Multimedia LCD Projector CP-635i USER'S MANUAL Please read this user's manual thoroughly to ensure correct usage through understanding. BEDIENUNGSANLEITUNG Bitte lessen Sie diese Bedienungsanleitung zugunsten der korrekten Bedienung aufmerksam. MANUEL D'UTILISATION Nous vous recommandons de lire attentivement ce manuel pour bien assimiler le fonctionnement de l'appareil. -
Page 2: Table Of Contents
Multimedia LCD Projector USER'S MANUAL USER'S MANUAL Thank you for purchasing this LCD projector. WARNING • Please read the accompanying manual “SAFETY INSTRUCTIONS” and this “USER'S MANUAL” thoroughly to ensure correct usage through understanding. After reading, store this instruction manual in a safe place for future reference. -
Page 3: Features
FEATURES FEATURES This liquid crystal projector is used to project various computer signals as well as NTSC / PAL / SECAM video signals onto a screen. Little space is required for installation and large images can easily be realized. Outstanding Brightness The UHB lamp and high-efficiency optical system assure a high level of brightness. -
Page 4: Part Names
Speaker Handle Hook Power Switch AC Inlet (to the Power Cord) Ventilation Openings (Intake) FRONT/LEFT VIEW OF THE PROJECTOR Control Panel STANDBY/ON Button KEYSTONE Button Foot Adjuster Button Filter Cover Air Filter and Intake for the Cooling Fan Rear Foot Adjuster... - Page 5 • Do not place the heavy objects on the remote controller. • Do not wet the remote controller or place it on any wet object. • Do not place the remote controller close to the cooling fan of the projector. • Do not disassemble the remote controller.
-
Page 6: Loading The Battery
CAUTION • Make sure the handle is fixed before carrying the projector with the handle. If the projector should be dropped from the handle should be off, it could result in an injury, and continued use could result in fire or electrical shock. -
Page 7: Installation
• Do not install LCD projector in smoke effected environment. Smoke residue may buildup on critical parts (i.e.LCD panel, Lens Assy etc.). Angle Adjustment Use the foot adjusters on the bottom of the projector to adjust the projection angle. It is variable within 0˚ to 9˚ approximately. Foot Adjuster 1. -
Page 8: Cabling
• Before connecting, turn off to all devices to be connected, except for the USB cable. • The cables may have to be used with the core set to the projector side. Use the cables which are included with the projector or specified. -
Page 9: Power Connection
Plug & Play This projector is VESA DDC 1/2B compatible. Plug & play is possible by connecting to a computer that is VESA DDC (Display Data Channel) compatible. Please use this function by connecting the accessory RGB cable with RGB IN 1 terminal (DDC 1/2B compatible). -
Page 10: Operations
• Except in emergencies, follow the above-mentioned procedure for turning power off. If the projector is used improperly, it may very difficult to turn off the projector caused by heating inside the unit. And the reduction of life time of lamp and LCD panels will be caused by incorrect procedure. -
Page 11: Basic Operation
Basic Operation The basic operations shown in Table 3 is performed from the supplied remote control transmitter or the projector control panel. Items indicated by (*) may be used from the control panel. Table 3 . Basic Operation Item Select Input Signal ( RGB IN 1→RGB IN 2→... - Page 12 Items indicated by (*) may be used from the control panel. Table 3. Basic Operation (continued) Item VOLUME Volume Adjustment : Press the VOLUME Set/Clear Mute Mode : Press the MUTE button. No sound is heard in the MUTE MUTE mode. Automatic Adjustment at RGB Input : Press the AUTO button.
