Time Guard ProgramaSTAT UFPT24 Operating Instructions Manual page 2

Change Button
sets days, hours, and minutes
and self cancelling override
Mode Selector Switch
(continuously ON,
continuously OFF, or AUTO
(timed) operation)
Indicator showing when the
ProgramaSTAT is in either
1
continuous ON mode or in a
timed ON period in Auto
mode.
General
The ProgramaSTAT combines the elements of timeswitch, floor thermostat and frostat in a single compact,
economical and stylish unit. A hinged cover hides the programme controls, but leaves access to the
thermostat dial and the button giving ON/OFF override of timer control. The Frostat protection works in
both programmed OFF periods and when set to permanent OFF for holidays. Rechargeable battery back
up is provided to retain clock and programme information in the event of a power failure.
Siting
The ProgramaSTAT should not be installed in a wet area. Further siting instructions are given in the
Thermolay cable and mat instruction leaflet.
ON
CHANGE
PROGRAM 1 2 3 4
ON OFF AUTO
HEATING ON
Contents
1 ProgramaSTAT UFPT24 (24 hour) or UFPT7 (7 day)
2 Temperature Probe
3 3.5mm fixing screws
selects clock and ON/OFF times
PROGRAM
Temperature Marker/Heating
UFPT ProgramaSTAT
with cover hinged open
24 hour digital
clock display
Programme Button
and review
Demand Indicator
Thermostat Dial
sets the floor temperature
