- Page 1 TYPE EM14-- TYPE EM15-- CyclonX Robotic Pool Cleaner Owner's Manual WARNING FOR YOUR SAFETY - For anything other than the routine cleaning and maintenance described in this manual, this product must be serviced by a pool technician who is licensed and qualified in pool equipment by the jurisdiction in which the product will be installed where such state or local requirements exist.
-
Page 2: Table Of Contents
If the original dealer does not perform warranty service, please visit www.zodiac.com.au to locate an independent service company near you. If you are unable to locate a service company, please call our After Sales Support Team at 1300 763 021. -
Page 3: Section 1. Important Safety Instructions
• Do not bury cord. Locate cord so as to prevent it from being damaged by lawn mowers, hedge trimmers and other equipment. • To reduce the risk of electrical shock, do not use the robotic cleaner or control box if the cord is worn or damaged. Contact Zodiac Customer Care Service 1300 763 021 immediately for proper servicing and replacement of the damaged cord. -
Page 4: Section 2. Getting Started
If there are missing parts or damage, contact Cycle lengths Variable programming Zodiac Technical Support: 1300 763 021 This cleaner is a double-insulated product. A double- insulated electrical appliance is one which has been designed in such a way that it does not require a safety connection to ground. -
Page 5: Connecting The Floating Cable To The Control Box
Connecting the Floating Cable to the Control Box WARNING Failure to comply with the following warnings can result in permanent injury, electrocution or drowning. PREVENT ELECTRICAL SHOCK • Keep the Control box at least 3.5 m from the edge of the pool. •... -
Page 6: Section 3. Operation
Allow enough fl oating cable for the cleaner to NOTE: Zodiac recommends no more than 3 cleaning reach the farthest point of the pool (Figure 4). cycles per week. Up to 3 cleaning cycles per week in summer means your pool will always be clean and the filter less clogged. -
Page 7: Starting The Cleaner
Starting the Cleaner • Adjust the wall climbing setting as necessary using the following guidelines: The fi rst time you use the cleaner, the cleaning surface if cleaner is climbing the wall Increase: setting is Floor and Wall slowly and stays below the waterline. After the fi... -
Page 8: Rinsing The Cleaner
Hold the cleaner vertically over the pool surface Cleaning the Filter Canister to drain water before removing (Figure 6). WARNING To avoid electric shock and other hazards which could result in permanent injury or death, disconnect (unplug) the control box from the power source before performing any cleaning and maintenance. -
Page 9: Storing The Cleaner
Grasp the handle and lift up to remove the fi lter Using a hose with clean water, rinse the fi lter canister (Figure 8). canister and lid to remove all debris (Figure 10). Figure 10. Rinse the Filter Canister Figure 8. Remove the Filter Canister Let the lid and fi... -
Page 10: Section 4. Maintenance
(even if the bristle wear is not even). Zodiac Group Australia Pty Ltd recommends that you replace the brushes every two (2) years. Figure 12. Correct Floating Cable... -
Page 11: Replacing The Track
Position the new brush matt underneath the Replacing the Track roller with the bristles facing downwards. Refer Stand the cleaner on its side (Figure 19). to Figure 16. Figure 19. Stand Cleaner on its Side Figure 16. Position the New Brush on Roller Starting at one of the wheels, pull on the inside Thread each tab into the slot provided and of the track to separate the tire lip from the... -
Page 12: Section 5. Troubleshooting
Unplug the fl oating cable from the LED fl ashes once into the Control box correctly. Control box and reconnect. If the problem persists, contact Zodiac After Sales Support at 1300 763 021 2 Flashes Cleaner wheels may be jammed Turn cleaner wheels to ensure LED fl... -
Page 13: General Troubleshooting
Remove cleaner from the pool. Press power button begin a new cycle. OFF, then begin a new cycle. Propeller may be jammed and not Remove cleaner from the pool. Contact Zodiac After turning correctly. Sales Support at 1300 763 021. Wheels may be jammed and not turn- Remove cleaner from the pool. -
Page 14: Section 6. Conformity
Although the robotic pool cleaners have been tested in a large variety of swimming pools, Zodiac cannot guarantee that this robotic pool cleaner will be compatible with all pools. Some pool features may affect performance. For further advice, please contact your Zodiac dealer. - Page 15 NOTES H0446500_REVB...
- Page 16 Wetherill Park NSW 2164, Australia 1300 763 021 | www.zodiac.com.au ZODIAC ® is a registered trademark of Zodiac International, S.A.S.U, used under license. All other trademarks used herein are the property of their respective owners. ©2015 Zodiac Pool Systems, Inc. H0446500 RevB...
