HUTTON Northwood Arbour Seat NA Assembly Instructions

H H UTTO UTTO
garden and landscaping products
List of parts in fixings pack
Sub Assemblies
1 x Roof Section
2 x Side Trellis Sections and
Uprights
1 x Back Trellis Section
1 x Seat
1 x Seat Back
2 x Armrests
Fixings
6 x M8 x 95 Con. Bolts
6 x M8 Con. Caps
4 x 90mm Screws
8 x Screw Cups
2 x Allen Keys 5mm
10 x 60mm Screws
4 x. Rubber Bungs
Tools required (not provided)
1 x No.2 Pozidrive Screwdriver or
a battery or electric drill with
No.2 Pozidrive bit. This makes life
easier, but is not essential
When assembling, loosely
bolt together until fully
assembled then tighten all
the bolts.
N N
Assembly Instructions
NA – Northwood Arbour Seat
Your Arbour is in six sub-assembled sections, two loose
armrests, a bag of fixings and instructions. Some basic tools
will be required to assemble the Arbour Seat.
1. On clean, level ground, assemble your Arbour Seat
horizontally on the ground.
2. Put the seat section into position between the two side
panels with the trellis flush to the outside of the arbour.
Using a 95mm bolt push through the front hole on the seat
section into the post on one side panel. Use one of the
connector caps in the relevant hole on the side panel to
fasten to the bolt loosely. Repeat for the other side.
3. Now, with help if necessary, lift this Assembly into a vertical
position with the rounded ends of the Seat facing you. This
will now be the front of your Seat.
continued overleaf
