  • Page 1 UNiK A Professional Power Amplif iers User Instructions This booklet contains important information concerning the proper and safe operation of your new amplifier.. Index DSP-Series DSP-4000 Made in Taiwan 02 Introduction 03 Front Panel 04 Rear Panel 5 Set Up 07 Speakon Assembly 08 Operating Modes 12 Protection...

  • Page 2: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS This symbol is intended to alert the user to the presence of This symbol is intended to alert the user of non insulated "dangerous voltage" within the product's the presence of important operating and CAUTION enclosure that may be of sufficient magnitude to constitute maintenance (servicing) instructions in the Do not open - a risk of electric shock to persons.

  • Page 3: Important Precautions

    Congratulations and thank you for purchasing DSP-4000 amplifier. This  moisture. amplifier is representation of UNiKA’s continuing commitment to produce  Do not spill water or other liquids into or on to your unit. the best and highest quality audio products at an affordable price. This amplifier is designed to provide a big impact in sound reproduction.
  • Page 4 UNiKA DSP-4000 Front Panel Introduction Rear Panel Set Up Speakon Assembly Operating Modes Protection Features Specifications DSP-4000 FRONT PANEL 6 7 8 9 10 UNiK A P R O F E S S I O N A L AU D I O...
  • Page 5 UNiKA DSP-4000 Rear Panel Introduction Front Panel Set Up Speakon Assembly Operating Modes Protection Features Specifications DSP-4000 REAR PANEL Figure 2 11. Fan Outlet Ports - Cooling air enters the amplifier through the front 15. Channel 1-2 XLR THRU Jack - These jacks are used to send a grills and exhausts through the fans.
  • Page 6 UNiKA DSP-4000 Set Up Introduction Front Panel Rear Panel Speakon Assembly Operating Modes Protection Features Specifications SET UP INPUTS - The DSP-4000 amplifier allows you to use two types of input connectors per channel, a XLR female jack for balanced connections and a 1/4”...
  • Page 7 UNiKA DSP-4000 Set Up Introduction Front Panel Rear Panel Speakon Assembly Operating Modes Protection Features Specifications BANANA PLUG: (Figure 6) When connecting your speakers to the amplifier using banana plug, be sure that the red and black caps on 1/5"...
  • Page 8 UNiKA DSP-4000 Speakon Assembly Introduction Front Panel Rear Panel Set Up Operating Modes Protection Features Specifications SPEAKON ASSEMBLY: You will need a pair of Neutrik Speakon NL4FC connectors. You will also need high-quality two or four conductor Speakon cable, a pair of needle-nosed pliers and a 1.5-mm Allen key...
  • Page 9 UNiKA DSP-4000 Operating Modes Introduction Front Panel Rear Panel Set Up Speakon Assembly Protection Features Specifications OPERATING MODES STEREO OPERATION : Page 8/ Figure 14 details an example of a typical stereo set-up. Connect your inputs into channels one and two of the amplifier.
  • Page 10 UNiKA DSP-4000 Protection Introduction Front Panel Rear Panel Set Up Speakon Assembly Operating Modes Features Specifications PROTECTION LIMITER - The DSP-4000 amplifier comes with a built in limiter. When the input signal overloads, the “CLIP LED” indicates a signal overload, at this time, the volume should be lowered to reduce distortion.

  • Page 11: Amplifier Features

    UNiKA DSP-4000 Protection Features Introduction Front Panel Rear Panel Set Up Speakon Assembly Operating Modes Specifications OPERATING VOLTAGE (AC MAINS) - On the rear panel will indicate the correct AC mains voltage. Connecting to the wrong voltage is dangerous and may damage the amplifier.

  • Page 12: Specifications

    UNiKA DSP-4000 Specifications Introduction Front Panel Rear Panel Set Up Speakon Assembly Operating Modes Protection Features SPECIFICATIONS MODEL NO. DSP-4000 Output Power: 1900W RMS Stereo. 2 ohms, 1 Khz 1% THD 1350W RMS Stereo. 4 ohms, 1 Khz 1% THD 8 ohms, 1 Khz 1% THD 800W RMS Stereo.
  • Page 13 UNiKA DSP-4000 Introduction Front Panel Rear Panel Set Up Speakon Assembly Operating Modes Protection Features Specifications page 12...
