HUTTON Cotswold Chair Assembly Instructions

List of parts in fixings
4 x 90mm Screws
4 x 80mm Screws
4 x Dowels
When assembling, loosely fix together until fully assembled then tighten all the fixings.
1. Slot in one side of the backrest into one of the leg/arm sections.
2. Place the seat onto the mid rail of the leg/arm section. Then fit the other leg/arm section to the other
end.
3. Screw through the two pre-drilled holes in the seat using the 80mm screws and repeat for the other
side.
4. Next screw through the pre-drilled holes at each side at the top of the leg/arm section into the
backrest using the 90mm screws. (Making sure the backrest is at its highest position in the mortise hole).
5. Wooden dowels are supplied to fill in the pre-drilled holes in the leg/arm sections of the chair/bench.
IMPORTANT CUSTOMER INFORMATION
To minimise twisting and warping all Hutton garden furniture products should only be used on firm level ground.
Softwood is a natural material which can twist and split during periods of wet/dry, hot/cold weather. If cracks do appear it is a
natural occurrence and not a fault with the product or material. The best way to treat this is to use a cloth and rub a little PVA
wood glue into the crack and once dry sand the area lightly. This will not affect the treatment of the product.
Church Lane, Northwood Green, Westbury-on-Severn, Gloucestershire GL14 1ND www.svw2000.co.uk/hutton
Tel: 01452 762089
Assembly Instructions
pack---
---------
Hutton Garden and Landscaping Products
Fax: 01452 760993
COT-2 / 4 / 5 / 6 – Cotswold Chair
Cotswold 4 / 5 / 6 Bench
