Trynex SnowEx SP-9500 Owner's/Operator's Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
This Manual Must Be Read Before Operating The Equipment
Owner / Operator's Manual
Warren, Michigan 48089
800-725-8377
800-725-8377
800-725-8377
© Trynex International 20
© Trynex International 2009
(REV 008)
Spreaders for Snow & Ice Control
L1185
Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915
and other pending U.S. and foreign patent applications.
FOR MODEL
SP-9500
CUSTOMER COPY
5 — 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the SnowEx SP-9500 and is the answer not in the manual?

Questions and answers

Related Manuals for Trynex SnowEx SP-9500

Summary of Contents for Trynex SnowEx SP-9500

  • Page 1 FOR MODEL SP-9500 CUSTOMER COPY Warren, Michigan 48089 Protected by the following patents, #6,089,478, #6,088,865, #Des.425,915 and other pending U.S. and foreign patent applications. 800-725-8377 800-725-8377 800-725-8377 © Trynex International 2009 © Trynex International 20 L1185 (REV 008) 5 — 1...

  • Page 2: Table Of Contents

    Warranty ..................38 - 39 Have a question or need assistance? SnowEx Customer Service (800) 725-8377 or (586) 756-6555 Monday through Friday 8:00 AM to 4:30 PM EST Fax: (586) 427-0552 E-Mail: customercare@trynexfactory.com Website: www.snowexproducts.com 5 — 2 © Trynex International 2009 L1185...

  • Page 3: Introduction

    (ORANGE) Information that, if not carefully followed, can cause serious personal injury or death! (YELLOW) Information that, if not carefully followed, can cause minor injury or damage to equipment. © Trynex International 2009 L1185 5 — 3...
  • Page 4 The spreader you have purchased is an example of snow and ice control technology at its nest! Your spreader’s innovative, self-contained design is a trademark of all Trynex products. Here’s why... SIMPLICITY: Fewer moving parts manufactured of higher quality means minimal maintenance for your SnowEx spreader.
  • Page 5 For your safety warning and information decals have been placed on this product to remind the operator of safety precautions . If anything happens to mark or destroy the decals, please request new ones from Trynex, International. Unit must be strapped down and locked into position before operating vehicle.

  • Page 6: Safety Information

    Before working with the spreader, secure all loose tting clothing and unrestrained hair. Always wear safety glasses with side shields when servicing spreader. Failure to do this could result in serious injury to the eyes. 5 — 6 L1185 © Trynex International 2009...
  • Page 7 Safety and Warning Labels Model # SP-9500 SERIAL NUMBER ON REVERSE SIDE D 6546 D 6859 D 6545 D 6544 D 6335 D 6548 © Trynex International 2009 L1185 5 — 7...
  • Page 8 Component Assembly Views Model # SP-9500 Spinner Drive Auger Drive Assembly Assembly Electrical System Assembly Hopper Frame Assembly Assembly 5 — 8 L1185 © Trynex International 2009...
  • Page 9 Side and Bottom Views Model # SP-9500 © Trynex International 2009 L1185 5 — 9...
  • Page 10 Auger Drive Assembly Parts Breakdown Model # SP-9500 5 — 10 L1185 © Trynex International 2009...
  • Page 11 D6877 #8 x 3/4” Driller With R-M Washer D6868 Auger Motor Cover D6576 5/16-18 x 1-1/4 Hex Head Bolt D6789 Auger Shaft Hopper Washer D6868 Auger Shaft Hopper Collar Auger Drive Assembly © Trynex International 2009 L1185 5 — 11...
  • Page 12 Spinner Drive Assembly Parts Breakdown Model # SP-9500 5 — 12 L1185 © Trynex International 2009...
  • Page 13 Spinner Hub Weldment D6891 1/4” Nylock Nut D4289 Heavy Duty Spinner Tubular Guard D6820 D6858 Plastic Spinner De ector Extended Plastic chute D6885 Extended Plastic Spinner Guard D6859 Complete Drive Assembly D6863 © Trynex International 2009 L1185 5 — 13...
  • Page 14 Hopper Assembly Parts Breakdown Model # SP-9500 5 — 14 L1185 © Trynex International 2009...
  • Page 15 D 6811 Inverted-V Backing Plates 3/8”-16 Nylock Nut D 4124 Heavy Duty Vibrator D 6899 D 6860 Vibrator Backing Plate D 4125 3/8” Flat Washer D 6898 Hopper Cross Bar Support Hopper Assembly © Trynex International 2009 L1185 5 — 15...
  • Page 16 Frame Assembly Parts Breakdown Model # SP-9500 5 — 16 © Trynex International 2009 L1185...
  • Page 17 9500 Frame Weldment D 6882 Upper/Lower Front Rail Auger Motor/Transmission Support D 6884 D 6880 Rear Apron With Light Hole Knock Outs D 6528 1/2”-13 x 1” Serrated Hex Head Bolt Frame Assembly © Trynex International 2008 L1185 5 — 17...

