MARTIN
®
SEATING SERIES
Studio Desk Height - 91-6009
Studio Drafting Height - 91-6008
QTY: 1
A
Base Plate & Lever
QTY: 1
F
Backrest
QTY: 4
K
Footrest Nuts
(For 91-6008 drafting height model
only)
If you have difficulty assembling your table, or need customer service
assistance, please call: Martin Universal Design, Inc. customer service
hotline at 1-313-895-0700, or email at custservmud@gmail.com. If
you need additional parts, it is not necessary to contact your dealer. Our
Customer Service Representative will forward them to you immediately.
LAFAYETTE
QTY: 1
B
*Depending on model:
-Drafting height for 91-6008
-Desk height for 91-6009.
-Bellow, only for 91-6009 (desk height)
QTY: 1
G
Seat
QTY: 4
L
1 1/4" Footrest Bolts
(For 91-6008 drafting height model
only)
IMPORTANT
QTY: 1
C
Backrest Support Bar
Note: This part [D] also has part [K]
attached to it.
QTY: 1
H
Backrest Cover
QTY: 4
M
5/8" Black Bolts for Base
Assembled 91-6008
QTY: 1
D
5-Star Base
QTY: 1
I
Footrest (for 91-6008 model only)
QTY: 2
N
1" Black Bolts for backrest
Assembled 91-6009
QTY: 5
E
Push-in Castors
QTY: 1
J
Knob
Note: This knob is attached to Part [C]
QTY: 1
O
Metal Backrest Plate
MUD2016
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Martin Universal Design LAFAYETTE SEATING Series
Summary of Contents for Martin Universal Design LAFAYETTE SEATING Series
- Page 1 IMPORTANT If you have difficulty assembling your table, or need customer service assistance, please call: Martin Universal Design, Inc. customer service hotline at 1-313-895-0700, or email at custservmud@gmail.com. If you need additional parts, it is not necessary to contact your dealer. Our Customer Service Representative will forward them to you immediately.
- Page 2 Attach Backrest Support Bar seat plate A by sliding the bar into the Place base face down and push Attach foot bar I to base plate A raised area of the seat plate (see arrow castors E in firmly. Insert cylinders using [4] 1 1/4”...
- Page 3 If properly assembled, the backrest plate and backrest Continue by taking the Backrest Cover H and placing it into support bar C should look like the above photograph. Once position onto the backside of the Backrest Plate O . NOTE: this is achieved move on to the next step.
