SKYDANCE EV5 Manual

5 Channel Constant Voltage Power Repeater
Model No.: EV5
5 Channel/PWM signal input/Constant voltage output/3KV optoelectronic isolation

Features

● 12-24V constant voltage power repeater.
● 5 channel , 5A per channel .
● To receive PWM signal control.
● Power repeater in series or in parallel to expand output unlimitedly.
● Apply to RGB+CCT constant voltage LED strip or module.

Technical Parameters

Input and Output

Input voltage 12-24VDC
Input current
25.5A
Input signal
PWM
Output voltage
5 x (12-24)VDC
Output current 5CH,5A/CH
Output power
5 x (60-120)W
Output type
Constant voltage
Environment
O O
Operation temperature Ta: -30 C ~ +55 C
Case temperature ( Max. ) O
T c: +85 C
IP rating
IP20
User Manual Ver 1.0.3
LVD

Safety and EMC

EMC standard (EMC) EN301 489,EN 62479
Safety standard(LVD)
EN60950
CE,EMC,LVD

Certification

Warranty and Protection

5 years
Warranty
Protection Reverse Polarity
Weight
0 . 243k g
Net weight
Gross weight
0 . 264k g

Mechanical Structures and Installations

Power indicator
PWM input +
POWER
CH1/R PWM input -
V-
V-
V+
CH2/G PWM input -
V+
CH1
V+
CH2
CH3/B PWM input -
V+
CH3
V+
CH4
CH1
CH4/WW PWM input -
CH5
CH2
CH3
CH5/CW PWM input -
CH4
CH5
Installation rack

Wiring Diagram

Power Supply
12-24VDC
Constant Voltage
AC100-240V
POWER
V-
V-
V+
V+
CH1
V+
CH2 EV5
V+
CH3
V+
CH4
CH1
CH5
CH2
CH3
CH4
CH5
POWER
V-
V-
V+
V+
CH1
V+
CH2 EV5
V+
CH3
V+
CH4
CH1
CH5
CH2
CH3
CH4
CH5
EV 5 5 Channel Constant Voltage Power Repeater
Installation rack
107.00 mm
Power input -
Power input +
LED output +
CH1/R LED output -
CH2/G LED output -
CH3/B LED output -
CH4/WW LED output -
CH5/CW LED output -
75.00 mm
24.50 mm
V5- M
+
Power Supply
12-24VDC
Constant Voltage
AC100-240V
RGB+CCT LED strip
WW
CW
Power Supply
12-24VDC
Constant Voltage
AC100-240V
RGB+CCT LED strip
WW
CW
