HUTTON Six Seater Round Picnic Table Assembly Instructions

List of parts in fixings
16 x 95mm Bolts
30 x 60mm Bolts
30 x 25mm Caps
2 x Allen Keys
6 x 90mm Green Screws
6 x 50mm Green Screws
When assembling, loosely fix together until fully assembled then tighten all the bolts.
1.
First start by assembling the cross rails. Bolt one of the table supports between one long and one
short cross rail (making sure the longest points are on the outside) using 95mm bolts and caps.
(See images A,B,C,D and E)
2.
Repeat for the other two.
3.
Screw the three longer cross rail sections together through the pre-drilled holes using two 90mm
screws in each section. Now using the 50mm screws, screw in the shorter cross rails through the
pre-drilled holes into the longer sections. (See images A,B,C,D and E)
4.
Now the cross rails are assembled place the table top upside down on a flat surface taking care to
protect the table top from scratching.
5.
Carefully turn the cross rail upside down and line up the three table supports to the table blocks and
bolt on using 60mm bolts and caps provided. (We suggest having assistance from other people for
this part.)
6.
Take your seats and bolt them to the ends of the cross rails using two 95mm bolts and caps.
7.
Taking the seat legs, these are right hand and left hand depending on the position of the threaded
insert, bolt to the outside of the seat blocks using two 60mm bolts and caps.
8.
Next bolt the diagonal braces between the leg and seat base using two 60mm bolts and locating
them in the threaded inserts.
9.
Tighten all the remaining loose bolts. Turn the table over and place into position. (We suggest
having assistance from other people for this part.)
IMPORTANT CUSTOMER INFORMATION
To minimise twisting and warping all Hutton garden furniture products should only be used on firm level ground.
Softwood is a natural material which can twist and split during periods of wet/dry, hot/cold weather. If cracks do appear it is a
natural occurrence and not a fault with the product or material. The best way to treat this is to use a cloth and rub a little PVA
wood glue into the crack and once dry sand the area lightly. This will not affect the treatment of the product.
