BOXLIGHT CP-634i User Manual

Multimedia lcd projector
Hide thumbs Also See for CP-634i:
Table of Contents

Advertisement

Quick Links

Download this manual
Multimedia LCD Projector
CP-634i
USER'S MANUAL
Please read this user's manual thoroughly to ensure correct usage through understanding.
BEDIENUNGSANLEITUNG
Bitte lessen Sie diese Bedienungsanleitung zugunsten der korrekten Bedienung
aufmerksam.
MANUEL D'UTILISATION
Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le
fonctionnement de l'appareil.
MANUALE D'ISTRUZIONI
Vi preghiamo voler leggere attentamente il manuale d'sitruzioni in modo tale da poter
comprendere quanto riportato ai fini di un corretto utilizzo del proiettore.
MANUAL DE USUARIO
Lea cuidadosamente este manual del usuario para poder utilizar corretamente el
producto.
GEBRUIKSAANWIJIZING
Lees voor het qebruik alstublieft deze handleiding aandachtig door, om volledig profijt te
hebben van de uitgebreide mogelijkheden.
BRUKERHÅNDBOK
Vennligst les denne bruksanvisningen grundig for å være garantert driftssikker bruk.
INSTRUÇÕES DO PROPRIETÁRIO
Para assegurar o uso correto do equipamento, por favor leia atentamente este manual do
usuário.
TECHNICAL
REGULATORY NOTICES

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CP-634i and is the answer not in the manual?

Questions and answers

Related Manuals for BOXLIGHT CP-634i

Summary of Contents for BOXLIGHT CP-634i

  • Page 1 Multimedia LCD Projector CP-634i USER'S MANUAL Please read this user's manual thoroughly to ensure correct usage through understanding. BEDIENUNGSANLEITUNG Bitte lessen Sie diese Bedienungsanleitung zugunsten der korrekten Bedienung aufmerksam. MANUEL D'UTILISATION Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le fonctionnement de l'appareil.

  • Page 2: Table Of Contents

    Multimedia LCD Projector USER'S MANUAL USER'S MANUAL Thank you for purchasing this LCD projector. WARNING • Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference.

  • Page 3: Features

    BEFORE USE BEFORE USE Contents of Package Make sure all of the following items are included in the package. If anything is missing, please contact BOXLIGHT at 800-762-5757 or 360-779-7901. • NOTE Keep the original packing material for future reshipment.

  • Page 4: Part Names

    Part Names Speaker Zoom Knob Focus Ring Handle Hook Remote Control Sensor Power Switch Lens AC Inlet Lens Cap (to the Power Cord) Foot Adjuster Ventilation Openings (Intake) FRONT/LEFT VIEW OF THE PROJECTOR Control Panel (Refer to P.9 "OPERATIONS") INPUT Button STANDBY/ON Button LAMP Indicator KEYSTONE Button...
  • Page 5 Part Names (continued) VIDEO Button VIDEO STANDBY/ON STANDBY/ON Button RGB Button KEYSTONE Button MENU SELECT Button KEYSTONE Button Used to click the left mouse button. MENU Used to operate SELECT the mouse shift POSITION Button function . RESET Button MENU RESET POSITION Used to click the right...

  • Page 6: Loading The Battery

    Loading the Battery First Loading: In original packing, the battery is installed in the battery holder of the remote controller with protection film (the transparent film some of which is inside the battery holder). Pull out the protection film to “+”...

  • Page 7: Installation

    INSTALLATION INSTALLATION Installation of the Projector and Screen Refer to the drawing and table below for determining the screen size and projection distance. The projection distances shown in the table below are for full size (800 x 600 dots). a: Distance from the projector to the screen. (±10%) Table 1.

  • Page 8: Cabling

    Cabling Refer to the table below for connecting each terminal of the projector to a device. Table 2. Cabling Function Terminal Cable RGB IN 1 RGB input RGB cable with D-sub 15-pin shrink jack RGB IN 2 and inch thread screws RGB output RGB OUT AUDIO IN 1...

  • Page 9: Power Connection

    Power Connection Use the correct power cord depending on the power outlet to be used. Connect the AC inlet of the projector to the power outlet firmly by the power cord. CAUTION • Be carful in handling the power Power cord according to instructions of the outlet accompanying manual "SAFETY INSTRUCTIONS"...

  • Page 10: Operations

    OPERATIONS OPERATIONS STANDBY/ STANDBY/ON VIDEO STANDBY/ON Button ON Button KEYSTONE POWER Indicator MENU SELECT MENU RESET POSITION MAGNIFY Zoom Knob FREEZE VOLUME MUTE AUTO BLANK Focus Ring Power Switch Lens Cap Power ON 1. Check that the power cord is connected correctly. 2.

