This Manual Must Be Read Before Operating The Equipment
Owner / Operator's Manual
LEADERS IN ICE CONTROL
Warren, Michigan 48089
800-725-8377
© Trynex International 2010
(REV000)
SP-8550
Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915
and other pending U.S. and foreign patent applications.
FOR MODELS
CUSTOMER COPY
1 — 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SnowEx SP-8550 and is the answer not in the manual?

Questions and answers

Related Manuals for Trynex SnowEx SP-8550

Summary of Contents for Trynex SnowEx SP-8550

  • Page 1 Owner / Operator’s Manual LEADERS IN ICE CONTROL FOR MODELS SP-8550 CUSTOMER COPY Warren, Michigan 48089 Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915 and other pending U.S. and foreign patent applications. 800-725-8377 1 — 1 © Trynex International 2010 (REV000)

  • Page 2: Table Of Contents

    Warranty ....................34 Have a question or need assistance? SnowEx Customer Service (800) 725-8377 or (586) 756-6555 Monday through Friday 8:00 AM to 4:30 PM EST Fax: (586) 427-0552 E-Mail: customercare@trynexfactory.com Website: www.snowexproducts.com 1 — 2 © Trynex International 2010...

  • Page 3: Introduction

    Information that, if not carefully followed, can cause death! (ORANGE) Information that, if not carefully followed, can cause serious personal injury or death! (YELLOW) Information that, if not carefully followed, can cause minor injury or damage to equipment. © Trynex International 2010 1 — 3...
  • Page 4 The spreader you have purchased is an example of snow and ice control technology at its nest! Your spreader’s innovative, self-contained design is a trademark of all Trynex products. Here’s why... SIMPLICITY: Fewer moving parts manufactured of higher quality means minimal maintenance for your SnowEx spreader.
  • Page 5 For your safety warning and information decals have been placed on this product to remind the operator of safety precautions . If anything happens to mark or destroy the decals, please request new ones from Trynex, International. Unit must be strapped down and locked into position before operating vehicle.

  • Page 6: Safety Information

    Before working with the spreader, secure all loose tting clothing and unrestrained hair. Always wear safety glasses with side shields when servicing spreader. Failure to do this could result in serious injury to the eyes. 1 — 6 © Trynex International 2010...
  • Page 7 Safety and Warning Labels Model # SP-8550 SERIAL NUMBER ON REVERSE SIDE D 6546 D 6859 D 6545 D 6544 D 6335 D 6548 © Trynex International 2010 1 — 7...

  • Page 8: Blank

    THIS PAGE INTENTIONALLY LEFT BLANK 1 — 8 © Trynex International 2010...
  • Page 9 THIS PAGE INTENTIONALLY LEFT BLANK 1 — 9 © Trynex International 2010...
  • Page 10 Auger Drive Assembly Parts Breakdown Model # SP-8550 1 — 10 © Trynex International 2010...
  • Page 11 D 5341 31:1 i s s r o t r e l With Locking Hex Bolt i r a " 6 Auger Shaft Hopper Washer Auger Shaft Hopper Collar © Trynex International 2010 1 — 11...
  • Page 12 Spinner Drive Assembly Parts Breakdown Model # SP-8550 © Trynex International 2010 1 — 12...
  • Page 13 Spinner Hub Weldment D 6824 1/4” Nylox Nut Zinc D 4289 5/16-18 x 1/2 Hex Head D 6133 Tubular Spinner Guard D 5347 Urethane Spinner D 6823 D 6854 1/4-20 x 1 Serrated Flange © Trynex International 2010 1 — 13...
  • Page 14 Hopper Assembly Parts Breakdown Model # SP-8550 1 — 14 © Trynex International 2010...
  • Page 15 Flat Washer " 6 Rear Top Screen t l o r o t e l f " 5 f l e l i r r e l t a l Front Top Screen 1 — 15 © Trynex International 2010...
  • Page 16 Frame Assembly Parts Breakdown Model # SP-8550 © Trynex International 2010 1 — 16...
  • Page 17 Frame Assembly Parts Breakdown Model # SP-8550 . y t - " " 1 t l o l i a " 8 " 1 t l o t f e 5350 © Trynex International 2010 1 — 17...