  • Page 18: Wiring Instructions

    Step 7: Push the ON/OFF button on the controller to check for power ; when that has been con rmed, turn power OFF. The electrical portion of the installation is complete. 5 — 18 L1185 © Trynex International 2009...
  • Page 19 Work light Spreader Harness D 6118 Spreader Spinner Dust Cap D 6786 Light Kit Vehicle Harness W/Switch D 6788 Amber Led Strobe Light D 6896 30’ Vehicle Harness (optional) D 6170 Anderson Connector With Leads © Trynex International 2009 L1185 5 — 19...
  • Page 20 D 6840 100 AMP Resetable Breaker 1 Connect to control mating half * NOTE: A) Leads must only be attached to battery. B) 100 Amp breaker must be inserted. Leads for Work Light L1185 © Trynex International 2009 5 — 20...
  • Page 21 Red Positive (+) Red Positive (+) VIBRATOR AUGER Black Negative (–) Black Negative (–) MAIN POWER PLUG SPREADER Positive (+) Black Negative (–) Black Negative (–) Positive (+) VIBRATOR POWER PLUG SPINNER POWER PLUG © Trynex International 2009 L1185 5 — 21...
  • Page 22 SPINNER OUTPUT Black Negative (–) Blue Positive (+) SPINNER OUTPUT SPINNER Orange Negative (–) AUGER Blue Positive (+) Red Positive (+) SPINNER Orange Negative (–) * NOTE: Reference Bumper Plug for Color Code L1185 © Trynex International 2009 5 — 22...
  • Page 23 Right Front Stop Bracket " 2 D 4116 1/2”-13 x1-1/2” Hex Bolt Flat Washer D 4121 3/8”-16 x 1” Lock Nut " 8 Tarp Bungie Tie Downs (13 Per Pkg) CROSS FRONT STRAPS AS SHOWN © Trynex International 2009 L1185 5 — 23...
  • Page 24 NOTE: (Do not use ratchet straps exclusively.) Step 9: Connect the spreader power cord to vehicle main power plug mounted at rear of vehicle (see Electrical Installation). L1185 © Trynex International 2009 5— 24...
  • Page 25 Mounting Instructions Model # SP-9500 Recommended Installation For Platform Bodies Through Floor Chain Tie Downs (6) Places Weld On Stake Pockets (6) Places. L1185 © Trynex International 2009 5— 25...
  • Page 26 • The Vibrator Switch is needed for dense material or to increase the ow to the auger. This eliminates bridging of material in hopper. • In case spreader becomes jammed, it will go into an auto-reverse program to free itself. Auger display will show (AR) while trying to clear obstruction. 5— 26 © Trynex International 2009 L1185...
  • Page 27 • You may repeat Steps 1 & 2 for a second and third time. • If after the third try the controller displays “OL” — you must extract the material that is causing the problem. • Follow all warning directions when clearing jams. L1185 © Trynex International 2009 5 — 27...
  • Page 28 • The main ba e assembly (D 6888) MUST never be removed from its original factory installed position unless the unit is being serviced or for installing the Optimum ow Kit. 5 — 28 © Trynex International 2009 L1185...
  • Page 29 • If you are using a sand/salt mixture, remove ba e extension. Part No. Description D 6776 Salt Ba e Extension D 6869 Discharge Ba e D 6874 #14 x 1-1/2" TEK w/Neo Washer © Trynex International 2009 5 — 29...
  • Page 30 (installed on Spreader from factory) Part No. Description Qty. D 6158 #10 Lock Nut D 6514 CHMSL Spreader Harness D 6529 #10 Black Oxide Screw CONNECT TO SPREADER LIGHT HARNESS 2-CONDUCTOR PLUG 5 — 30 © Trynex International 2009 L1185...
  • Page 31 Motor is not getting power. Turn o . Check all connections. display shows EO. Audible alarm beeping Vehicle battery is extremely low, Turn o . Charge battery. display shows LB. or a poor connection exists. © Trynex International 2009 L1185 5 — 31...
  • Page 32 BAD CONTROLLER LIGHTS NO DISPLAY TO BLUE WIRE CHECK WITH TEST KIT NOTHING HAPPENS BAD CONTROLLER NO DISPLAY CHECK POWER SOURCE TO CONTROLLER ON/OFF SWITCH WILL CHECK WITH TEST KIT NOT LIGHT UP 5 — 32 © Trynex International 2009 L1185...
  • Page 33 AUGER RUNS AT AUGER MOTOR REPLACE SPREADER FOR REVERSE VIBRATOR BACKWARDS HARNESS POLARITY SLOW TURN ON MATERIAL VIBRATOR FLOW INCREASE AUGER SPEED MATERIAL ISSUE * Spreader capable of speading most granular bulk material. © Trynex International 2009 L1185 5 — 33...

  • Page 34: Spreader Maintenance

    CAUTION – Vibrator is not designed for continuous duty. Allow motor to cool between long cycle times. • CAUTION – Do not modify vehicle or spreader wiring harness. Doing so will void product warranty. 5 — 34 © Trynex International 2009 L1185...
  • Page 35 3/4-10 7/8-9 Metric Grade 8.8 (ft.-lb.) SIZE TORQUE SIZE TORQUE M 12 M 14 M 10 M 16 These torque values apply to mount assembly fasteners except those noted in the instruction. © Trynex International 2009 L1185 5 — 35...
  • Page 36 THIS PAGE INTENTIONALLY LEFT BLANK 5 — 36 © Trynex International 2008 L1185...
  • Page 37 NOTES: ______________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ ________________________________________________________________________________________________________ © Trynex International 2009 L1185 5 — 37...

  • Page 38: Warranty

    Snowex dealers or Snowex personnel. Due to the corrosive properties of the materials dispensed by spreaders, Trynex does not warrant against damage caused by corrosion. Warranty claims by the user must be made to the dealer from where the product was purchased, unless otherwise authorized by Snowex.
  • Page 39 SnowEx Dealer Address: SnowEx Dealer Phone: Does your Trynex Dealer stock Trynex replacement Parts? I don’t know Do you feel your Trynex Dealer sold you the correct product for your needs/application? 10) How would you rate your overall satisfaction Very...
