- Page 1 1 PLUS/PB01AP Rockchip RK3399 Elitegroup Computer Systems Co., LTD. No. 239, Sec. 2, Tiding Blvd., Neihu District, Taipei City, Taiwan (11493) Tel: 02-21621177...
- Page 2 Trademark Recogni ti on Rockchip is a registered trademark of Rockchip Electronics Co.,Ltd. Other product names used in this manual are the properties of their respective owners and are acknowledged. LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL...
- Page 3 RF emission limits governing this device. Changes or modifications not expressly approved by the system’s manufacturer could void the user’s authority to operate the equipment. LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL...
- Page 4 Information technology equipment-Immunity characteristics-Limits and methods of measurement EN 60950 Safety for information technology equipment including electrical business equipment EN 62368 Safety for information technology equipment including electrical business equipment CE marking LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL...
- Page 5 • When the system is turned OFF, a small amount of electrical current still flows. Always unplug all power, modem, and network cables from the power outlets before cleaning the system. LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL...
- Page 6 This equipment complies with FCC radiation exposure limits forth for an uncontrolled environmrnt. This equipment should be installed and operated with minimum dis- tance 20cm between the radiator & your body. LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL...
- Page 7 3. Do not expose this product to high levels of direct sunlight, high-humidity or wet conditions. 4. Do not block the air vents to this product or impede the airflow in any way. LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL...
- Page 8 Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouilieur du Canada. Software Development For Android app development details, please refer to the official Android developer web site http://developer.android.com LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL vi i...
- Page 9 Memo LIVA Q1A PLUS/ PB01AP Ultra Tiny PC USER MANUAL viii...
-
Page 10: Table Of Contents
TABLE OF CONTENTS Preface Chapter 1 Introducing the PC Introduction............1 Specifications..........2 Front and Rear I/O..........4 Side I/O.............6 Install the VESA Mount........7 Motherboard Components......9 LIVA Q1A PLUS/ PB01AP Ul tr a Ti ny PC USER MANUAL... - Page 11 Memo LIVA Q1A PLUS/ PB01AP Ul tr a Ti ny PC USER MANUAL...
-
Page 12: Introducing The Pc
USB 2.0 ports, one USB 3.1 Gen1 port, one Giga LAN connector, one HDMI 2.0 Tpye A port, one DP 1.2 port, one Micro SD card slot, one DC port, one power button. LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL... -
Page 13: Specifications
1 x DP 1.2 port • 1 x Micro SD card slot • 1 x DC port Button and LED • Power button • Power LED Light Light LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL... - Page 14 WB-24J12R Operation • Android 8.1 / LINUX(Lubuntu 18.04) System Heatsink • Heatsink Design Operation • 0~+40 Temp Dimension • 74mm x 74mm x 34.6mm Color • Black/Blue LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL...
-
Page 15: Front And Rear I/O
This is power state LED light. 3. USB 2.0 Port Connect your USB 2.0 device to this port. 4. USB 3.1 Gen1 Port Connect your USB 3.1 Gen1 device to this port. LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL... - Page 16 Network connecting. 7. DP Port You can connect the display device to the DP port. 8. 12V DC_IN Port Connect the DC_IN port to the power adapter. LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL...
-
Page 17: Side I/O
Side I/O 9. Micro SD card slot This is Micro SD card slot. 10. Security Key hole This is security key hole. LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL... -
Page 18: Install The Vesa Mount
Install the VESA Mount 1. Mount 4 screws on VESA bracket. 2. Fasten 2 screws under the case. LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL... - Page 19 3. Hold the case towards the VESA bracket and insert the screws into the holes. 4. Slide the case down until it fixed. LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL...
-
Page 20: Motherboard Components
HDMI eMMC USB3.0 USB2.0 USB2.0 PWR_BTN J1801 J1800 J1501 J1500 Note: Find J1500~1501 and J1800~1801 on the two motherboards, insert J1500~1501 into J1800~1801 correctly after their alignment. LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL... - Page 21 12. USB 2.0 Standard USB 2.0 port 13. USB 3.1 Gen1 USB 3.1 Gen1 port 14. HDMI HDMI connector 15. LAN Network connector 16. DP DP connector LIVA Q1A PLUS/ PB0 1AP Ul tr a Ti ny PC USER MANUAL...