  • Page 18: Wiring Instructions

    Step 7: Push the ON/OFF button on the controller to check for power ; when that has been con rmed turn power OFF. The electrical portion of the installation is complete. 1 — 18 © Trynex International 2010...
  • Page 19 4) Any repairs to wiring harness must be done with heat shrink butt connectors. D6354 Vibrator Switch | 3 Terminal Red D6784 Utility Work Light D6785 Light Kit Spreader Harness D6786 Light Kit Vehicle Harness © Trynex International 2011 (REV 001)
  • Page 20 D 6840 100 AMP Resetable Breaker 1 Connect to control mating half * NOTE: A) Leads must only be attached to battery. B) 100 Amp breaker must be inserted. Leads for Work Light L1218 © Trynex International 2009 MAX — 20...
  • Page 21 Red Positive (+) Yellow Positive (+) VIBRATOR AUGER Green Negative (–) Black Negative (–) MAIN POWER PLUG SPREADER Yellow Positive (+) Orange Negative (–) Green Negative (–) Blue Positive (+) VIBRATOR SPINNER POWER PLUG POWER PLUG © Trynex International 2010 1— 21...
  • Page 22 SPINNER OUTPUT Black Negative (–) Blue Positive (+) SPINNER OUTPUT SPINNER Orange Negative (–) AUGER Blue Positive (+) Red Positive (+) SPINNER Orange Negative (–) * NOTE: Reference Bumper Plug for Color Code © Trynex International 2010 1 — 22...
  • Page 23 CHMSL Spreader Harness (installed on Spreader from factory) Part No. Description Qty. D 6158 #10 Lock Nut D 6514 CHMSL Spreader Harness D 6529 #10 Black Oxide Screw CONNECT TO SPREADER LIGHT HARNESS 2-CONDUCTOR PLUG © Trynex International 2010 1 — 26...
  • Page 24 " 2 D 4121 3/8 - 16 x 1" Hex Bolt " 8 D 6536 Adj. Stop Bracket RT D 6537 Adj. Stop Bracket LT Bungie Straps (13 Per Pkg) © Trynex International 2009 L1159 VM4 — 23...
  • Page 25 Step 9: Connect the spreader power cord to vehicle main power plug mounted at rear of vehicle (see electrical installation). Step 10: Connect Center High Mount Stop Lamp (CHMSL) cord from the spreader to mating half attached to vehicle (See electrical installation). 1 — 24 © Trynex International 2010...
  • Page 26 THIS PAGE INTENTIONALLY LEFT BLANK © Trynex International 2010 1 — 25...
  • Page 27 • If you are using a sand/salt mixture, remove ba e extension. Part No. Description Qty. D 6847 Salt Ba e Extension D 6807 Discharge Ba e D 6874 #14 x 1-1/2" TEK w/Neo Washer 1 — 26 © Trynex International 2010...
  • Page 28 • The Vibrator Switch is needed for dense material or to increase the ow to the auger. This eliminates bridging of material in hopper. • In case spreader becomes jammed, it will go into an auto-reverse program to free itself. Auger display will show (AR) while trying to clear obstruction. 1 — 27 © Trynex International 2010...
  • Page 29 • You may repeat Steps 1 & 2 for a second and third time. • If after the third try the controller displays “OL” — you must extract the material that is causing the problem. • Follow all warning directions when clearing jams. 1 — 28 © Trynex International 2010...
  • Page 30 Motor is not getting power. Turn . Check all connections. display shows EO. Audible alarm beeping Vehicle battery is extremely low, Turn . Charge battery. display shows LB. or a poor connection exists. © Trynex International 2010 1 — 29...
  • Page 31 BAD CONTROLLER LIGHTS NO DISPLAY TO BLUE WIRE CHECK WITH TEST KIT NOTHING HAPPENS BAD CONTROLLER NO DISPLAY CHECK POWER SOURCE ON/OFF SWITCH WILL TO CONTROLLER CHECK WITH TEST KIT NOT LIGHT UP © Trynex International 2010 1 — 30...
  • Page 32 SPREADER POWER CORD POLARITY CORRECT CHECK CONNECTIONS TURN ON AUGER RUNS REPLACE SPREADER AT AUGER MOTOR VIBRATOR BACKWARDS HARNESS FOR REVERSE POLARITY SLOW TURN ON MATERIAL VIBRATOR FLOW INCREASE AUGER SPEED MATERIAL ISSUE © Trynex International 2010 1 — 31...

  • Page 33: Spreader Maintenance

    CAUTION – Vibrator is not designed for continuous duty. Allow motor to cool between long cycle times. • CAUTION – Do not modify vehicle or spreader wiring harness. Doing so will void product warranty. 1 — 32 © Trynex International 2010...
  • Page 34 5/8-11 3/4-10 7/8-9 Metric Grade 8.8 (ft.-lb.) SIZE TORQUE SIZE TORQUE M 12 M 14 M 10 M 16 These torque values apply to mount assembly fasteners except those noted in the instruction. © Trynex International 2010 1 — 33...

  • Page 35: Warranty

    Neither Trynex, nor any company a liated with it, makes any warranties, representations for promise as to the performance or quality other than what is herein contained. The liability of Trynex to the purchaser for damages arising out of the manufacture, sale, delivery, use or resale of this spreader shall be limited to and shall not exceed the costs of repair or replacement of defective parts.