-
Page 13: Setup Menu
Setup Menu The following adjustments and settings are possible when SETUP is selected at the top of the menu. Part of the Setup menu differs between RGB input and video input. Select an item with the operation. Use the Single menu to reduce menu size (see Table 3, MENU SELECT). SETUP INPUT IMAGE... -
Page 14: Input Menu
Input Menu The following functions are available when INPUT is selected on the menu. Select an item with the operation with the buttons. The function indicated (**) are effective on video input mode only, not on RGB input mode. Table 5. Input Menu Item Automatic Adjustment at RGB Input: Select the EXECUTE with the button. -
Page 15: Image Menu
Image Menu The following adjustments and settings are available when IMAGE is selected on the menu. Select an item with the start or stop operation with the Table 6. Image Menu Item Select Blank Screen Color: Select color with the BLANK •... -
Page 16: Options Menu
Options Menu The following adjustments and settings are available when OPT. is selected on the menu. Select an item with the start or stop operation with the Table 7. Options Menu Item VOLUME Reduce MENU COLOR Select Menu Background Color: Select with the LANGUAGE Select Menu Display Language: Select with the Set AUTO OFF: Set 1~99 minutes with the... -
Page 17: No Signal Menu
No Signal Menu The same adjustments and settings are available with the Image and Options menus when the MENU button is pressed during display of the “NO INPUT IS DETECTED ON ***” or “SYNC IS OUT OF RANGE ON ***” message while no signal is received.Select an item with the buttons, and start or stop operation with the Table 8. -
Page 18: Maintenance
• Never use the lamp in a state where the lamp cover is removed. Lamp Life Projector lamps have a finite life. The image will become darker, and hues will become weaker, after a lamp has been used for a long period of time. -
Page 19: Replacing The Lamp
Replacing the Lamp 1. Switch the projector OFF, remove the power cord from the power outlet, and wait at least 45 minutes for the unit to cool. 2. Prepare a new lamp. 3. Check that the projector has cooled sufficiently, and gently turn it upside down. -
Page 20: Air Filter
Other Maintenance Maintenance Inside the Equipment For safety reasons, ensure that the equipment is cleaned and checked by BOXLIGHT once every two years. Maintaining the equipment by yourself is dangerous. Cleaning the Lens Gently wipe the lens with lens cleaning paper. -
Page 21: Troubleshooting
TROUBLESHOOTING TROUBLESHOOTING OSD Message The messages as described below may appear on the screen at power ON. Take the appropriate measures when such messages appears. Table 9. OSD Message Message CHANGE THE LAMP AFTER REPLACING LAMP, RESET THE LAMP TIME. CHANGE THE LAMP AFTER REPLACING LAMP, RESET THE LAMP TIME. -
Page 22: Indicators Message
Switch power OFF, and wait for 45 minutes until the equipment cools. Check fitting of the lamp and lamp cover, and switch power ON again. Contact BOXLIGHT if the same problem occurs again. The cooling fan is not operating. Switch power OFF, and wait for 20 minutes until the equipment cools. -
Page 23: Symptom
Symptom Before requesting repair, consult the following chart. If the situation cannot be corrected, then contact BOXLIGHT at 800-762-5757 or 360-779-7901. Table 11. Symptom Symptom The main power switch is not turned on. The power cord is disconnected. The power is not turned on. -
Page 24: Specifications
Optional Parts • NOTE This specifications are subject to change without notice. Specification Liquid crystal projector 2.3 cm (0.9 type) TFT active matrix 480,000 pixels (800 horizontal x 600 vertical) Zoom lens F=1.7 ~ 2.1 f=36.8 ~ 47.8 mm 200 W UHB 1.0W+1.0W (stereo) -
Page 25: Warranty
BOXLIGHT CORPORATION's liability for the breach of the foregoing limited warranty is limited to the repair or replacement of the Product or refund of the purchase price of the Product, at BOXLIGHT's sole option. To exercise the Purchaser's rights under the foregoing warranty, the Product must be returned at the Purchaser's sole cost and expense, to BOXLIGHT or any authorized service center provided, however, that the Product must be accompanied by a written letter explaining the problem and which includes (i) proof of purchase;... - Page 26 Printed in Japan *QR53221*...
