HUTTON Melrose Dining Set Assembly Instructions

List of parts in fixings pack

32 x 90mm Screws

List of parts

1 x Table Top
2 x Table Leg Sets
2 x Seat Sections
4 x Seat Legs
2 x Table Cross Brace
When assembling, loosely fix together until fully assembled then tighten all the fixings.
1. Place the table top upside down on a clean
level surface. Taking care to protect the table
top from scratching.
2. Slot in a leg set on either side making sure that
the leg braces are facing inwards.
3. Through the braces attached to the table
screw into each leg using 3 screws in each
leg.
4. Turn table the correct way up and slot the
cross brace onto the leg braces. Screw into
place through the pre-drilled holes.
5. Place seat board upside down on a clean level
surface. Taking care to protect the seat boards
from scratching.
6. Slot in a leg set on either side making sure that
the leg braces are facing inwards.
7. Through the braces attached to the legs screw
into each seat using 3 screws.

IMPORTANT CUSTOMER INFORMATION

To minimise twisting and warping all Hutton garden furniture products should only be used on firm level ground.
Softwood is a natural material which can twist and split during periods of wet/dry, hot/cold weather. If cracks do appear it is a
natural occurrence and not a fault with the product or material. The best way to treat this is to use a cloth and rub a little PVA
wood glue into the crack and once dry sand the area lightly. This will not affect the treatment of the product.
