THESE JOINTS ARE NOT RE- QUIRED TO BE SEALED. ONLY NON-COMBUSTIBLE MATERIAL (USING 300°... -
Page 23: Step 10 Installing Trim, Logs, And Ember Material
Step 10. Installing Trim, Logs, and Ember Material CAUTION: IT IS STRONGLY RECOMMENDED THAT TRIM DOORS WITH OPTIONAL MESH SCREENS BE IN- STALLED ON PROPANE MODELS. -
Page 24: Step 11 Before Lighting The Fireplace
Step 12. Lighting the Fireplace Step 11. Before Lighting the Fireplace Installers Guide After the Installation... -
Page 25: Section 4: Maintaining And Servicing Your Fireplace
Maintaining and Servicing Your Fireplace Fireplace Maintenance 7000XLS 6000XLSB MAKE SURE THE FLAMES ARE STEADY—NOT LIFTING OR FLOATING.
