S R
INGLE ACKMOUNT
1. Securely fasten the rackmount brackets to the NetVanta 1131 using the screws provided
with the unit. The brackets can be attached in flush mount, 2-inch mount, and mid-mount
positions (see Figure
damaging the unit when attaching the mounting brackets, use only the screws supplied with
the unit.
2. To allow proper grounding, scrape the paint from the rack around the mounting holes where
the unit will be positioned.
3. Position the unit in a stationary equipment rack either above or below the NetVanta switch.
4. Have an assistant hold the unit in position as you install two appropriate mounting bolts
through the unit's brackets and into the equipment rack.
5. Proceed to the steps given in
Front Mount
Figure 1. Rack Mounting the NetVanta 1131 Using the Brackets
D R
UAL ACKMOUNT
1. Install the dual mounting tray in a stationary equipment rack using the screws provided.
2. To allow proper grounding, scrape the paint from the rack around the mounting holes where
the tray will be positioned.
3. Position two NetVanta 1131 units side by side on the dual mounting tray lining up the holes
in the front of the units with the holes in the tabs on the front of the tray (see
Important! To avoid damaging the unit when attaching it to the dual mounting tray,
use only the screws supplied with the tray.
4. Insert the provided screws through the tabs into the units securing them with a screwdriver.
5. Proceed to the steps given in
Figure 2. Rack Mounting the NetVanta 1131 Using the Dual Mounting Tray
2
1) depending on your installation requirements. Important! To avoid
Connecting the NetVanta 1131 and the NetVanta Switch.
2-inch Mount
Connecting the NetVanta 1131 and the NetVanta Switch.
Copyright © 2014 ADTRAN, Inc. All Rights Reserved.
Mid-mount
Figure 2).