  • Page 11: Basic Operation

    Basic Operation The basic operations shown in Table 3 is performed from the supplied remote control transmitter or the projector control panel. Items indicated by (*) may be used from the control panel. Table 3 . Basic Operation Item Description Select Input Signal ( : Press the INPUT button.
  • Page 12 Items indicated by (*) may be used from the control panel. Table 3. Basic Operation (continued) Item Description VOLUME Volume Adjustment : Press the VOLUME button. Set/Clear Mute Mode : Press the MUTE button. No sound is heard in the MUTE MUTE mode.

  • Page 13: Setup Menu

    Setup Menu The following adjustments and settings are possible when SETUP is selected at the top of the menu. Part of the Setup menu differs between RGB input and video input. Select an item with the buttons, and start operation. Use the Single menu to reduce menu size (see Table 3, MENU SELECT). SETUP INPUT IMAGE...

  • Page 14: Input Menu

    Input Menu SETUP INPUT IMAGE OPT. The following functions are available when INPUT is selected on the AUTO EXECUTE menu. Select an item with the buttons, and start or stop CANCEL VIDEO operation with the buttons. The function indicated (**) are HDTV effective on video input mode only, not on RGB input mode.

  • Page 15: Image Menu

    Image Menu SETUP INPUT IMAGE OPT. The following adjustments and settings are available when IMAGE is BLANK MIRROR selected on the menu. Select an item with the buttons, and START UP GAMMA COLOR TEMP start or stop operation with the buttons.

  • Page 16: Options Menu

    Options Menu SETUP INPUT IMAGE OPT. The following adjustments and settings are available when OPT. is VOLUME MENU COLOR selected on the menu. Select an item with the buttons, and LANGUAGE AUTO OFF start or stop operation with the buttons. SYNC ON G WHISPER Table 7.

  • Page 17: No Signal Menu

    No Signal Menu VOLUME The same adjustments and settings are available with the Image and BLANK MIRROR Options menus when the MENU button is pressed during display of the START UP MENU COLOR “NO INPUT IS DETECTED ON ***” or “SYNC IS OUT OF RANGE LANGUAGE AUTO OFF ON ***”...

  • Page 18: Maintenance

    HIGH VOLTAGE HIGH TEMPERATURE HIGH PRESSURE Contact BOXLIGHT before replacing the lamp. For the optional lamp, see the item “Optional Parts” of the Table 12. Before replacing the lamp, switch power OFF, remove the power cord from the power outlet, and wait approximately 45 minutes until the lamp has cooled.
  • Page 19 Replacing the Lamp 1. Switch the projector OFF, remove the power cord from the power outlet, and wait at least 45 minutes for the unit to cool. 2. Prepare a new lamp. 3. Check that the projector has cooled sufficiently, and gently turn it upside down.

  • Page 20: Air Filter

    Other Maintenance Maintenance Inside the Equipment For safety reasons, ensure that the equipment is cleaned and checked by BOXLIGHT once every two years. Maintaining the equipment by yourself is dangerous. Cleaning the Lens Gently wipe the lens with lens cleaning paper.

  • Page 21: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING OSD Message The messages as described below may appear on the screen at power ON. Take the appropriate measures when such messages appears. Table 9. OSD Message Message Contents The usage time of lamp will be reaching 2000 hr CHANGE THE LAMP shortly.(*2) AFTER REPLACING LAMP,...

  • Page 22: Indicators Message

    Switch power OFF, and wait for 45 minutes until the equipment Turns off /Lights red cools. Check fitting of the lamp and lamp cover, and switch power ON again. Contact BOXLIGHT if the same problem occurs again. The cooling fan is not operating. Blinks Blinks...

  • Page 23: Symptom

    Symptom Before requesting repair, consult the following chart. If the situation cannot be corrected, then contact BOXLIGHT at 800-762-5757 or 360-779-7901. Table 11. Symptom Symptom Possible cause Remedy Page The main power switch is not Turn on the main power switch.

  • Page 24: Specifications

    SPECIFICATIONS SPECIFICATIONS Table 12. Specifications Item Specification Product name Liquid crystal projector Panel size 2.3 cm (0.9 type) Liquid crystal Drive system TFT active matrix panel Pixels 480,000 pixels (800 horizontal x 600 vertical) Lens Zoom lens F=1.7 ~ 2.1 f=36.8 ~ 47.8 mm Lamp 200 W UHB Speaker...

  • Page 25: Warranty

    BOXLIGHT CORPORATION's liability for the breach of the foregoing limited warranty is limited to the repair or replacement of the Product or refund of the purchase price of the Product, at BOXLIGHT's sole option. To exercise the Purchaser's rights under the foregoing warranty, the Product must be returned at the Purchaser's sole cost and expense, to BOXLIGHT or any authorized service center provided, however, that the Product must be accompanied by a written letter explaining the problem and which includes (i) proof of purchase;...
  • Page 26 Printed in Japan *QR53221*...
