Kids' Dual Art Center Assembly Instructions
Parts List
A) 1 ea
Black Tray
B) 1 ea.
Wooden Dowel Rod
D) 1 ea.
Paper Roll - not pictured
E) 4 ea.
Bottom Legs
F) 4 ea.
3/16" x 2 " Bolts
G) 4 ea.
3/16" x 2 1/2" Bolt
H) 8 ea.
3/16" Flat Washer
I)
8 ea.
3/16" Wing Nut
J) 2 ea.
Brackets
K) 4 ea.
5/8" Phillip Head Screws
L) 1 ea.
Upper Easel Assembly
PLEASE NOTE:
All holes drilled to close tolerances for
maximum rigidity. It may be necessary to
tap bolts in place with a hammer.
PERIODIC RE-TIGHTENING WILL
ASSURE A STURDY PRODUCT.
I M P O R T A N T !
If you have any difficulty assembling your Kids' Dual
Art Centers or need customer service assistance,
Please call: Martin Universal Design, Inc.
Customer Service Hot Line at (313)895-0700
If you need additional parts, it is not necessary to
contact your dealer, our Customer Service Rep. will
forward them to you immediately.
Made in China
!
WARNING:
CHOKING HAZARD
Not for children under 6 years
Model # U9102
- small parts
4444 Lawton Avenue, Detroit, MI 48208 USA • Tel:(313)895-0700/Fax:(313)895-0709
Email: CustservMUD@gmail.com • visit us at www.MartinUniversalDesign.com
(F) 3/16" x 2"
Bolts
4 each
(H) 3/16"
Flat Washer
8 each
(K) 5/8" Phillip
(E) Bottom
Head Screws
Legs
4 each
4 each
(L) Upper Easel
1
(A) Black Tray
(B) Wooden
(G) 3/16" x 2-1/2 "
Bolts
4 each
(I) 3/16"
Wing Nut
8 each
Assembly
1 each
1 each
Dowel Rod
1 each
(J)
Bracket
2 each
