BOXLIGHT CP-300t Service Manual

Dlp projector
Hide thumbs Also See for CP-300t:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual

SERVICE MANUAL

ORIGINAL VERSION
PRODUCT CODE
1 122 094 04
MS6E CP-300t :
1 122 094 10
MS6L CP-310t :
SERVICE MANUAL
BOXLIGHT CP-300t
NOTE: Match the Chassis No. on the unit's
CP-310t
Chassis No. MS6-CP-300t00
MS6-CP-310t00
back cover with the Chassis No. in the
Service Manual.
If the Original Version Service
Manual Chassis No. does not match
the
unit's,
additional
Literature is required.You must refer to
"Notices" to the Original Service
Manual prior to servicing the unit.
REFERENCE NO.
Service
SM
5110258
